Industrial Motor Control Solution – SIEMENS 6SE7027-2TD84-1HF3 | SIMOVERT MASTERDRIVES
Where This Product Is Used
The SIEMENS 6SE7027-2TD84-1HF3 is a high-performance AC variable frequency drive (VFD) from the SIMOVERT MASTERDRIVES Vector Control series, engineered for demanding industrial motor control applications. Engineers and system integrators specify this drive across the following sectors:
- Water & Wastewater Treatment: Pump speed regulation for municipal water supply, sewage lift stations, and desalination plants — delivering precise flow control and significant energy savings over fixed-speed operation.
- HVAC & Building Automation: Fan and air-handling unit (AHU) speed control in large commercial buildings, data centers, and cleanrooms requiring stable airflow and pressure management.
- Oil & Gas / Petrochemical: Compressor and blower drives in hazardous-area-adjacent control panels, where reliable torque response and fault diagnostics are critical.
- Cement & Mining: Conveyor belt drives, crusher auxiliaries, and kiln fan control where high starting torque and robust overload capacity are mandatory.
- Pulp & Paper / Textile: Winder and unwinder tension control, extruder drives, and multi-motor coordinated line speed applications.
- Marine & Offshore: Thruster and pump drives aboard vessels requiring compact, high-efficiency power conversion.
Technical Specifications
| Parameter | Value |
|---|---|
| Part Number / SKU | 6SE7027-2TD84-1HF3 |
| Brand / Manufacturer | SIEMENS |
| Product Series | SIMOVERT MASTERDRIVES Vector Control (VC) |
| Drive Type | AC Variable Frequency Drive (VFD) |
| Rated Output Power | 75 kW (100 HP) |
| Input Voltage | 3-Phase 380–480 V AC (±10%) |
| Input Frequency | 47–63 Hz |
| Output Voltage | 0 – Input Voltage (3-Phase) |
| Output Current (Rated) | ~145 A |
| Control Mode | Vector Control (Sensorless & Encoder Feedback) |
| Overload Capacity | 150% for 60 s / 200% for 3 s |
| Protection Class | IP20 (cabinet-mount) |
| Cooling Method | Forced air cooling (internal fan) |
| Communication Interface | PROFIBUS-DP (via -1HF3 option board) |
| Braking | Dynamic braking ready (external resistor) |
| Ambient Temperature | 0°C to +40°C (derating above 40°C) |
| Storage Temperature | -25°C to +70°C |
| Humidity | ≤ 95% RH, non-condensing |
| Weight (approx.) | 45 kg |
| Country of Origin | Germany |
Why Engineers Specify This Model
- PROFIBUS-DP Integration (-1HF3): The -1HF3 option board provides native PROFIBUS-DP connectivity, enabling seamless integration into SIMATIC S7 PLC networks and distributed I/O architectures without additional gateways.
- True Vector Control: Closed-loop and sensorless vector control delivers precise torque regulation from near-zero speed — critical for hoists, winders, and process lines where speed accuracy is non-negotiable.
- Proven MASTERDRIVES Platform: Backed by decades of field deployment in heavy industry, the SIMOVERT MASTERDRIVES platform offers extensive spare-parts availability, global service networks, and well-documented parameter sets.
- High Overload Tolerance: 150%/60 s overload rating handles demanding start cycles in compressors and conveyors without nuisance tripping.
- Modular Option Board Architecture: Supports encoder feedback, additional I/O, and technology boards (T400, T100) for application-specific control functions.
- Energy Efficiency: Variable-speed operation on pump and fan loads typically reduces energy consumption by 30–50% versus fixed-speed DOL starters.
Complete System Bill of Materials
For a complete SIMOVERT MASTERDRIVES installation, engineers typically specify the following complementary components:
- Input Line Reactor: 4% UK reactor for harmonic mitigation and supply protection
- Output dV/dt Filter: Protects motor winding insulation on long cable runs (>50 m)
- Braking Resistor: External resistor module for regenerative braking applications
- Encoder Feedback Module: SBP or SBR board for closed-loop vector control
- PROFIBUS Terminator: Bus termination plug for PROFIBUS-DP segment end
- Control Panel / HMI: SIMATIC OP/TP panel for local parameter access and diagnostics
- Fuses & Circuit Breaker: Appropriately rated upstream protection per IEC 60364
- Shielded Motor Cable: Low-capacitance screened cable to minimize EMC emissions
Compliance & Industry Standards
- CE Marked – EU Low Voltage Directive (2014/35/EU) & EMC Directive (2014/30/EU)
- UL Listed / cUL (where applicable)
- IEC 61800-3 (Adjustable Speed Electrical Power Drive Systems – EMC)
- IEC 61800-5-1 (Safety requirements for adjustable speed drive systems)
- EN 55011 Class C2 EMC compliance
- RoHS compliant
Quality Assurance & Sourcing
At Konmask.com, every SIEMENS drive unit undergoes a structured incoming inspection process before dispatch:
- Visual inspection for physical damage, label integrity, and firmware version verification
- Parameter backup and factory-reset confirmation where applicable
- Functional power-on test with load bank (available on request)
- Sourced from authorized SIEMENS distribution channels and verified surplus inventory with full traceability documentation
- Packaging: anti-static foam, moisture-barrier bag, and double-wall carton for international freight
How to Source This Part
Ready to procure the SIEMENS 6SE7027-2TD84-1HF3? Here’s how to get started:
- Request a Quote: Email support@konmask.com with your required quantity and delivery timeline.
- Lead Time: In-stock units ship within 3–5 business days. Ex-stock or special-order units: 2–4 weeks.
- MOQ: 1 unit (no minimum order quantity).
- Payment Terms: T/T, PayPal, and trade credit available for qualified accounts.
- Export & Customs: We handle export documentation, HS code declaration (8504.40.19.90), and commercial invoicing for international shipments.
- Warranty: 12-month warranty against manufacturing defects. Replacement or full refund policy.
Application-Specific FAQ
Q: Can the 6SE7027-2TD84-1HF3 control a pump in a closed-loop pressure control loop?
A: Yes. With a PROFIBUS-DP connection to a SIMATIC S7 PLC and a 4–20 mA pressure transmitter wired to the drive’s analog input, closed-loop PID pressure control is fully supported via the drive’s built-in technology functions.
Q: Is this drive compatible with SIMATIC S7-300/400 via PROFIBUS?
A: Yes. The -1HF3 option board provides a native PROFIBUS-DP slave interface. The drive is fully compatible with SIMATIC S7-300, S7-400, and S7-1500 (via DP master) using standard GSD files.
Q: What motor types are supported?
A: Standard asynchronous (induction) motors and synchronous motors (with encoder feedback). The drive supports both sensorless vector and closed-loop vector control modes.
Q: Can I use this drive as a replacement for an existing 6SE70 series unit?
A: In most cases, yes — provided the power rating, voltage class, and option boards match. Parameter sets from existing units can be uploaded via the serial interface or PROFIBUS for rapid commissioning.
Q: What is the difference between the -1HF3 and other option suffixes?
A: The -1HF3 suffix denotes the PROFIBUS-DP communication option board. Other suffixes indicate different fieldbus options (e.g., DeviceNet, CANopen) or technology boards. Confirm your fieldbus protocol before ordering.
