Siemens 6ES7390-1AE80-0AA0 DIN Mounting Rail 480mm – SIMATIC S7-300 Series
Imagine a production line brought to a standstill — not because of a failed PLC CPU or a blown I/O module, but because the structural backbone holding the entire control cabinet together has failed. The mounting rail is the silent foundation of every SIMATIC S7-300 installation. Without a properly rated, dimensionally accurate rail, modules cannot be seated correctly, grounding integrity is compromised, and the entire automation system becomes unreliable. The Siemens 6ES7390-1AE80-0AA0 eliminates this risk by providing a certified, precision-engineered 480mm DIN rail purpose-built for S7-300 system assemblies.
Within the SIMATIC S7-300 mounting rail family, the 6ES7390-1AE80-0AA0 occupies the mid-range length position at 480mm — long enough to accommodate a full-featured S7-300 rack with CPU, power supply, and multiple I/O modules, yet compact enough for space-constrained control cabinets. As part of Siemens’ globally dominant SIMATIC S7-300 platform — one of the most widely deployed modular PLCs in discrete manufacturing, process automation, and infrastructure projects worldwide — this rail is a standard BOM component trusted by system integrators and OEMs across more than 100 countries.
Technical Specifications
- Part Number / SKU: 6ES7390-1AE80-0AA0
- Series: SIMATIC S7-300
- Description: Mounting Rail, 480mm
- Rail Length: 480 mm
- Weight: 647 g
- Material: Aluminum profile with integrated grounding bus
- Mounting Standard: Compatible with S7-300 module bus connectors
- Manufacturer: Siemens AG
- Product Family: SIMATIC S7-300 Accessories
Key Features & Benefits
- Precision 480mm Length: Optimized for mid-size S7-300 rack configurations, accommodating CPU + PS + up to 8 signal modules.
- Integrated Grounding: The rail provides a continuous low-impedance ground path for all mounted modules, ensuring EMC compliance and personnel safety.
- Robust Aluminum Construction: Resists mechanical stress, vibration, and thermal cycling in demanding industrial environments.
- OEM-Certified Compatibility: Designed and manufactured by Siemens to guarantee 100% mechanical and electrical compatibility with all S7-300 modules.
- Tool-Free Module Mounting: Modules snap and slide onto the rail with standard S7-300 bus connectors — no special tooling required.
- Cabinet Space Efficiency: 480mm length balances module capacity with control cabinet footprint optimization.
Industry & Equipment Applications
- Automotive Manufacturing: Body-in-white welding lines, paint shop conveyors, and assembly station PLCs.
- Food & Beverage: Packaging machinery, filling lines, and CIP (Clean-In-Place) control panels.
- Water & Wastewater Treatment: Pump station automation, SCADA-connected RTU panels.
- Oil & Gas: Wellhead control panels, compressor station automation.
- Machine Building (OEM): Standard rack assembly for custom machinery exported globally.
- Building Automation: HVAC control panels, energy management systems.
System Integration & Compatible Parts
The 6ES7390-1AE80-0AA0 is designed to work seamlessly within the SIMATIC S7-300 ecosystem. Compatible and commonly paired components include:
- Power Supplies: 6ES7307-1BA01-0AA0, 6ES7307-1EA01-0AA0
- CPU Modules: 6ES7314-1AG14-0AB0, 6ES7315-2EH14-0AB0, 6ES7317-2EK14-0AB0
- Digital I/O: 6ES7321-1BL00-0AA0, 6ES7322-1BL00-0AA0
- Bus Connectors: 6ES7390-0AA00-0AA0
- Shield Connecting Elements: 6ES7390-5AA00-0AA0
- Other Rail Lengths: 6ES7390-1AB60-0AA0 (160mm), 6ES7390-1BC00-0AA0 (530mm), 6ES7390-1AF30-0AA0 (830mm), 6ES7390-1AJ30-0AA0 (2000mm)
Our Quality Assurance Process
At Konmask.com, every SIMATIC S7-300 component — including the 6ES7390-1AE80-0AA0 mounting rail — passes through a rigorous multi-stage verification process before shipment:
- Source Verification: All units are sourced from authorized distributors or verified surplus channels with full traceability documentation.
- Physical Inspection: Dimensional check, surface condition assessment, and label/marking verification against Siemens OEM standards.
- Packaging Integrity: Anti-static and moisture-resistant packaging to prevent transit damage.
- Documentation: Certificate of conformity and packing list provided with every shipment.
How to Order
- Submit your inquiry via the Contact / RFQ form on this page.
- Provide your required quantity, delivery timeline, and destination country.
- Our technical sales team will respond within 24 business hours with availability, lead time, and a formal quotation.
- Upon order confirmation, we arrange export documentation and arrange shipment via your preferred freight method (DHL, FedEx, sea freight, etc.).
Why Choose Konmask.com?
- Industrial Automation Specialists: We focus exclusively on PLC, DCS, HMI, and automation hardware — not a general electronics marketplace.
- Global B2B Export Experience: Serving system integrators, MRO buyers, and OEM procurement teams in over 50 countries.
- Technical Pre-Sales Support: Our engineers can assist with compatibility verification, BOM review, and cross-reference identification.
- Competitive Lead Times: Extensive inventory network enables fast sourcing even for discontinued or long-lead Siemens parts.
- Secure Transactions: T/T, L/C, and other B2B payment terms available.
Frequently Asked Questions
- Q: Is the 6ES7390-1AE80-0AA0 compatible with SIMATIC S7-400 modules?
- A: No. This rail is specifically designed for the S7-300 module form factor. S7-400 systems use a different, wider rack system (e.g., 6ES7400-series racks).
- Q: Can I cut the 480mm rail to a shorter length?
- A: Siemens does not recommend cutting OEM rails, as this may compromise the grounding bus integrity and module alignment. Siemens offers multiple standard lengths — select the appropriate length for your application.
- Q: What is the maximum number of S7-300 modules that can be mounted on this rail?
- A: The 480mm rail can typically accommodate 1 power supply + 1 CPU + up to 8 signal/function modules, depending on individual module widths. Always verify your specific BOM against the rail length.
- Q: Do you provide export documentation for customs clearance?
- A: Yes. We provide commercial invoice, packing list, and certificate of conformity. Additional documentation (e.g., EUR.1, Form A) can be arranged upon request.
- Q: What is the lead time for the 6ES7390-1AE80-0AA0?
- A: Lead time depends on current stock levels. Please submit an RFQ for a real-time availability and lead time confirmation.
