Siemens 6ES7288-7DP01-0AA0 PROFIBUS-DP Slave Module – SIMATIC S7-200 SMART Series
Imagine a distributed manufacturing line where dozens of remote I/O stations, drives, and sensors must exchange data with a central PLC in real time — without a reliable PROFIBUS-DP slave interface, the entire communication chain collapses. Conveyor lines halt, process variables go unmonitored, and unplanned downtime cascades across the facility. The Siemens 6ES7288-7DP01-0AA0 eliminates this risk by providing a dedicated, high-speed PROFIBUS-DP slave port that seamlessly integrates the S7-200 SMART CPU into any PROFIBUS network as a fully compliant slave station.
Within the SIMATIC S7-200 SMART ecosystem, the 6ES7288-7DP01-0AA0 occupies a critical communication role: it is the only expansion module that enables the S7-200 SMART to participate as a DP slave in a PROFIBUS network controlled by a higher-level master — such as a Siemens S7-300, S7-400, or S7-1500 PLC. This positions the module as an essential bridge in multi-tier automation architectures across automotive, food & beverage, water treatment, and discrete manufacturing industries worldwide.
Technical Specifications
- Part Number: 6ES7288-7DP01-0AA0
- Series: SIMATIC S7-200 SMART
- Module Type: PROFIBUS-DP Slave Communication Module
- Communication Protocol: PROFIBUS-DP (EN 50170)
- Max. Baud Rate: 12 Mbps
- DP Slave Address Range: 1–99
- Max. Input Data: 244 bytes
- Max. Output Data: 244 bytes
- Supply Voltage: 5 VDC (via S7-200 SMART CPU bus)
- Current Consumption (5 VDC): 130 mA (typical)
- Connector: 9-pin Sub-D female (RS-485)
- Dimensions (W × H × D): 45 mm × 90 mm × 81 mm
- Weight: approx. 176 g
- Operating Temperature: 0 °C to +55 °C
- Storage Temperature: −40 °C to +70 °C
- Relative Humidity: 5% to 95% (non-condensing)
- Protection Class: IP20
- Certifications: CE, UL, cULus
- Compatible CPUs: All S7-200 SMART CPU variants (SR20, SR30, SR40, SR60, ST20, ST30, ST40, ST60)
Key Features & Benefits
- Plug-and-Play DP Slave Integration: Connects directly to the S7-200 SMART CPU expansion bus — no additional power supply or wiring required beyond the PROFIBUS cable.
- High-Speed Communication: Supports PROFIBUS-DP baud rates up to 12 Mbps, ensuring deterministic, low-latency data exchange in time-critical applications.
- Large I/O Data Area: Up to 244 bytes of input and 244 bytes of output data allow complex process data to be exchanged with the DP master in a single cycle.
- Automatic Baud Rate Detection: The module automatically detects the network baud rate set by the DP master, simplifying commissioning.
- GSD File Support: Standard GSD file available for integration into any PROFIBUS master configuration tool (STEP 7, TIA Portal, third-party masters).
- Compact DIN-Rail Design: Slim 45 mm width minimizes cabinet space while maintaining full electrical isolation from the PROFIBUS network.
- LED Diagnostics: Onboard LEDs provide instant visual feedback on power status, DP communication state, and fault conditions.
Industry & Equipment Applications
- Automotive Manufacturing: Body-in-white welding lines, paint shop conveyors, and assembly station I/O integration via PROFIBUS networks.
- Food & Beverage: Bottling lines, filling machines, and packaging equipment where S7-200 SMART acts as a local slave under a central S7-300/400 master.
- Water & Wastewater Treatment: Pump station control, valve actuation, and remote monitoring in distributed SCADA/PROFIBUS architectures.
- Textile & Printing: Multi-axis drive coordination where frequency inverters and S7-200 SMART nodes share a common PROFIBUS segment.
- Building Automation: HVAC control panels integrated into facility-wide PROFIBUS networks managed by higher-level BMS controllers.
- Material Handling: Sorters, palletizers, and AGV charging stations requiring real-time I/O exchange with a central logistics PLC.
