SIEMENS 6ES7288-1SR60-0AA0 CPU SR60 S7-200 SMART | Replacement, Equivalent & Selection Guide
The SIEMENS 6ES7288-1SR60-0AA0 is a high-performance CPU module in the S7-200 SMART series, designed for compact automation applications requiring large I/O capacity. With 60 onboard I/O points (36 DI / 24 DO), AC power supply, and relay outputs, it is widely deployed in packaging, material handling, HVAC, and OEM machine control. This page provides full technical specifications, compatible replacement models, and a structured selection guide to help engineers and procurement teams make the right choice.
Technical Specifications
- Part Number: 6ES7288-1SR60-0AA0
- Series: SIMATIC S7-200 SMART
- CPU Type: SR60 (Standard, Relay Output)
- Power Supply: AC 85–264 V
- Digital Inputs: 36 × DC 24 V
- Digital Outputs: 24 × Relay, 2 A per point
- Onboard I/O: 60 points total
- Max Expandable I/O: Up to 188 points (with expansion modules)
- Program Memory: 24 KB
- Data Memory: 10 KB (retentive)
- High-Speed Counters: 4 × 200 kHz
- Pulse Outputs: 3 × 100 kHz (transistor models only; relay model supports motion via SB)
- Communication Ports: 1 × Ethernet (RJ45), 1 × RS-485
- Programming Software: STEP 7-Micro/WIN SMART
- Operating Temperature: 0–55 °C
- Protection Rating: IP20
- Dimensions (W×H×D): 196 × 100 × 81 mm
- Weight: Approx. 620 g
- Certifications: CE, UL, cULus, FM
Compatible Replacement & Equivalent Models
The table below lists direct replacements and functional equivalents for the 6ES7288-1SR60-0AA0, suitable for retrofit, spare-part sourcing, or cross-brand substitution:
- SIEMENS 6ES7288-1ST60-0AA0 — CPU ST60, same I/O count, transistor (sourcing) output; drop-in replacement for DC load applications
- SIEMENS 6ES7288-1SR40-0AA0 — CPU SR40, 40 I/O, relay output; downgrade option when full 60-point capacity is not required
- SIEMENS 6ES7288-1SR30-0AA0 — CPU SR30, 30 I/O, relay output; compact alternative for smaller panels
- SIEMENS 6ES7288-1SR20-0AA0 — CPU SR20, 20 I/O; entry-level S7-200 SMART for minimal I/O needs
- Mitsubishi FX3U-64MR/ES — 64 I/O, relay output, AC power; cross-brand functional equivalent with similar capacity
- Mitsubishi FX5U-64MR/ES — Next-generation Mitsubishi PLC; higher performance cross-brand alternative
- Omron CP1H-X40DR-A — 40 I/O, relay, AC; comparable compact PLC for cross-brand evaluation
Note: Cross-brand replacements require program re-engineering. Always verify I/O voltage levels, communication protocols, and software compatibility before substitution.
Why Choose the Original Model
- Seamless STEP 7-Micro/WIN SMART integration — no re-programming required when replacing like-for-like
- Proven reliability in harsh industrial environments with wide AC input range (85–264 V)
- Relay outputs provide galvanic isolation and compatibility with AC/DC loads without additional interface relays
- Largest I/O in the S7-200 SMART CPU range — eliminates the need for additional expansion in many applications
- Integrated Ethernet port enables direct PC programming, HMI connection, and peer-to-peer communication without extra modules
- Long-term SIEMENS support and global spare-parts availability
Typical Applications
- Packaging and labeling machines
- Conveyor and material handling systems
- HVAC and building automation panels
- Water treatment and pump control stations
- OEM machine control with mixed AC/DC loads
- Textile and printing machinery
- Food and beverage processing lines
System Compatibility
- Expansion Modules: Compatible with all S7-200 SMART EM modules (EM DE08, EM DT08, EM DR08, EM AE04, EM AQ02, etc.)
- Signal Boards: Supports SB AQ01, SB DT04, SB CM01 (RS-232/RS-485)
- HMI: SIMATIC Smart Line panels, KTP series via Ethernet or RS-485
- SCADA/DCS: Modbus RTU/TCP, S7 protocol via Ethernet
- Programming Software: STEP 7-Micro/WIN SMART V2.4 and above
- Power Supply: Requires external 24 V DC sensor supply for input circuits
Selection Guide
Use the following criteria to confirm the 6ES7288-1SR60-0AA0 is the right choice, or to identify the best alternative:
- I/O Count: Need ≤ 60 onboard points? → SR60. Need fewer? → SR40 / SR30 / SR20.
- Output Type: Relay (AC/DC loads, galvanic isolation) → SR60. Transistor (high-speed, DC only) → ST60.
- Power Supply: AC mains available → SR60 (AC). DC-only panel → consider ST60 (DC/DC/Transistor).
- Communication: Ethernet + RS-485 standard on all S7-200 SMART CPUs — no additional module needed.
- Expansion Needed: Up to 6 EM modules can be added; max 188 I/O total.
- Cross-Brand: If migrating from Mitsubishi FX3U or Omron CP1H, functional mapping is feasible but requires full program re-development.
Quality Assurance & Sourcing
- All units sourced from authorized distributors or verified secondary-market suppliers
- Each module undergoes incoming inspection: label verification, firmware version check, and power-on functional test
- Original SIEMENS packaging and documentation preserved where available
- Traceability records maintained for every batch
- Warranty: 12 months from shipment date (DOA replacement within 7 days)
How to Order
- Part Number: 6ES7288-1SR60-0AA0
- Minimum Order Quantity: 1 unit
- Lead Time: In-stock orders ship within 1–3 business days; contact us for bulk lead times
- Payment: T/T, PayPal, credit card, and trade-term arrangements available
- Shipping: DHL / FedEx / UPS worldwide; sea freight available for large orders
- Request a Quote: Email support@konmask.com or call +0086 19859288691
Replacement & Compatibility FAQ
Q: Can the 6ES7288-1ST60-0AA0 (ST60) directly replace the SR60?
A: Yes, for DC load applications. The ST60 uses transistor (sourcing) outputs instead of relay outputs. If your loads are AC or require galvanic isolation, retain the SR60.
Q: Is the 6ES7288-1SR60-0AA0 still in production?
A: The S7-200 SMART series remains in active production and sale as of 2026. It is not discontinued.
Q: Can I use a Mitsubishi FX3U-64MR as a drop-in replacement?
A: No. Cross-brand replacement requires full program re-development in GX Works2/3. Hardware wiring must also be re-verified.
Q: What is the maximum number of expansion modules?
A: Up to 6 EM expansion modules, reaching a maximum of 188 digital I/O points.
Q: Does the SR60 support motion control?
A: Relay output CPUs do not natively output high-speed pulses. Add an SB DT04 signal board for pulse output capability.
Q: What HMIs are compatible?
A: SIMATIC Smart Line panels (SMART 700 IE, SMART 1000 IE) and KTP series panels connect via Ethernet or RS-485.
