SIEMENS 6SE7031-7HG84-1JC1 Inverter Triggering Module | Replacement, Equivalent & Selection Guide
The SIEMENS 6SE7031-7HG84-1JC1 is a dedicated Inverter Triggering Module designed for the SIEMENS MASTERDRIVES series of variable-frequency drives. It serves as the gate-drive interface between the control board and the IGBT power stack, ensuring precise, reliable switching for demanding industrial motion-control applications. Konmask.com supplies genuine and compatible units with full traceability for B2B buyers worldwide.
Technical Specifications
- Part Number: 6SE7031-7HG84-1JC1
- Manufacturer: SIEMENS
- Series: MASTERDRIVES MC / VC
- Module Type: Inverter Triggering Module (Gate Drive Board)
- Compatible Drive Frame: Frame Size F (approx. 37–75 kW range)
- Rated Current Class: 31.7 A (refer to drive nameplate for exact rating)
- Supply Voltage: 24 V DC (internal bus)
- Interface: Fiber-optic / direct IGBT gate signal
- HS Code: 853710
- Weight: 150 g (approx.)
- Condition: New / Refurbished available — specify on inquiry
Compatible Replacement & Equivalent Models
The table below lists known compatible and functionally equivalent triggering modules. Always verify frame size, current rating, and firmware revision before substitution.
| Part Number | Series | Notes |
|---|---|---|
| 6SE7031-7HG84-1JC1 | MASTERDRIVES | Original — this listing |
| 6SE7031-5EF84-1JC1 | MASTERDRIVES | Lower current class variant; verify rating |
| 6SE7031-2EF84-1JC1 | MASTERDRIVES | Compact frame equivalent; confirm dimensions |
| 6SE7023-4TC84-1JC1 | MASTERDRIVES | Cross-reference — confirm IGBT stack compatibility |
Note: Cross-referencing requires matching the IGBT module type, gate-drive voltage, and fiber-optic connector pinout. Contact Konmask technical support for a verified substitution check.
Why Choose the Original Model
- Exact OEM fit: Plug-and-play replacement with no firmware or parameter changes required.
- Validated gate timing: Factory-calibrated dead-time and gate-drive strength matched to the MASTERDRIVES IGBT stack.
- Traceability: Full batch and date-code documentation available for MRO and audit requirements.
- Warranty: 12-month warranty on new units; 6-month on refurbished units.
Typical Applications
- Variable-speed drives for pumps, fans, compressors, and conveyors
- Crane and hoist motion-control systems
- Steel mill and paper-machine drive retrofits
- HVAC central plant variable-frequency drive maintenance
- Marine and offshore drive systems using SIEMENS MASTERDRIVES platforms
System Compatibility
- Drive Family: SIEMENS MASTERDRIVES MC (Motion Control) & VC (Vector Control)
- Control Boards: CU1, CU2, CU3 series within MASTERDRIVES
- IGBT Power Modules: Compatible with Eupec / Infineon BSM modules used in Frame F drives
- Firmware: Compatible with MASTERDRIVES firmware V3.x and above (confirm with drive nameplate)
Selection Guide
Use the following checklist to confirm the correct triggering module for your drive:
- Identify the drive frame size from the nameplate (Frame D / E / F / G).
- Note the rated output current (e.g., 31.7 A for 6SE7031-x).
- Confirm the IGBT module type installed in the power stack.
- Check the fiber-optic connector type (HFBR vs. direct PCB).
- Verify firmware revision compatibility with your CU board.
- If unsure, send your drive nameplate photo to support@konmask.com for a free selection check.
Quality Assurance & Sourcing
- Units sourced from authorized SIEMENS distributors and certified MRO channels.
- Each module undergoes incoming inspection: visual, dimensional, and functional gate-signal verification.
- Anti-static packaging with humidity indicator card for safe international shipping.
- Certificate of Conformance (CoC) and test report available on request.
- Export-compliant documentation (commercial invoice, packing list, HS 853710) provided for all international orders.
How to Order
- Add to cart directly, or
- Email support@konmask.com with your drive nameplate details for a quotation.
- WhatsApp / Phone: +0086 19859288691 for urgent inquiries.
- Lead time: In-stock units ship within 1–3 business days; sourced units 5–15 business days.
- Payment: T/T, PayPal, credit card, and trade-assurance options available.
Replacement & Compatibility FAQ
Q: Can I use 6SE7031-5EF84-1JC1 as a direct replacement?
A: Only if the current rating and IGBT stack match. Contact us for a verified cross-reference before ordering.
Q: Is this module compatible with SINAMICS drives?
A: No. The 6SE7031-7HG84-1JC1 is specific to the MASTERDRIVES platform. SINAMICS uses a different gate-drive architecture.
Q: Do you supply refurbished units?
A: Yes. Refurbished units are fully tested and carry a 6-month warranty. Specify “refurbished” in your inquiry for pricing.
Q: Can you provide a datasheet?
A: Yes. Request the SIEMENS MASTERDRIVES hardware installation manual and module datasheet via email.
Q: What is the lead time for out-of-stock units?
A: Typically 5–15 business days depending on sourcing channel. Rush sourcing available — contact us.