System Integration & Compatible Parts
The 6ES7288-7DP01-0AA0 is designed exclusively for the SIMATIC S7-200 SMART platform. It mounts directly to the right side of the CPU and communicates via the internal expansion bus. Typical system configurations include:
- Compatible CPUs: 6ES7288-1SR20-0AA0, 6ES7288-1SR30-0AA0, 6ES7288-1SR40-0AA0, 6ES7288-1SR60-0AA0, 6ES7288-1ST20-0AA0, 6ES7288-1ST30-0AA0, 6ES7288-1ST40-0AA0, 6ES7288-1ST60-0AA0
- PROFIBUS-DP Masters (examples): Siemens S7-300 CP 342-5, S7-400 CP 443-5, S7-1500 CM 1542-5, ET 200M IM 153-2
- PROFIBUS Cables & Connectors: Siemens 6XV1830-0EH10 (PROFIBUS cable), 6ES7972-0BB52-0XA0 (bus connector with terminating resistor)
- Programming Software: STEP 7 Micro/WIN SMART V2.x or later
- Max. Expansion Modules per CPU: Up to 6 expansion modules total (signal + communication modules combined)
Our Quality Assurance Process
At Konmask.com, every unit of the Siemens 6ES7288-7DP01-0AA0 passes through a rigorous multi-stage verification process before shipment:
- Source Verification: Units are sourced exclusively from authorized Siemens distributors and verified OEM channels with full traceability documentation.
- Visual Inspection: Each module is inspected for label authenticity, housing integrity, connector condition, and correct part number markings.
- Functional Testing: Where applicable, modules undergo power-on and communication handshake tests to confirm operational status.
- Anti-Counterfeit Check: Holographic labels, date codes, and firmware version markers are cross-referenced against Siemens OEM standards.
- Secure Packaging: ESD-safe bags, foam inserts, and double-wall cartons protect the module during international transit.
How to Order
- Submit your inquiry via the “Get a Quote” button on this page, or email support@konmask.com.
- Provide your required quantity, delivery destination, and any urgency requirements.
- Our team will respond within 24 business hours with availability, lead time, and a formal quotation.
- Upon order confirmation, we arrange export documentation, customs clearance support, and your preferred shipping method (DHL, FedEx, sea freight).
Why Choose Konmask.com?
- ✅ Specialized in Industrial Automation: 100% focus on PLC, DCS, HMI, and drive components — no generalist catalog noise.
- ✅ Global B2B Export Experience: Serving engineering firms, system integrators, and MRO buyers in 50+ countries.
- ✅ Competitive Lead Times: In-stock items ship within 3–5 business days; sourced items within 7–15 business days.
- ✅ Full Documentation Support: Commercial invoice, packing list, certificate of origin, and test reports provided on request.
- ✅ Dedicated Technical Support: Pre-sales compatibility checks and post-sales integration guidance from experienced automation engineers.
Frequently Asked Questions
- Q: Can the 6ES7288-7DP01-0AA0 act as a PROFIBUS-DP master?
- A: No. This module operates exclusively as a DP slave. The S7-200 SMART CPU itself does not support DP master functionality. For master operation, a higher-level PLC such as the S7-300 or S7-1500 with a CP module is required.
- Q: How many 6ES7288-7DP01-0AA0 modules can be connected to one S7-200 SMART CPU?
- A: Only one DP slave module can be connected per CPU, as the S7-200 SMART supports a single communication module slot in its expansion chain alongside up to 5 signal modules.
- Q: Is the GSD file available for third-party PROFIBUS masters?
- A: Yes. The standard GSD file for the 6ES7288-7DP01-0AA0 is available from the Siemens Industry Online Support portal and can be imported into any EN 50170-compliant PROFIBUS master configuration tool.
- Q: What is the maximum cable length for PROFIBUS at 12 Mbps?
- A: At 12 Mbps, the maximum segment length is 100 meters per PROFIBUS-DP specification. Repeaters can extend the network beyond this limit.
- Q: Do you provide a warranty for this module?
- A: Yes. Konmask.com provides a 12-month warranty against manufacturing defects for all verified OEM units. Please contact support@konmask.com for warranty claims.
