SIEMENS 6GK7343-1EX11-0XE0 Ethernet Communication Module – SIMATIC S7-300 CP 343-1 EX11
When an Ethernet communication processor fails on a SIMATIC S7-300 production line, the consequences are immediate and severe: the PLC loses its network connection, SCADA systems go blind, remote diagnostics become impossible, and in multi-controller architectures, entire production cells halt. Downtime in automotive stamping, pharmaceutical batch processing, or water treatment facilities can cost thousands of dollars per minute. The SIEMENS 6GK7343-1EX11-0XE0 — the CP 343-1 EX11 — is the single module that restores that critical data highway between your S7-300 controller and the plant-wide Industrial Ethernet backbone.
Within the SIMATIC S7-300 communication processor family, the CP 343-1 EX11 occupies the mid-range performance tier, offering full TCP/IP, ISO-on-TCP, and S7 communication protocols over 10/100 Mbit/s Ethernet. It is one of the most widely deployed Ethernet CPs in the S7-300 ecosystem globally, found in tens of thousands of installations across automotive, food & beverage, energy, and process industries. Its proven firmware stability and broad STEP 7 / TIA Portal compatibility make it the default specification for engineers upgrading legacy S7-300 networks to modern Ethernet topologies.
Technical Specifications
| Part Number | 6GK7343-1EX11-0XE0 |
| Product Family | SIMATIC S7-300 CP 343-1 |
| Module Type | Communications Processor (CP) |
| Network Interface | Industrial Ethernet (10/100 Mbit/s), RJ45 |
| Supported Protocols | TCP/IP, ISO-on-TCP, UDP, S7 Communication, FETCH/WRITE, SEND/RECEIVE |
| Max. Connections | 16 configurable connections |
| Data Transfer Rate | 10/100 Mbit/s (auto-sensing) |
| Supply Voltage | DC 5 V (via S7-300 backplane bus) |
| Power Consumption | Approx. 1.2 W |
| Operating Temperature | 0 °C to +60 °C |
| Storage Temperature | -40 °C to +70 °C |
| Dimensions (W×H×D) | 40 mm × 125 mm × 120 mm |
| Weight | Approx. 500 g |
| Degree of Protection | IP20 |
| Configuration Tool | STEP 7 V5.x / TIA Portal (with HSP) |
| Certifications | CE, UL, cULus, FM, ATEX (Zone 2) |
Note: Specifications are based on published Siemens documentation. Always verify against the official datasheet for your specific firmware revision.
Key Features & Benefits
- Dual-protocol flexibility: Supports both S7 communication (for Siemens-to-Siemens data exchange) and open TCP/IP standards (for third-party SCADA, MES, and HMI integration) on a single module.
- Auto-sensing 10/100 Mbit/s: Automatically negotiates link speed, eliminating manual configuration and ensuring compatibility with both legacy 10 Mbit/s hubs and modern 100 Mbit/s switches.
- 16 simultaneous connections: Handles multiple concurrent communication partners — CPUs, HMIs, SCADA servers, and remote I/O — without performance degradation.
- FETCH/WRITE server: Enables passive data access from third-party systems without requiring PLC program changes, ideal for retrofitting legacy lines.
- Integrated web diagnostics: Built-in web server provides real-time module status, connection diagnostics, and I&M data accessible via standard browser — no additional software required.
- Hot-swap capable: Can be replaced on the S7-300 rack without powering down the entire rack (subject to system configuration), minimizing maintenance downtime.
- PROFINET-ready network topology: Integrates seamlessly into star, line, and ring Ethernet topologies used in modern PROFINET-based plant networks.
Industry & Equipment Applications
- Automotive Manufacturing: Body-in-white welding lines, paint shop conveyors, and press shop automation where S7-300 PLCs communicate with plant MES systems over Ethernet.
- Food & Beverage: Bottling lines, pasteurization systems, and CIP (Clean-In-Place) stations requiring real-time data logging to SCADA historians.
- Pharmaceutical & Life Sciences: Batch reactors and filling lines operating under FDA 21 CFR Part 11 environments where audit-trail data must be transmitted to MES in real time.
- Water & Wastewater Treatment: Pump stations and filtration systems with remote monitoring requirements over TCP/IP to central SCADA.
