TRICONEX LR82696 PLC Digital Output Module | Replacement, Equivalent & Selection Guide
The TRICONEX LR82696 is a high-reliability PLC Digital Output Module designed for use in Triconex Triple Modular Redundancy (TMR) safety systems. It delivers deterministic digital output control for critical process automation environments including oil & gas, petrochemical, and power generation. This page provides full technical specifications, compatible replacement options, and a structured selection guide to help engineers and procurement teams make informed sourcing decisions.
Technical Specifications
| Parameter | Specification |
|---|---|
| Part Number | LR82696 |
| Manufacturer | TRICONEX (Schneider Electric) |
| Module Type | Digital Output Module |
| Platform | Tricon TMR Safety System |
| Output Type | Digital (Discrete) Output |
| Safety Rating | SIL 3 Capable |
| Communication | Tricon Backplane Bus |
| Operating Temperature | 0°C to 60°C |
| Weight | Approx. 5.26 kg |
| Condition Available | New / Refurbished / Tested |
Note: Specifications are based on published Triconex documentation. Always verify against your system’s engineering drawings before ordering.
Compatible Replacement & Equivalent Models
The following models may serve as functional replacements or equivalents for the TRICONEX LR82696, depending on your system revision and firmware version. Always consult your system integrator before substitution.
- TRICONEX 3805E — Digital Output Module, Tricon platform, direct functional equivalent candidate
- TRICONEX 3603E — Digital Output Module, compatible with Tricon v9/v10 chassis
- TRICONEX 3664 — Enhanced Digital Output Module, extended I/O count
- TRICONEX 3703E — Analog/Digital hybrid output, for mixed-signal applications
- Honeywell SM-DO-8 — Third-party SIL 3 digital output, cross-platform consideration
Contact support@konmask.com for cross-reference verification and compatibility confirmation.
Why Choose the Original TRICONEX LR82696
- TMR Architecture: Triple Modular Redundancy ensures fault tolerance and continuous operation even with single-point failures.
- SIL 3 Certified: Meets IEC 61511 / IEC 61508 safety integrity requirements for high-demand process safety applications.
- Proven Field Reliability: Widely deployed in upstream oil & gas, LNG terminals, and power plant ESD systems globally.
- OEM Firmware Compatibility: Guaranteed compatibility with Triconex TriStation 1131 programming environment.
- Long Service Life: Designed for 10+ year operational cycles in harsh industrial environments.
Typical Applications
- Emergency Shutdown Systems (ESD) in oil & gas facilities
- Burner Management Systems (BMS) in power plants
- High Integrity Pressure Protection Systems (HIPPS)
- Compressor and turbine control systems
- Chemical and petrochemical process safety loops
- LNG liquefaction and regasification plant automation
System Compatibility
The LR82696 is designed for integration within the Triconex Tricon TMR platform. Confirm compatibility with the following system components before ordering:
- Tricon Main Chassis (v9 / v10 / v11 series)
- Triconex Communication Module (TCM) versions
- TriStation 1131 v4.x / v4.12+ programming software
- Tricon Power Supply Modules (PSM)
Not compatible with Trident or Tri-GP platforms without engineering review.
Selection Guide
Use the following criteria to confirm the LR82696 is the correct module for your application:
- Step 1 — Identify Platform: Confirm your system is a Tricon TMR chassis (not Trident or Tri-GP).
- Step 2 — Verify Slot Type: Check the I/O slot designation in your system drawing (digital output slot required).
- Step 3 — Check Firmware Revision: Ensure TriStation firmware is compatible with LR82696 module revision.
- Step 4 — Confirm Output Voltage/Current: Match field device load requirements to module output ratings.
- Step 5 — SIL Verification: Confirm SIL 3 loop requirement aligns with module’s PFD/PFH data from safety manual.
- Step 6 — Sourcing Condition: Specify New, Refurbished (tested), or Exchange to match budget and lead-time requirements.
Quality Assurance & Sourcing
- All modules are inspected and function-tested prior to shipment.
- Refurbished units include full power-on test and I/O channel verification.
- Traceability documentation available upon request (test reports, photos).
- Secure anti-static packaging with shock-absorbing foam inserts.
- Export compliance reviewed for applicable trade regulations (CN origin).
How to Order
- Confirm part number: LR82696
- Specify required condition: New / Refurbished / Exchange
- Provide quantity and required delivery timeline
- Email support@konmask.com or call +0086 19859288691
- Receive quotation within 1 business day
Replacement & Compatibility FAQ
Q: Can the LR82696 replace a TRICONEX 3805E directly?
A: Potentially yes, but firmware revision and chassis slot compatibility must be verified by a qualified Triconex engineer before substitution.
Q: Is the LR82696 available new from stock?
A: Konmask.com maintains both new and refurbished inventory. Contact us for current stock status and lead times.
Q: What warranty is provided?
A: All units carry a minimum 12-month warranty covering functional defects. Extended warranty options available on request.
Q: Can you provide a certificate of conformance?
A: Yes. CoC and test documentation are available for all shipped units upon request.
Q: Do you ship internationally?
A: Yes. Konmask.com ships globally with full export documentation support.
