Siemens 6ES7313-5BE00-0AB0 CPU 313C-2 DP Processor Module | Replacement, Equivalent & Selection Guide
The Siemens 6ES7313-5BE00-0AB0 is a compact CPU module (CPU 313C-2 DP) from the SIMATIC S7-300 series, featuring integrated I/O and a PROFIBUS-DP interface. Designed for mid-range automation tasks, it is widely used in manufacturing, process control, and machine automation. This page provides full technical specifications, compatible replacements, and a selection guide to help engineers and procurement teams make informed decisions.
Technical Specifications
- Part Number: 6ES7313-5BE00-0AB0
- Series: SIMATIC S7-300
- CPU Type: CPU 313C-2 DP
- Work Memory: 32 KB
- Load Memory: 128 KB (integrated MMC slot)
- Processing Speed: 0.1 ms / 1000 instructions (binary)
- Integrated Digital I/O: 16 DI / 16 DO
- Integrated Analog I/O: 3 AI / 1 AO
- Communication Interface: MPI + PROFIBUS-DP (Master/Slave)
- Max. PROFIBUS-DP Slaves: 32
- Power Supply: 24 V DC (via backplane bus)
- Operating Temperature: 0 °C to +60 °C
- Dimensions (W×H×D): 80 × 125 × 130 mm
- Weight: Approx. 700 g
- Protection Class: IP20
- Programming Language: LAD, FBD, STL, SCL, CFC (via STEP 7)
- Firmware: V2.0
Compatible Replacement & Equivalent Models
When the 6ES7313-5BE00-0AB0 is discontinued or unavailable, the following models are commonly considered as replacements or functional equivalents:
- 6ES7313-5BF03-0AB0 — Direct successor (CPU 313C-2 DP, V3.3), pin-compatible, expanded memory, recommended upgrade
- 6ES7313-6BF03-0AB0 — CPU 313C-2 PtP, same form factor but RS-422/485 interface instead of DP; suitable if PROFIBUS is not required
- 6ES7314-1AG14-0AB0 — CPU 314, higher performance, no integrated I/O; requires additional SM modules
- 6ES7315-2EH14-0AB0 — CPU 315-2 DP, larger memory and more DP slaves; for expanded systems
- 6ES7318-3EL01-0AB0 — CPU 319-3 PN/DP, top-tier S7-300 CPU; overkill for simple replacements but future-proof
Note: Always verify firmware version, MMC card compatibility, and I/O mapping before substituting CPUs in live systems.
Why Choose the Original Model
- Proven Reliability: The 6ES7313-5BE00-0AB0 has a long field history in industrial environments with high MTBF ratings.
- Integrated I/O: Built-in 16 DI/16 DO and 3 AI/1 AO reduce wiring complexity and cabinet space.
- PROFIBUS-DP Master/Slave: Native DP interface enables direct connection to distributed I/O, drives, and field devices without additional CP modules.
- STEP 7 Ecosystem: Full compatibility with Siemens STEP 7 v5.x toolchain, widely available in maintenance teams.
- Spare Parts Availability: Konmask.com stocks tested, genuine units sourced from authorized channels.
Typical Applications
- Conveyor and material handling systems
- Packaging and bottling lines
- HVAC and building automation
- Water treatment and pump control
- Machine tool and CNC auxiliary control
- Distributed I/O networks via PROFIBUS-DP
System Compatibility
- Rack: SIMATIC S7-300 standard rail (e.g., 6ES7390-1AE80-0AA0)
- Power Supply: PS 307 series (e.g., 6ES7307-1BA01-0AA0, 6ES7307-1EA01-0AA0)
- Signal Modules: All S7-300 SM 321/322/331/332 series
- Memory Card: SIMATIC Micro Memory Card (MMC), e.g., 6ES7953-8LF31-0AA0
- Programming Software: SIMATIC STEP 7 v5.4 and above
- HMI: Compatible with SIMATIC HMI via MPI/PROFIBUS (e.g., TP700, KTP900)
- Communication Processors: CP 342-5 for additional DP ports if needed
Selection Guide
Use the table below to select the right CPU for your S7-300 application:
- Need integrated I/O + PROFIBUS-DP + 32 KB memory? → 6ES7313-5BE00-0AB0 (this unit) or successor 6ES7313-5BF03-0AB0
- Need integrated I/O + serial (RS-422/485) instead of DP? → 6ES7313-6BF03-0AB0 (CPU 313C-2 PtP)
- Need more memory (96 KB) without integrated I/O? → 6ES7314-1AG14-0AB0 (CPU 314)
- Need PROFINET (PN) interface? → 6ES7315-2FJ14-0AB0 (CPU 315-2 PN/DP)
- Need TIA Portal compatibility? → Consider migrating to S7-1200 (6ES7214 series) or S7-1500
- Replacing a failed unit like-for-like? → 6ES7313-5BF03-0AB0 is the safest drop-in with minimal reconfiguration
Quality Assurance & Sourcing
- Source: Genuine Siemens units; surplus, refurbished, or new-old-stock (NOS) clearly labeled
- Testing: Each unit is powered-on tested and firmware-verified before shipment
- Warranty: 90-day replacement warranty on all units
- Packaging: Anti-static ESD packaging with original accessories where available
- Certification: CE marked; RoHS compliant
- Lead Time: In-stock units ship within 1–3 business days; sourced units 5–15 business days
How to Order
- Confirm your part number: 6ES7313-5BE00-0AB0
- Specify quantity and preferred condition (new / refurbished / tested surplus)
- Add to cart or contact us for bulk pricing and lead time
- For urgent requirements, email support@konmask.com or call +0086 19859288691
- We accept T/T, PayPal, and major credit cards; LC available for large orders
Replacement & Compatibility FAQ
Q: Is 6ES7313-5BF03-0AB0 a direct drop-in replacement for 6ES7313-5BE00-0AB0?
A: Yes, in most cases. The BF03 is the successor with the same form factor and pinout. You will need to update the hardware configuration in STEP 7 and re-download the program. The MMC card from the old unit can typically be reused.
Q: Can I use this CPU with TIA Portal?
A: No. The 6ES7313-5BE00-0AB0 is only supported under SIMATIC STEP 7 v5.x. For TIA Portal, you need S7-1200 or S7-1500 series CPUs.
Q: Does this CPU support PROFINET?
A: No. It has MPI and PROFIBUS-DP interfaces only. For PROFINET, select a CPU 315-2 PN/DP or higher.
Q: What MMC card is required?
A: A SIMATIC Micro Memory Card (MMC) is required to store the program. Recommended: 6ES7953-8LF31-0AA0 (4 MB) or 6ES7953-8LJ31-0AA0 (8 MB).
Q: Can I mix this CPU with S7-400 modules?
A: No. S7-300 and S7-400 use different backplane buses and are not cross-compatible.
