Genuine VAT PM-6 Pressure Controller 810-49867 | 650PM-24CG-ADK3/0431 – Verified Source
Konmask.com supplies genuine VAT PM-6 Series Pressure Controllers to procurement engineers and MRO teams worldwide. Part number 810-49867, configuration 650PM-24CG-ADK3/0431 — sourced through verified channels with full traceability documentation available upon request.
VAT Group AG is the global leader in high-performance vacuum valves and pressure control systems, serving semiconductor fabs, flat-panel display manufacturers, solar cell producers, and advanced research facilities. The PM-6 platform represents VAT’s precision pressure management solution for process-critical vacuum environments.
Technical Specifications
| Manufacturer | VAT Group AG (Switzerland) |
| Product Series | PM-6 Pressure Controller |
| Part Number | 810-49867 |
| Configuration Code | 650PM-24CG-ADK3/0431 |
| SKU | PM-6 810-49867 650PM-24CG-ADK3/0431 |
| Control Type | Pressure / Flow Control |
| Drive Voltage | 24 VDC (per configuration code -24CG-) |
| Interface | Analog + Digital (per ADK3 designation) |
| Approx. Weight | 100 g (controller module) |
| Condition | New / Refurbished / Surplus (specify at inquiry) |
| Origin | Switzerland / EU |
| Compliance | CE, RoHS (VAT factory standard) |
Note: Full datasheet and configuration breakdown available upon request. Contact [email protected] with your application requirements.
Our 4-Step Quality Verification Process
Every VAT component shipped from Konmask.com passes through a structured verification workflow before dispatch:
- Step 1 — Source Verification: All units are procured exclusively from authorized distributors, OEM surplus channels, or factory-direct pipelines. No grey-market or unverified broker stock.
- Step 2 — Physical Inspection: Each unit undergoes visual inspection for label integrity, housing condition, connector pin status, and serial number legibility. Counterfeit indicators are cross-checked against VAT’s published authentication markers.
- Step 3 — Functional Screening: Where applicable, units are bench-tested for basic electrical continuity and interface response prior to packaging.
- Step 4 — Documentation Package: Shipment includes packing list, country of origin declaration, and optional test report. COC (Certificate of Conformance) available on request for qualified B2B buyers.
Key Features & Benefits
- Precision pressure regulation optimized for high-vacuum and ultra-high-vacuum (UHV) process environments
- 24 VDC drive — compatible with standard PLC and DCS 24V I/O power rails
- ADK3 interface supports both analog setpoint control and digital communication for process integration flexibility
- Compact controller module design — minimal footprint for retrofit and OEM integration
- VAT’s proven PM-series reliability: widely deployed in semiconductor CVD, PVD, etch, and ion implant chambers
- Fast response time for dynamic pressure stabilization in load-lock and transfer chamber applications
- Sourced with full part number traceability — no ambiguous substitutions
Typical Applications
- Semiconductor wafer processing: CVD, PVD, ALD, dry etch chambers
- Flat-panel display (FPD) and OLED manufacturing lines
- Solar cell deposition systems
- Ion implantation and e-beam lithography equipment
- Research accelerators and synchrotron beamline vacuum systems
- Industrial vacuum furnaces and heat treatment systems
- Leak detection and mass spectrometry instrumentation
Compatible System Components
The VAT PM-6 Pressure Controller is designed to integrate with the following VAT and third-party system elements:
- VAT Pendulum / Butterfly Valves: Series 64, 65, 650 — direct drive compatibility
- VAT Gate Valves: Series 01, 02, 10, 48 — for upstream/downstream isolation
- Pressure Sensors: MKS Baratron, Pfeiffer CMR, Edwards APG — analog 0–10V or 4–20mA input
- Host Controllers: Siemens S7, Allen-Bradley ControlLogix, Mitsubishi MELSEC — via analog I/O or fieldbus adapter
- Vacuum Pumps: Edwards, Pfeiffer, Leybold — system-level integration for pressure cascade control
Compatibility confirmation for specific system configurations available from our technical team.
Global Sourcing & Shipping Capabilities
- Stock Location: China (Mainland) — bonded warehouse with export documentation support
- Lead Time: In-stock units ship within 3–5 business days; sourced units 7–21 business days (confirmed at order)
- Shipping Methods: DHL Express, FedEx International Priority, UPS Worldwide, sea freight for bulk orders
- Export Documentation: Commercial invoice, packing list, COO (Certificate of Origin), HS code declaration
- Served Regions: Asia-Pacific, Europe, North America, Middle East, Southeast Asia
- Customs Support: HS Code 8481.20 (pressure-reducing valves / controllers) — pre-classified for smooth customs clearance
Certifications & Compliance Statement
- CE Marking: VAT Group AG products manufactured to EU Machinery Directive and Low Voltage Directive standards
- RoHS Compliance: Restriction of Hazardous Substances — standard across VAT’s product range
- ISO 9001: VAT Group AG operates under ISO 9001 quality management certification
- Export Control: Buyers are responsible for verifying end-use compliance with applicable export regulations (EAR, ITAR where applicable). Konmask.com provides accurate product descriptions to support classification.
How to Order
- Confirm Part Number: Verify 810-49867 / 650PM-24CG-ADK3/0431 matches your BOM or equipment service manual.
- Submit Inquiry: Email [email protected] with quantity, required condition (new/refurbished), and delivery timeline.
- Receive Quotation: We respond within 1 business day with pricing, lead time, and stock confirmation.
- Place Order: Purchase via this product page, bank transfer (T/T), or corporate PO for qualified accounts.
- Shipment & Tracking: Tracking number and export documents provided within 24 hours of dispatch.
Minimum Order Quantity: 1 unit | Bulk Pricing: Available for orders of 5+ units
Authenticity & Trust FAQ
Q: How do I know this is a genuine VAT product?
A: We source exclusively from verified supply chains and can provide procurement documentation. Each unit is inspected against VAT’s published part marking standards before shipment.
Q: Can you provide a Certificate of Conformance (COC)?
A: Yes. COC is available for qualified B2B buyers upon request. Please specify this requirement at the time of inquiry.
Q: What if the part doesn’t match my application?
A: Contact us before ordering with your equipment model and chamber configuration. Our technical team will confirm compatibility or recommend the correct VAT part number.
Q: Do you accept returns?
A: Yes, within 30 days for unused, uninstalled units in original packaging. Functional issues covered under our quality guarantee — contact [email protected].
Q: Can you source other VAT part numbers not listed on your site?
A: Yes. Konmask.com maintains access to an extensive VAT parts network. Submit your part number via email and we will respond with availability within 1–2 business days.
