Siemens 6SL3100-1CE14-0AA0 SINAMICS S120 Capacitor Module | Replacement, Equivalent & Selection Guide
The Siemens 6SL3100-1CE14-0AA0 is a DC link Capacitor Module designed for the SINAMICS S120 drive system. It extends the DC bus capacitance to improve ride-through capability during brief power interruptions and reduce voltage ripple in multi-axis drive configurations. Sourced and verified by Konmask.com — your trusted industrial automation partner.
Technical Specifications
- Part Number: 6SL3100-1CE14-0AA0
- Brand: Siemens
- Series: SINAMICS S120
- Type: Capacitor Module (DC Link Extension)
- Rated Power: 4 kW equivalent DC link support
- DC Bus Voltage: Up to 600 V DC
- Capacitance: Extended DC link capacitance for multi-axis systems
- Degree of Protection: IP20
- Cooling: Internal air cooling
- Weight: approx. 8.2 kg
- Country of Origin: Germany
- HS Code: 850440
Compatible Replacement & Equivalent Models
The following models are functionally compatible or serve as direct/near-direct replacements for the 6SL3100-1CE14-0AA0 in SINAMICS S120 systems. Always verify electrical ratings and firmware compatibility before substitution.
- 6SL3100-1CE21-0AA0 – Higher capacitance variant, same S120 booksize form factor
- 6SL3100-1CE28-0AA0 – Extended capacitance for larger multi-axis configurations
- 6SL3100-1CE31-0AA0 – High-capacity DC link module for demanding applications
- 6SL3100-1BE25-0AA0 – Braking Module alternative for energy dissipation scenarios
- Third-party DC link capacitor modules rated for 600 V DC / SINAMICS S120 booksize chassis (consult Konmask for compatibility verification)
Why Choose the Original Model
- ✅ OEM-certified for SINAMICS S120 booksize drive systems
- ✅ Plug-and-play integration — no firmware modification required
- ✅ Guaranteed DC bus compatibility with Siemens Line Modules and Motor Modules
- ✅ Full Siemens warranty and lifecycle support
- ✅ Traceable manufacturing from Siemens Germany production facilities
Typical Applications
- CNC machine tool drive systems (multi-axis configurations)
- Packaging and printing machinery with frequent start/stop cycles
- Conveyor and material handling systems requiring ride-through capability
- Robotics and servo drive arrays on shared DC bus
- Textile and winding machines with regenerative braking
System Compatibility
- Drive System: Siemens SINAMICS S120 (Booksize format)
- Compatible Line Modules: Active Line Module (ALM), Smart Line Module (SLM), Basic Line Module (BLM)
- Compatible Motor Modules: Single-axis and double-axis booksize Motor Modules
- Control Units: CU320-2 DP, CU320-2 PN and compatible S120 CUs
- Not compatible with: SINAMICS S120 chassis format or SINAMICS G120 series
Selection Guide
Use the following criteria to select the correct capacitor module for your SINAMICS S120 system:
- Step 1 – Determine DC bus voltage: Confirm your system operates at ≤600 V DC (standard European 3-phase supply).
- Step 2 – Calculate required capacitance: Sum the motor module capacitance requirements; select a module that bridges the gap to your ride-through target.
- Step 3 – Verify booksize format: 6SL3100-1CE14-0AA0 is booksize only — confirm your Line Module and Motor Modules are also booksize.
- Step 4 – Check available DIN rail / cabinet space: Module width is fixed; plan cabinet layout accordingly.
- Step 5 – Confirm firmware version: Ensure SINAMICS S120 firmware supports the capacitor module (V4.x and above recommended).
📩 Not sure which module fits your system? Contact our engineers for a free selection consultation.
Quality Assurance & Sourcing
- All units sourced from authorized Siemens distribution channels or verified surplus with full traceability
- Pre-shipment inspection: visual check, label verification, and functional test where applicable
- Anti-static packaging with humidity indicators for safe international shipping
- Certificate of conformity available upon request
- Counterfeit-free guarantee — Konmask.com maintains a strict supplier qualification process
How to Order
- Add 6SL3100-1CE14-0AA0 to your cart and proceed to checkout, or
- Email support@konmask.com with your quantity and delivery requirements
- For bulk orders (>5 units) or project-based procurement, request a formal quotation
- Lead time: in-stock units ship within 1–3 business days; ex-stock orders subject to availability
- International shipping available — DHL, FedEx, UPS with full customs documentation
Replacement & Compatibility FAQ
Q: Can I use 6SL3100-1CE21-0AA0 as a direct replacement for 6SL3100-1CE14-0AA0?
A: Yes, in most cases. The -1CE21 offers higher capacitance and is physically compatible with the same booksize slot. Verify your system’s total DC bus capacitance budget does not exceed Line Module limits.
Q: Is this module compatible with SINAMICS S120 chassis format?
A: No. The 6SL3100-1CE14-0AA0 is designed exclusively for the booksize format. Chassis-format systems require different capacitor modules.
Q: Can third-party capacitor modules replace this unit?
A: Third-party alternatives exist but may not support DRIVE-CLiQ communication or Siemens diagnostics. Contact Konmask for vetted alternatives.
Q: What is the typical service life of this capacitor module?
A: Electrolytic capacitors typically have a service life of 5–8 years depending on operating temperature and duty cycle. Siemens recommends periodic capacitance testing.
Q: Do you provide warranty on used or refurbished units?
A: Yes — Konmask offers a 90-day functional warranty on all tested surplus units, and full OEM warranty on new stock.
