Industrial Ethernet Solution — SIEMENS 6GK5208-0BA10-2AA3 | SCALANCE X200 Series
Where This Product Is Used
The SIEMENS 6GK5208-0BA10-2AA3 is an 8-port unmanaged Industrial Ethernet switch from the SCALANCE X200 series, purpose-built for demanding factory-floor and process-automation environments. Engineers specify this switch across a wide range of industrial applications:
- Automotive Manufacturing Lines — Connecting PLCs, HMIs, and robot controllers on PROFINET-based production cells where deterministic communication is critical.
- Machine Tool & CNC Networks — Providing reliable star or line topology Ethernet segments for CNC controllers, servo drives, and I/O modules.
- Water & Wastewater Treatment Plants — Deployed in control cabinets for SCADA-connected pump stations, valve actuators, and remote I/O in harsh, humid environments.
- Power Distribution & Substations — Used in IEC 61850-compliant substation automation networks linking protection relays and bay controllers.
- Food & Beverage Processing — Installed in washdown-adjacent control panels where IP30 protection and DIN-rail mounting simplify integration.
- Building Automation & HVAC — Connecting BACnet/IP devices, variable-frequency drives, and energy meters in intelligent building management systems.
- Oil & Gas Field Instrumentation — Linking remote terminal units (RTUs) and flow computers in upstream and midstream control architectures.
Technical Specifications
| Parameter | Value |
|---|---|
| Part Number | 6GK5208-0BA10-2AA3 |
| Series | SCALANCE X200 (Unmanaged) |
| Ports | 8 × RJ45, 10/100 Mbps, Auto-MDI/MDIX |
| Switching Method | Store-and-Forward |
| Transmission Rate | 10 / 100 Mbps (auto-negotiation) |
| Supply Voltage | 24 V DC (18–32 V DC) |
| Power Consumption | Max. 3.5 W |
| Operating Temperature | −10 °C to +60 °C |
| Storage Temperature | −40 °C to +85 °C |
| Degree of Protection | IP30 |
| Mounting | DIN rail (35 mm) / S7-300 rail |
| Dimensions (W×H×D) | 60 × 125 × 75 mm |
| Weight | Approx. 560 g |
| MTBF | > 500,000 hours |
| Diagnostics | LED per port (Link/Activity), Power LED |
Why Engineers Specify This Model
- Zero Configuration Required — Plug-and-play operation eliminates commissioning time on the factory floor; no IP address or management interface needed.
- PROFINET-Ready — Fully compatible with SIMATIC S7 PLCs and PROFINET IO devices, ensuring seamless integration into existing Siemens automation architectures.
- Industrial-Grade Reliability — Conformal-coated PCB, wide temperature range, and vibration/shock resistance per IEC 60068 make it suitable for continuous 24/7 operation.
- Compact DIN-Rail Form Factor — 60 mm width fits neatly in standard control cabinets alongside SIMATIC power supplies and I/O modules.
- Redundant Power Input — Dual 24 V DC inputs with fault signaling relay prevent single-point power failure from taking down the network segment.
- Long Product Lifecycle — Siemens SCALANCE X200 series is supported with long-term availability commitments, reducing obsolescence risk for OEMs and system integrators.
Complete System Bill of Materials
For a complete PROFINET control cabinet network segment, engineers typically pair the 6GK5208-0BA10-2AA3 with the following components:
- SIMATIC S7-1200 / S7-1500 PLC (e.g., 6ES7214-1AG40-0XB0)
- SITOP PSU100S 24 V / 5 A Power Supply (6EP1333-2BA20)
- SIMATIC ET 200SP Distributed I/O (6ES7155-6AU01-0BN0)
- Industrial Ethernet Cable IE FC TP Standard Cable GP 2×2 (6XV1840-2AH10)
- IE FC RJ45 Plug 180 (6GK1901-1BB10-2AA0)
- SCALANCE XB005 Media Converter (if fiber uplink required)
Compliance & Industry Standards
- CE Marking — EU Low Voltage Directive & EMC Directive
- UL 508 — Industrial Control Equipment (cULus listed)
- IEC 61000-6-2 / IEC 61000-6-4 — Industrial EMC Immunity & Emission
- IEC 60068-2-6 / -2-27 — Vibration & Shock Resistance
- PROFINET Conformance Class A
- IEEE 802.3 / 802.3u — 10BASE-T / 100BASE-TX
- RoHS Compliant
Quality Assurance & Sourcing
At Konmask.com, every SIEMENS SCALANCE module is sourced through verified industrial distribution channels. Each unit undergoes the following before dispatch:
- Visual inspection for label authenticity and hologram verification
- Power-on functional test confirming all port LEDs and relay outputs
- Original factory packaging retained where available
- Batch traceability records maintained for warranty and audit purposes
We do not supply grey-market, refurbished, or counterfeit components. All products carry the original Siemens manufacturer warranty where applicable.
How to Source This Part
- Add to Cart — Click the purchase button above to place an order directly.
- Request a Quote — For quantities ≥ 5 units or project BOM pricing, email support@konmask.com with your project details.
- Lead Time — In-stock units ship within 1–3 business days. Ex-stock orders from our supplier network typically ship within 5–10 business days.
- Export & Cross-Border Orders — We support international shipments with full commercial invoice and packing list documentation for customs clearance.
Application-Specific FAQ
Q: Is the 6GK5208-0BA10-2AA3 compatible with PROFINET IO?
A: Yes. As an unmanaged switch it is transparent to PROFINET IO communication and fully compatible with SIMATIC S7 controllers and ET 200 distributed I/O.
Q: Can this switch be used in a ring topology for redundancy?
A: No. Ring redundancy (MRP/HRP) requires a managed switch such as the SCALANCE X208 (6GK5208-0BA10-2AA3 is unmanaged). For ring topologies, consider the SCALANCE XC208 or XR324 series.
Q: What is the maximum cable length per port?
A: Up to 100 m per segment using Cat 5e or better shielded twisted-pair (STP) cable per IEEE 802.3u specification.
Q: Does it support PoE (Power over Ethernet)?
A: No. This model does not support PoE. For PoE requirements, refer to the SCALANCE XP208 series.
Q: What DIN rail standard does it mount on?
A: Standard 35 mm DIN rail (EN 60715) and SIMATIC S7-300 mounting rail.
Q: Is a configuration software required?
A: No software or configuration is required. The switch operates fully plug-and-play out of the box.
