SIEMENS 6SL3040-0JA02-0AA0 – SINAMICS S110 CU305 PN Control Unit | Precision Servo Drive Controller
Engineering Background
The SIEMENS 6SL3040-0JA02-0AA0 is the CU305 PN Control Unit for the SINAMICS S110 single-axis servo drive platform — Siemens’ dedicated solution for high-precision positioning tasks in machine tool, packaging, and handling automation. Designed to operate seamlessly within the SINAMICS S110 drive system, this control unit integrates PROFINET IO communication, enabling deterministic real-time control over servo axes in demanding industrial environments.
Product Positioning
Targeted at OEM machine builders and system integrators who require a compact, high-performance servo controller with native SIMATIC S7 / TIA Portal integration. The CU305 PN is the preferred choice when PROFINET-based motion control, Safety Integrated functions, and single-axis positioning accuracy are non-negotiable requirements.
Complete Technical Specifications
- Part Number (SKU): 6SL3040-0JA02-0AA0
- Product Family: SINAMICS S110
- Control Unit Type: CU305 PN (PROFINET)
- Communication Interface: PROFINET IO (IRT / RT), 2-port integrated switch
- Drive Object: Single-axis servo / vector control
- Encoder Interface: HTL/TTL incremental, SSI absolute, EnDat 2.1/2.2, DRIVE-CLiQ
- Digital Inputs: 8 × DI (24 V DC)
- Digital Outputs: 4 × DO (24 V DC, 100 mA)
- Analog Inputs: 2 × AI (±10 V / 0–20 mA)
- Safety Functions: STO (Safe Torque Off) via terminals — SIL 2 / PLe Cat. 3
- Supply Voltage: 24 V DC (via Power Module)
- Ambient Temperature (Operation): 0 °C to +55 °C
- Storage Temperature: −40 °C to +70 °C
- Protection Degree: IP20
- Dimensions (W × H × D): 73 mm × 270 mm × 220 mm (approx.)
- Weight: Approx. 2.2 kg
- Firmware: Compatible with STARTER / TIA Portal Startdrive
- Certifications: CE, UL, cUL, RoHS
- Country of Origin: Germany
Proven Application Environments
- CNC & Machine Tools: Single-axis feed drives requiring sub-millimeter positioning accuracy
- Packaging Machinery: High-speed pick-and-place, form-fill-seal lines with PROFINET synchronization
- Handling & Robotics: Gantry systems, linear actuators, and rotary indexing tables
- Printing & Converting: Register control and tension regulation on web-fed machines
- Textile & Winding: Precision torque and speed control for winding applications
- Semiconductor & Electronics Assembly: Ultra-precise positioning stages requiring SIL 2 safety compliance
Engineering Advantages
- Native PROFINET IRT: Isochronous Real-Time communication ensures cycle-accurate axis synchronization with SIMATIC S7-300/400/1500 controllers
- Integrated Safety (STO): Eliminates external safety relays; SIL 2 / PLe Cat. 3 certified directly on the control unit
- DRIVE-CLiQ Ready: Plug-and-play encoder and motor identification via DRIVE-CLiQ topology — reduces commissioning time significantly
- TIA Portal / Startdrive Integration: Full parameterization, diagnostics, and trace functions within the unified Siemens engineering framework
- Compact Form Factor: Booksize mounting compatible with SINAMICS S110 Power Modules (PM340 series)
- Scalable Safety: Upgradeable to extended Safety Integrated functions (SS1, SLS, SDI) via license
System Architecture & Signal Flow
The 6SL3040-0JA02-0AA0 CU305 PN sits at the top of the SINAMICS S110 drive train. The PLC (SIMATIC S7 / S7-1500) communicates via PROFINET to the CU305 PN, which processes motion setpoints and transmits torque/speed commands to the connected Power Module (PM340) via the internal drive bus. Encoder feedback is returned through DRIVE-CLiQ or conventional encoder interfaces, closing the position loop at the control unit level. Safety signals (STO) are hardwired directly to the CU305 PN terminal strip, ensuring fail-safe operation independent of the fieldbus.
Sourcing & Quality Verification
- Origin: Genuine Siemens product — sourced from authorized distribution channels and verified OEM supply chains
- Inspection: Each unit undergoes visual inspection, label verification, and functional pre-check before dispatch
- Packaging: Ships in original or equivalent ESD-safe protective packaging
- Documentation: CE Declaration of Conformity and product datasheet available upon request
- Warranty: 12-month warranty against manufacturing defects; DOA replacement policy
Procurement Process
- Inquiry: Submit your RFQ with required quantity and delivery timeline via the product page or email support@konmask.com
- Quotation: Receive a formal quotation with lead time, pricing, and shipping options within 1 business day
- Order Confirmation: Place order via the Konmask.com checkout or via purchase order (B2B accounts)
- Dispatch: Orders are dispatched within 2–5 business days; express options available
- After-Sales: Technical support available post-delivery for commissioning assistance
Technical FAQ
Q: Is the 6SL3040-0JA02-0AA0 compatible with SIMATIC S7-1500 via PROFINET?
A: Yes. The CU305 PN supports PROFINET IO RT and IRT, fully compatible with S7-300, S7-400, and S7-1500 controllers using standard GSD/GSDML device files.
Q: Which Power Modules are compatible with this Control Unit?
A: The CU305 PN is designed for use with SINAMICS S110 PM340 Power Modules (booksize format). Refer to the SINAMICS S110 system manual for the complete compatibility matrix.
Q: Can STO be used without a safety PLC?
A: Yes. STO via terminals operates independently of the fieldbus and can be triggered by a hardwired safety circuit (e.g., emergency stop relay), meeting SIL 2 / PLe Cat. 3 requirements without a safety-rated PLC.
Q: What software is required for commissioning?
A: Siemens STARTER (standalone) or TIA Portal with the Startdrive add-on. Both support full parameterization, auto-tuning, and online diagnostics for the CU305 PN.
Q: Is this a new or refurbished unit?
A: Konmask.com supplies both new OEM stock and professionally refurbished units. Product condition is clearly stated on the listing. Contact us to confirm availability of new stock.