- Energy & Power Generation: Substation automation and turbine control panels where S7-300 controllers interface with energy management systems.
- Machine Tool & OEM Equipment: CNC machining centers and packaging machines where the CP 343-1 provides the Ethernet gateway for remote diagnostics and firmware updates.
System Integration & Compatible Parts
The 6GK7343-1EX11-0XE0 is designed for direct installation into any SIMATIC S7-300 rack. Typical system bill of materials includes:
- Host PLC Rack: SIMATIC S7-300 series (e.g., 6ES7300-1AH14-0AA0 Rail)
- Power Supply: PS 307 series (e.g., 6ES7307-1EA01-0AA0)
- CPU: S7-300 CPU 314 / 315 / 317 / 319 series
- Network Switch: SCALANCE X series (e.g., X208, X216) for managed Ethernet topology
- Patch Cable: IE FC RJ45 Plug 180 (6GK1901-1BB10-2AA0) with IE FC TP Standard Cable
- Configuration Software: STEP 7 Professional V5.6 or TIA Portal V15+ with S7-300 HSP
Our Quality Assurance Process
At Konmask.com, every SIEMENS module undergoes a structured verification process before shipment:
- Source verification: Units are sourced exclusively from authorized distributors, certified resellers, or directly from decommissioned OEM equipment with traceable maintenance records.
- Visual & physical inspection: Housing integrity, connector condition, label authenticity (hologram, date codes, firmware stickers), and backplane connector pin inspection.
- Functional power-on test: Module is seated in an S7-300 test rack, powered, and verified to enumerate correctly on the backplane bus with green LED status confirmation.
- Anti-static packaging: Shipped in ESD-safe bags with foam cushioning and double-wall carton to prevent transit damage.
- Documentation: Each shipment includes a packing list with serial number, firmware version (where readable), and inspection sign-off.
How to Order
- Submit an inquiry: Email [email protected] or call +0086 19859288691 with your required quantity and delivery timeline.
- Receive a quotation: Our team responds within 1 business day with pricing, lead time, and available stock confirmation.
- Confirm & pay: We accept T/T (bank transfer), PayPal, and other B2B payment terms for qualified accounts.
- Shipment & tracking: Orders are dispatched via DHL, FedEx, or UPS Express with full tracking. Export documentation (commercial invoice, packing list, COO) provided for customs clearance.
Why Choose Konmask.com?
- Industrial automation specialists: We focus exclusively on PLC, DCS, and industrial communication components — not a generalist electronics marketplace.
- Global B2B supply chain: Serving engineering teams and procurement departments across Southeast Asia, the Middle East, Europe, and the Americas.
- Fast response, no minimum order: Single-unit inquiries are welcome. We understand that one missing module can stop an entire production line.
- Transparent sourcing: We disclose the condition (new, surplus-new, refurbished) and source of every unit. No surprises.
- Technical pre-sales support: Our team can advise on firmware compatibility, replacement alternatives, and system integration questions before you commit to a purchase.
Frequently Asked Questions
Q: Is the 6GK7343-1EX11-0XE0 compatible with TIA Portal?
A: Yes, with the installation of the appropriate Hardware Support Package (HSP) for S7-300 CPs in TIA Portal V13 and above. Full native support is available in STEP 7 V5.x.
Q: What is the difference between 6GK7343-1EX11-0XE0 and 6GK7343-1EX30-0XE0?
A: The EX30 variant is a newer hardware revision with enhanced web server functionality and additional protocol support. The EX11 is the proven predecessor widely available as surplus-new stock and fully functional for standard S7 and TCP/IP communication tasks.
Q: Can this module replace a 6GK7343-1CX10-0XE0 (CP 343-1 Lean)?
A: No — the CP 343-1 Lean is a reduced-feature variant. The 6GK7343-1EX11-0XE0 is a full CP 343-1 and offers more connections and protocol options, making it a functional upgrade but not a drop-in replacement without reconfiguration.
Q: Do you provide a warranty?
A: Yes. We offer a 90-day functional warranty on all modules. If a unit fails under normal operating conditions within the warranty period, we will replace or refund it.
Q: Can you supply multiple units for a plant-wide upgrade project?
A: Yes. Contact us with your project BOM and timeline. We can reserve stock and coordinate phased deliveries to match your installation schedule.
