Siemens 6SX7010-0KC00 – Terminal Extension Board | MASTERDRIVES Drive System
Engineering Background: The Siemens 6SX7010-0KC00 is a factory-engineered Terminal Extension Board designed for integration within the SIEMENS MASTERDRIVES drive platform. It extends the I/O terminal capacity of the drive controller, enabling engineers to connect additional control signals, feedback loops, and field-level wiring without external relay panels or signal converters.
Product Positioning: Targeted at OEM machine builders, system integrators, and MRO procurement teams operating MASTERDRIVES MC/VC/FC series drives in continuous-process and discrete-manufacturing environments. The 6SX7010-0KC00 is a direct Siemens OEM component — not a third-party substitute — ensuring full compatibility with existing drive firmware and hardware revisions.
Complete Technical Specifications
- Part Number (SKU): 6SX7010-0KC00
- Manufacturer: Siemens AG
- Product Family: MASTERDRIVES Drive System
- Component Type: Terminal Extension Board
- Function: Expands terminal I/O capacity for drive control wiring
- Country of Origin: Germany
- Weight: 740 g
- Compatibility: SIEMENS MASTERDRIVES MC / VC / FC series
- Mounting: Internal drive chassis / DIN rail (per drive enclosure design)
- Condition: New / Refurbished (specify at inquiry)
Proven Application Environments
- Continuous process industries: paper mills, cement plants, steel rolling lines
- Discrete manufacturing: CNC machining centers, conveyor systems, hoisting equipment
- Water & wastewater treatment pump drive systems
- HVAC and building automation variable-speed drive panels
- Marine and offshore drive control cabinets
- MRO replacement for aging MASTERDRIVES installations
Engineering Advantages
- OEM Genuine Part: Manufactured by Siemens AG — full firmware and hardware compatibility guaranteed
- Expanded I/O: Eliminates the need for external terminal multiplexers or relay expansion modules
- Plug-and-Play Integration: Designed for direct installation within the MASTERDRIVES chassis — no custom wiring adapters required
- Reduced Downtime: Drop-in replacement for failed or degraded terminal boards — minimizes production interruption
- Long Service Life: Industrial-grade PCB construction rated for harsh electrical environments
System Architecture & Signal Flow
The 6SX7010-0KC00 Terminal Extension Board interfaces directly with the MASTERDRIVES control board backplane. It routes analog and digital I/O signals from field devices (sensors, encoders, PLC outputs) to the drive’s internal control logic. The board supports standard terminal screw connections, enabling straightforward field wiring by maintenance engineers without specialized tooling.
Signal flow: Field Device → Terminal Extension Board (6SX7010-0KC00) → MASTERDRIVES Control Board → Drive Power Stage → Motor
Sourcing & Quality Verification
- All units sourced through verified Siemens authorized distribution channels or certified industrial surplus with full traceability
- Pre-shipment inspection: visual, dimensional, and functional verification
- Counterfeit-prevention: part markings, date codes, and PCB silkscreen verified against Siemens OEM references
- Packaging: anti-static ESD bag + foam-lined carton for safe international transit
- Documentation available: Siemens datasheet, test report, certificate of conformity (on request)
Procurement Process
- Confirm Compatibility: Verify your MASTERDRIVES drive model and firmware version against the 6SX7010-0KC00 compatibility matrix
- Request Quote: Contact support@konmask.com with your PO requirements, quantity, and delivery timeline
- Order Confirmation: Receive proforma invoice with lead time and shipping options (DHL Express / sea freight)
- Quality Inspection: Unit inspected and documented before dispatch
- Delivery & Support: Tracking provided; post-delivery technical support available
Technical FAQ
Q: Is the 6SX7010-0KC00 compatible with all MASTERDRIVES variants?
A: It is designed for the MASTERDRIVES platform. Confirm your specific drive model (MC/VC/FC) and hardware revision with our technical team before ordering.
Q: Can this board be used as a direct replacement for a failed unit?
A: Yes. It is a drop-in OEM replacement. No firmware changes are required in most standard configurations.
Q: Do you provide a warranty?
A: Yes. We offer a 90-day functional warranty on all verified units. Extended warranty available on request.
Q: What is the typical lead time?
A: In-stock units ship within 1–3 business days. Out-of-stock items: 2–4 weeks sourcing lead time.
Q: Can you provide Siemens documentation?
A: Yes. Siemens product datasheets and installation manuals are available upon request.
