Industrial Drive Control Solution – SIEMENS 6SE7090-0XX84-1CJ0 | MASTERDRIVES Vector Control Unit
Where This Product Is Used
The SIEMENS 6SE7090-0XX84-1CJ0 is a dedicated Control Unit (CU) for the SIEMENS MASTERDRIVES MC/VC series frequency inverters. It is widely deployed across demanding industrial environments where precise motor speed and torque control are critical:
- Crane & Hoist Systems – Provides closed-loop vector control for safe, smooth load handling in overhead cranes, port gantry cranes, and hoisting equipment.
- Extruder & Injection Molding Machines – Delivers accurate torque regulation for plastics processing lines requiring consistent melt pressure and throughput.
- Paper & Printing Mills – Enables tension control and web speed synchronization across multi-drive winder/unwinder systems.
- Steel Rolling Mills – Supports high-dynamic torque response for rolling stands and coiler drives in hot and cold rolling applications.
- Conveyor & Material Handling – Manages coordinated multi-motor conveyor systems in mining, cement, and bulk material plants.
- Pump & Fan Drives – Optimizes energy consumption in large HVAC, water treatment, and process pump installations.
- Test Bench & Dynamometer Systems – Used in motor test rigs requiring four-quadrant operation and regenerative braking.
Technical Specifications
| Parameter | Value |
|---|---|
| Part Number (SKU) | 6SE7090-0XX84-1CJ0 |
| Product Series | SIEMENS MASTERDRIVES MC/VC |
| Module Type | Control Unit (CU) – Vector Control |
| Control Mode | Vector Control (VC) / Sensorless Vector / Closed-Loop Field-Oriented |
| Communication Interface | PROFIBUS-DP (integrated), Serial RS-232/RS-485 |
| Encoder Interface | Incremental encoder input (HTL/TTL) |
| Digital Inputs | Multiple programmable DI (24 V DC) |
| Digital Outputs | Multiple relay/transistor DO |
| Analog Inputs/Outputs | ±10 V / 0–20 mA configurable |
| Operating Temperature | 0 °C to +55 °C |
| Storage Temperature | -25 °C to +70 °C |
| Protection Class | IP20 |
| Weight | Approx. 8 kg |
| Compatible Power Units | SIEMENS MASTERDRIVES 6SE70xx Power Modules |
| Firmware | Upgradeable via SIMOVIS / DriveMonitor |
Why Engineers Specify This Model
- High-Dynamic Vector Control – Achieves fast torque response (<5 ms) without encoder in sensorless mode, reducing mechanical complexity.
- Four-Quadrant Capability – Supports motoring and regenerative braking in both directions, essential for crane and test bench applications.
- Integrated PROFIBUS-DP – Native fieldbus connectivity eliminates the need for additional communication boards, reducing panel space and cost.
- Modular Architecture – The CU separates from the power section, allowing independent replacement without disturbing power wiring — minimizing downtime.
- Proven MASTERDRIVES Platform – Backed by decades of SIEMENS drive engineering with extensive global service network and spare parts availability.
- Flexible Parameter Set – Over 900 programmable parameters via OP1S operator panel or PC tool (DriveMonitor/STARTER) for application-specific tuning.
Complete System Bill of Materials
For a fully operational MASTERDRIVES vector drive system, the following components are typically required:
- 6SE7090-0XX84-1CJ0 – Control Unit (this item)
- 6SE70xx-xxxxx-xxx0 – MASTERDRIVES Power Module (rated to motor kW)
- 6SE7090-0XX84-0KA0 – OP1S Operator Panel (optional, for local parameterization)
- 6SX7010-0AA00 – PC Connection Cable for DriveMonitor
- 6SE7090-0XX84-0FF5 – PROFIBUS-DP Termination Plug (if end node)
- Incremental Encoder (HTL, 1024 PPR recommended for closed-loop)
- 24 V DC Control Power Supply (SITOP or equivalent)
- Input Line Reactor / EMC Filter (application-dependent)
Compliance & Industry Standards
- CE Marked – Compliant with EU Low Voltage Directive (2014/35/EU) and EMC Directive (2014/30/EU)
- UL Listed – Suitable for North American installations
- IEC 61800-5-1 – Adjustable speed electrical power drive systems safety requirements
- IEC 61800-3 – EMC requirements for drive systems
- PROFIBUS-DP – IEC 61158 / EN 50170 compliant fieldbus
- RoHS Compliant
Quality Assurance & Sourcing
At Konmask.com, every SIEMENS 6SE7090-0XX84-1CJ0 unit is subject to our multi-point quality process:
- Authenticity Verification – Units are cross-checked against SIEMENS serial number databases and holographic labels inspected.
- Functional Pre-Test – Power-on and communication interface tests performed prior to shipment where applicable.
- Condition Grading – Clearly stated as New, Refurbished-Grade A, or Surplus Stock. Contact us for current stock condition.
- Secure Packaging – Anti-static ESD bags, foam-lined cartons, and moisture-barrier packaging for international freight.
- Traceability – Full documentation including test records and packing list provided with each shipment.
How to Source This Part
- Add to Cart – Click “Add to Cart” above and proceed to checkout for standard online ordering.
- Request a Quote – For bulk orders (>3 units), OEM projects, or urgent requirements, email support@konmask.com for a dedicated quotation within 24 hours.
- Lead Time – In-stock units ship within 1–3 business days. Ex-stock international delivery via DHL/FedEx typically 5–10 business days.
- Payment – T/T Bank Transfer, PayPal, and major credit cards accepted. LC available for orders above USD 10,000.
- Export Compliance – We handle export documentation, commercial invoices, and customs HS code classification for smooth cross-border clearance.
Application-Specific FAQ
Q: Can the 6SE7090-0XX84-1CJ0 be used without an encoder (sensorless)?
A: Yes. The CU supports sensorless vector control (open-loop VC) for applications where encoder installation is impractical. For high-precision positioning or crane applications, closed-loop mode with an HTL encoder is recommended.
Q: Is this CU compatible with all MASTERDRIVES power modules?
A: The 6SE7090-0XX84-1CJ0 is designed for the MASTERDRIVES MC/VC platform. Compatibility depends on the power module frame size and firmware version. Please provide your power module part number when inquiring to confirm compatibility.
Q: Can I upgrade the firmware on this control unit?
A: Yes. Firmware can be updated via the SIEMENS DriveMonitor or SIMOVIS software using the RS-232 serial interface. Ensure the firmware version is compatible with your power module before upgrading.
Q: What is the difference between the 1CJ0 and other CU variants (e.g., 1CA0, 1CB0)?
A: The suffix designates the communication and encoder option board configuration. The 1CJ0 variant includes integrated PROFIBUS-DP. Contact us to confirm the exact option board fitted if your application requires a specific configuration.
Q: Do you provide a warranty?
A: Yes. All units sold by Konmask.com carry a minimum 90-day functional warranty. Extended warranty options are available — contact us for details.
