Tokyo Electron TTLM10-11 ELVIF-F / TTLD14-12 WCIF-L / TTLM11-11 W/TIF-L PCB Board | TEL Semiconductor Equipment Platform
Engineering Background
Tokyo Electron Limited (TEL) is one of the world’s leading semiconductor equipment manufacturers, supplying critical process modules to fabs operating at 28nm and below. The TTLM and TTLD series PCB boards serve as core control and interface logic cards within TEL’s etch, CVD, and thermal processing platforms. These boards govern signal routing, interlock logic, and subsystem communication across the equipment chassis.
Product Positioning
This listing covers a verified set of three TEL PCB modules — TTLM10-11 ELVIF-F (P/N 3895-120321-21), TTLD14-12 WCIF-L (P/N 3881-020032-11), and TTLM11-11 W/TIF-L (P/N 3895-120322-21) — sourced from decommissioned TEL equipment. Ideal for maintenance engineers requiring direct board-level replacements without full system downtime.
Complete Technical Specifications
- Module 1: TTLM10-11 ELVIF-F | Part No. 3895-120321-21
- Module 2: TTLD14-12 WCIF-L | Part No. 3881-020032-11
- Module 3: TTLM11-11 W/TIF-L | Part No. 3895-120322-21
- Manufacturer: Tokyo Electron Limited (TEL)
- Country of Origin: Japan
- Board Type: Printed Circuit Board (PCB) — Control / Interface Logic
- HS Code: 853710
- Weight: 1,450 g (combined set)
- Condition: Used / Surplus — Pulled from operational TEL equipment
- Compatibility: TEL semiconductor processing platforms (etch / CVD / thermal series)
Proven Application Environments
- Semiconductor wafer etch and deposition equipment (TEL Trias, Tactras, Alpha-8SE platforms)
- Front-end-of-line (FEOL) process tool maintenance and board-level repair
- Fab spare parts inventory for 200mm and 300mm wafer processing lines
- OEM equipment refurbishment and resale operations
- University and R&D lab equipment restoration projects
Engineering Advantages
- OEM Authenticity: Genuine TEL boards with original part numbers — no third-party clones or re-labeled substitutes
- Direct Drop-In Replacement: Maintains original connector pinout, firmware compatibility, and interlock logic
- Reduced Downtime: Board-level swap eliminates the need for full module or chassis replacement
- Traceable Part Numbers: All three P/Ns cross-reference to TEL’s internal BOM documentation
- Tested Surplus Stock: Pulled from functioning equipment; visual and functional inspection completed prior to listing
System Architecture & Signal Flow
Within a TEL process tool, the TTLM-series boards (TTLM10-11, TTLM11-11) function as interface logic modules managing TTL-level signal conditioning between the main controller and peripheral subsystems. The TTLD14-12 WCIF-L board handles wafer carrier interface (WCIF) communication, coordinating FOUP/SMIF pod handshaking and wafer transfer sequencing. Together, these three boards form a tightly coupled control sub-assembly responsible for equipment-level interlock management and process recipe execution signaling.
Sourcing & Quality Verification
- All boards sourced directly from decommissioned TEL equipment at certified semiconductor facilities
- Visual inspection: no burnt components, cracked traces, or physical damage
- Part numbers verified against TEL documentation and cross-referenced with known BOM databases
- Stored in ESD-safe packaging; shipped with anti-static protection and foam cushioning
- Certificate of conformance available upon request for qualified buyers
Procurement Process
- Step 1: Confirm compatibility with your TEL platform model and existing board revision
- Step 2: Contact Konmask for stock availability confirmation and lead time: [email protected]
- Step 3: Submit purchase order — we accept T/T wire transfer, PayPal, and trade terms for qualified accounts
- Step 4: Boards shipped within 2–5 business days via DHL / FedEx with full tracking and export documentation
- Step 5: Post-delivery technical support available for installation guidance
Technical FAQ
Q: Are these boards tested before shipment?
A: All boards undergo visual inspection and basic functional verification. Full load testing under live equipment conditions is available for an additional fee — contact us for details.
Q: Can these boards be used interchangeably across different TEL tool generations?
A: No. TEL PCB boards are platform-specific. Always verify the exact part number and revision against your equipment’s BOM before ordering.
Q: Do you offer a warranty?
A: We offer a 90-day DOA (Dead on Arrival) warranty. Boards confirmed defective upon receipt will be replaced or refunded. Warranty does not cover damage from improper installation.
Q: Can you source other TEL part numbers not listed here?
A: Yes. Konmask maintains an extensive network of TEL surplus inventory. Contact us with your required P/N and quantity.
Q: What export documentation is provided?
A: Commercial invoice, packing list, and HS code declaration (853710) are standard. ECCN classification and end-user certificates available upon request.
