Industrial Automation Solution – SIGMATEK 01-450-031 256MB LX800 CPU Module | DIAS Series
Where This Product Is Used
The SIGMATEK 01-450-031 is a high-performance CPU module built on the AMD Geode LX800 processor with 256MB of onboard RAM, designed for demanding real-time control applications within the SIGMATEK DIAS (Distributed Industrial Automation System) platform. It is widely deployed in:
- Packaging Machinery – Multi-axis synchronization for form-fill-seal, cartoning, and labeling lines
- Printing & Converting Equipment – High-speed register control and tension management
- Plastics & Injection Molding – Precise cycle-time control and mold-protection logic
- Textile & Winding Machines – Coordinated drive control across multiple spindles
- Robotics & Handling Systems – Real-time kinematics and interpolation tasks
- Special-Purpose Machines (SPM) – Custom OEM automation requiring deterministic scan times
Technical Specifications
| Parameter | Value |
|---|---|
| Part Number | 01-450-031 |
| Manufacturer | SIGMATEK GmbH & Co KG |
| Series | DIAS (Distributed Industrial Automation System) |
| Processor | AMD Geode LX800 (500 MHz) |
| RAM | 256 MB DDR SDRAM |
| Module Type | CPU / Controller Module |
| Operating System | SIGMATEK LASAL (real-time OS) |
| Programming Environment | LASAL Class / IEC 61131-3 compatible |
| Communication | DIAS-Bus, Ethernet (onboard) |
| Operating Temperature | 0 °C to +55 °C |
| Storage Temperature | -25 °C to +70 °C |
| Supply Voltage | 24 V DC (via backplane) |
| Weight | Approx. 300 g |
| Form Factor | DIAS rack-mount module |
Why Engineers Specify This Model
- Deterministic Real-Time Performance – The LX800 core running SIGMATEK’s LASAL OS delivers sub-millisecond cycle times critical for motion-synchronized applications.
- 256MB RAM Headroom – Supports complex multi-axis programs, large data tables, and recipe management without memory bottlenecks.
- Seamless DIAS Ecosystem Integration – Drop-in compatible with SIGMATEK I/O, drive, and safety modules; no gateway or protocol conversion required.
- Proven OEM Track Record – Widely adopted by European machine builders in packaging, printing, and converting sectors since its introduction.
- Compact Rack Architecture – Modular backplane design minimizes cabinet footprint while maximizing I/O scalability.
Complete System Bill of Materials
The 01-450-031 CPU module is typically paired with the following SIGMATEK DIAS components to build a complete control system:
- DIAS Power Supply Module – 24 V DC rack power (e.g., 01-100-xxx series)
- DIAS Digital I/O Modules – DI/DO expansion (e.g., 01-200-xxx / 01-210-xxx)
- DIAS Analog I/O Modules – AI/AO for process signals (e.g., 01-220-xxx)
- DIAS Drive Interface Modules – Servo/stepper axis cards (e.g., 01-300-xxx)
- DIAS Safety Modules – SIL-rated safety I/O (e.g., 01-400-xxx)
- DIAS Backplane / Rack – 4, 8, or 16-slot chassis
- LASAL Development Software – Engineering workstation license
Contact support@konmask.com for complete BOM sourcing assistance.
Compliance & Industry Standards
- CE Marked – EMC Directive 2014/30/EU & Low Voltage Directive 2014/35/EU
- IEC 61131-3 Programming Standard Compatible
- UL/cUL Listed (verify current certification status with manufacturer)
- RoHS Compliant
- Designed for use in Pollution Degree 2 industrial environments
Quality Assurance & Sourcing
At Konmask.com, every SIGMATEK module is:
- Sourced from authorized distributors or verified surplus channels with full traceability
- Inspected for physical integrity, label authenticity, and firmware version prior to dispatch
- Shipped in anti-static ESD packaging with protective foam inserts
- Backed by our 90-day functional warranty on all tested units
- Supported by our technical team for pre-sale compatibility verification
How to Source This Part
- Add to Cart – Place your order directly on this page for in-stock units.
- Request a Quote – Email support@konmask.com for volume pricing, lead time, or alternative part numbers.
- WhatsApp / Phone – Reach our sourcing team at +0086 19859288691 for urgent requirements.
- Provide Your BOM – Send your full parts list and we will cross-reference availability across our supplier network.
Application-Specific FAQ
Q: Is the 01-450-031 compatible with newer SIGMATEK DIAS racks?
A: Yes. The module uses the standard DIAS backplane bus and is backward/forward compatible with most DIAS rack generations. Confirm firmware version compatibility with your LASAL software version.
Q: Can this CPU module run multi-axis motion control?
A: Yes. With 256MB RAM and the LX800 processor, it supports multi-axis interpolation via SIGMATEK drive interface modules. Axis count depends on cycle time requirements and I/O configuration.
Q: What programming software is required?
A: SIGMATEK LASAL Class software (Windows-based). IEC 61131-3 structured text and function block diagram are supported.
Q: Do you offer exchange or repair services?
A: Yes. Contact us at support@konmask.com to discuss repair, exchange, or refurbished unit options.
Q: What is the lead time for out-of-stock units?
A: Typically 2–8 weeks depending on global surplus availability. Submit an RFQ and we will provide a firm lead time within 24 hours.
