Harsh-Environment HMI Solution – Siemens 6AG1124-0MC01-4AX0 | SIPLUS HMI TP1200 Comfort
The Siemens SIPLUS HMI TP1200 Comfort (6AG1124-0MC01-4AX0) is the ruggedized evolution of the standard SIMATIC TP1200 Comfort, purpose-engineered for demanding industrial environments where standard panels fail. With extended temperature tolerance, enhanced vibration resistance, and conformal-coated PCBs, this 12-inch widescreen touch panel delivers reliable human-machine interface performance in chemical plants, offshore platforms, steel mills, and outdoor machinery — wherever uptime is non-negotiable.
Where This Product Is Used
- Chemical & Petrochemical Plants – Corrosive atmosphere resistance makes it ideal for process control panels near reactors and pipelines.
- Steel & Metal Processing – Withstands high ambient temperatures and heavy vibration from rolling mills and furnace lines.
- Offshore & Marine Applications – Salt-fog and humidity resistance supports deployment on drilling platforms and vessel control rooms.
- Outdoor Machinery & Mobile Equipment – Extended operating temperature range (-20 °C to +60 °C) covers outdoor kiosks, agricultural machinery, and construction equipment.
- Water & Wastewater Treatment – IP65 front protection and robust enclosure suit wet, dusty pump-station environments.
- Automotive Manufacturing – High-cycle touch reliability and vibration tolerance support press lines and robotic welding cells.
- Power Generation & Utilities – EMC-hardened design operates reliably near high-voltage switchgear and transformer rooms.
Technical Specifications
| Part Number | 6AG1124-0MC01-4AX0 |
| Series | SIPLUS HMI TP1200 Comfort |
| Display Size | 12.1″ Widescreen TFT |
| Resolution | 1280 × 800 px |
| Touch Type | Resistive, multi-touch capable |
| Operating Temperature | -20 °C to +60 °C |
| Storage Temperature | -40 °C to +70 °C |
| Protection Rating | IP65 (front) / IP20 (rear) |
| Supply Voltage | 24 V DC |
| Processor | ARM Cortex-A8, 600 MHz |
| RAM / Flash | 128 MB / 24 MB |
| Interfaces | 2× PROFINET, 2× USB, 1× MPI/PROFIBUS, 1× RS-422/485 |
| Conformal Coating | Yes (PCB protected) |
| Weight | 3.6 kg |
| Certifications | CE, UL, cULus, ATEX Zone 2 (option) |
Why Engineers Specify This Model
- SIPLUS Ruggedization – Conformal-coated boards and extended temperature range go beyond standard SIMATIC specs, reducing field failures in harsh sites.
- Seamless TIA Portal Integration – Programmed identically to standard TP1200 Comfort; no retraining required for existing Siemens engineering teams.
- High-Brightness Display – 450 cd/m² backlight ensures readability in bright outdoor or high-ambient-light factory conditions.
- Long Product Lifecycle – Siemens SIPLUS line is designed for extended availability, reducing obsolescence risk for long-running plant projects.
- Broad Protocol Support – Native PROFINET IRT, PROFIBUS, and serial interfaces cover legacy and modern automation architectures.
- Proven Global Installed Base – Deployed across thousands of sites in process, discrete, and hybrid manufacturing worldwide.
Complete System Bill of Materials
- Siemens 6AG1124-0MC01-4AX0 – SIPLUS HMI TP1200 Comfort (this unit)
- Siemens 6ES7972-0CB35-0XA0 – PROFIBUS connector for MPI/DP port
- Siemens 6GK1901-1BB10-2AE0 – PROFINET RJ45 patch cable
- Siemens 6EP1332-1SH71 – SITOP PSU100S 24 V / 3 A power supply
- Siemens 6AV2181-8XP00-0AX0 – Panel mounting clamps set
- Siemens 6AV2124-0MC01-0AX0 – Standard TP1200 Comfort (non-SIPLUS alternative)
Compliance & Industry Standards
- CE Marking – Compliant with EU Machinery Directive 2006/42/EC and EMC Directive 2014/30/EU.
- UL / cULus Listed – Recognized for North American industrial control panel applications.
- IEC 61131-2 – Programmable controller equipment standard compliance.
- ATEX / IECEx Zone 2 – Available with optional ATEX certification for gas-hazardous areas (confirm at order).
- RoHS Compliant – Meets EU Directive 2011/65/EU on restriction of hazardous substances.
- REACH Compliant – No substances of very high concern above threshold limits.
Quality Assurance & Sourcing
Every unit supplied by Konmask.com undergoes a documented 4-step verification process:
- Origin Verification – Serial number and date code cross-referenced against Siemens production records.
- Physical Inspection – Label integrity, connector condition, and cosmetic assessment by trained technicians.
- Functional Power-On Test – Display, touch calibration, and communication ports verified before dispatch.
- Packaging & ESD Audit – Anti-static packaging, humidity indicators, and tamper-evident sealing confirmed.
We source exclusively from authorized distributors, OEM decommissions, and verified surplus channels. Counterfeit-free guarantee backed by our return policy.
How to Source This Part
- Add to cart and complete checkout — we confirm stock and lead time within 1 business day.
- For volume orders (5+ units), contact support@konmask.com for a formal quotation with datasheet and test report.
- Urgent requirements? Call or WhatsApp +0086 19859288691 for same-day response.
- Export orders: we prepare commercial invoice, packing list, and COO documentation for customs clearance.
Application-Specific FAQ
Q: What is the difference between 6AG1124-0MC01-4AX0 and 6AV2124-0MC01-0AX0?
A: The 6AG1 prefix denotes the SIPLUS ruggedized variant with conformal coating and extended temperature range (-20 to +60 °C). The 6AV2 is the standard SIMATIC version rated 0 to +50 °C without conformal coating.
Q: Can this panel be programmed with TIA Portal V16 or later?
A: Yes. The TP1200 Comfort (SIPLUS and standard) is fully supported from TIA Portal V13 SP1 onwards, including V16, V17, and V18.
Q: Is ATEX certification included as standard?
A: ATEX Zone 2 is an option that must be specified at order. Please confirm your hazardous area classification when enquiring.
Q: Do you provide a warranty?
A: Yes — 12-month warranty against manufacturing defects. DOA units are replaced or refunded within 7 business days of confirmed fault report.
Q: Can you supply the matching PROFINET switch or cabinet accessories?
A: Yes. Contact us with your full BOM and we will source compatible Siemens components from the same verified supply chain.
