Siemens 6ES7422-1FH00-0AA0 Digital Output Module – SIMATIC S7-400 Series
When a digital output module fails on a production line, the consequences are immediate and severe: actuators freeze, conveyor belts stop, robotic arms halt mid-cycle, and entire manufacturing cells go dark. Every minute of unplanned downtime costs thousands of dollars in lost output, emergency labor, and potential product scrap. The Siemens 6ES7422-1FH00-0AA0 is the critical link between your S7-400 controller and the physical world — without it, your automation system simply cannot act.
The 6ES7422-1FH00-0AA0 is a 16-channel 24 VDC digital output module purpose-built for the SIMATIC S7-400 platform — Siemens’ flagship high-performance PLC series designed for demanding process and manufacturing automation. Within the S7-400 family, this module occupies the mid-range output tier, offering a balance of channel density, current capacity (2 A per channel), and diagnostic capability that makes it the go-to choice for machine builders and system integrators worldwide. The S7-400 platform powers critical infrastructure across automotive, chemical, oil & gas, and heavy industry sectors globally, and this module is one of its most widely deployed I/O components.
Technical Specifications
- Part Number: 6ES7422-1FH00-0AA0
- Series: SIMATIC S7-400
- Module Type: Digital Output (DO)
- Number of Outputs: 16 channels
- Output Voltage: 24 VDC
- Output Current: 2 A per channel
- Output Type: Transistor (sourcing)
- Backplane Bus: S7-400 central rack / expansion rack
- Isolation: Optocoupler isolation between field and backplane
- Diagnostics: Short-circuit and overload detection per channel
- Dimensions (W×H×D): 25 mm × 290 mm × 210 mm (standard S7-400 form factor)
- Weight: Approx. 800 g
- Operating Temperature: 0 °C to +60 °C
- Storage Temperature: −40 °C to +70 °C
- Degree of Protection: IP20
- Standards: CE, UL, cULus, ATEX (zone 2)
Key Features & Benefits
- 16 Independent Output Channels: High channel density reduces rack space and wiring complexity in large-scale control panels.
- 2 A Per Channel Output: Sufficient to drive solenoid valves, contactors, indicator lamps, and small actuators directly without intermediate relays.
- Per-Channel Diagnostics: Short-circuit and wire-break detection with status feedback to the CPU — enabling predictive maintenance and faster fault isolation.
- Optocoupler Isolation: Protects the S7-400 backplane from field-side voltage transients and ground loops common in industrial environments.
- Hot-Swap Compatible: Supports module replacement under power in redundant S7-400 configurations, minimizing maintenance downtime.
- Proven Reliability: Designed to Siemens’ SIMATIC quality standards with MTBF exceeding 500,000 hours in typical industrial conditions.
- Seamless STEP 7 / TIA Portal Integration: Fully supported in both classic STEP 7 and TIA Portal V13+ engineering environments with pre-configured hardware catalog entries.
Industry & Equipment Applications
- Automotive Manufacturing: Body-in-white welding lines, paint shop conveyors, assembly robot cell control
- Chemical & Petrochemical: Valve actuation in batch reactors, pump control in process skids
- Oil & Gas: Wellhead control panels, pipeline valve automation, compressor station control
- Food & Beverage: Filling line actuator control, CIP/SIP valve sequencing
- Power Generation: Turbine auxiliary control, switchgear automation
- Water & Wastewater: Pump station control, dosing valve automation
- Mining & Metals: Conveyor drive control, crusher and mill auxiliary systems
System Integration & Compatible Parts
The 6ES7422-1FH00-0AA0 is designed to operate within the SIMATIC S7-400 ecosystem. Compatible and commonly paired components include:
- CPUs: 6ES7412-x, 6ES7414-x, 6ES7416-x, 6ES7417-x series CPU modules
- Power Supplies: 6ES7407-0DA02-0AA0, 6ES7407-0KA02-0AA0
- Racks: 6ES7400-1JA01-0AA0 (UR1), 6ES7400-2JA00-0AA0 (UR2)
- Digital Input Modules: 6ES7421-1BL01-0AA0, 6ES7421-7BH01-0AB0
- Front Connectors: 6ES7492-1AL00-0AA0 (40-pin)
- IM (Interface Modules): 6ES7460-1BA01-0AA0 / 6ES7461-1BA01-0AA0 for expansion racks
Our Quality Assurance Process
At Konmask.com, every Siemens module we supply undergoes a rigorous multi-stage verification process before shipment:
- Authenticity Verification: Cross-reference of serial numbers, date codes, and holographic labels against Siemens’ product authentication database.
- Visual Inspection: 100% inspection for physical damage, connector pin integrity, and label completeness.
- Functional Test (where applicable): Power-on test and I/O channel verification using calibrated test equipment.
- Packaging: Anti-static ESD packaging with desiccant, foam cushioning, and tamper-evident sealing for safe international transit.
- Documentation: Certificate of conformity and test report available upon request.
How to Order
- Submit your inquiry via the Contact Us form or email support@konmask.com with your required quantity and delivery timeline.
- Our technical team will confirm availability, lead time, and provide a formal quotation within 24 business hours.
- Upon PO confirmation, we arrange secure packaging and international shipping via DHL, FedEx, or UPS with full tracking.
- Post-delivery technical support is available for integration and commissioning questions.
Why Choose Konmask.com?
- ✅ Specialized in Industrial Automation: We focus exclusively on PLC, DCS, and automation hardware — not a generalist marketplace.
- ✅ Global Supply Network: Access to both new and surplus Siemens inventory from verified international sources.
- ✅ Fast Response: Dedicated B2B inquiry team with <24h quotation turnaround.
- ✅ Secure International Shipping: Export-compliant packaging and documentation for customs clearance.
- ✅ Technical Expertise: Our team includes qualified automation engineers who can advise on compatibility and system integration.
- ✅ Competitive Pricing: Direct sourcing relationships enable pricing advantages for volume orders.
Frequently Asked Questions
Q: Is the 6ES7422-1FH00-0AA0 compatible with both STEP 7 and TIA Portal?
A: Yes. This module is fully supported in STEP 7 V5.x (classic) and TIA Portal V13 and later. The hardware catalog entry is available in both environments.
Q: Can this module be used in a redundant S7-400H system?
A: The 6ES7422-1FH00-0AA0 is a standard (non-F, non-H) output module. It can be used in the standard I/O racks of an S7-400H system but is not a redundant or fail-safe module itself.
Q: What is the difference between 6ES7422-1FH00-0AA0 and 6ES7422-1BL00-0AA0?
A: The 1FH00 variant provides 16 channels at 24 VDC / 2 A (transistor output), while the 1BL00 variant offers 32 channels at 24 VDC / 0.5 A. Choose 1FH00 for higher current loads per channel; choose 1BL00 for higher channel density with lighter loads.
Q: Do you supply new, refurbished, or surplus units?
A: We supply both new (factory-sealed) and tested surplus units depending on availability. The condition is clearly stated in our quotation. All units pass our QA process regardless of condition.
Q: What is the typical lead time?
A: In-stock units ship within 2–5 business days internationally. For sourced units, lead time is typically 7–15 business days. We confirm exact lead time in the quotation.
Q: Can I get a datasheet or technical documentation?
A: Yes. Contact us at support@konmask.com and we will provide the official Siemens datasheet and, where applicable, our test report.
