UNIOP BKDC-16-0045 – Operator Interface Panel | UNIOP HMI Series
Engineering Background
UNIOP is a globally recognized brand in the field of Human-Machine Interface (HMI) technology, delivering robust operator panels engineered for demanding industrial environments. The BKDC-16-0045 is a purpose-built operator interface designed to bridge the gap between machine control systems and plant-floor operators, enabling real-time process visualization, parameter adjustment, and alarm management across a wide range of automation architectures.
Product Positioning
The UNIOP BKDC-16-0045 is positioned as a reliable, field-proven HMI solution for OEM machine builders, system integrators, and end-user facilities requiring a compact yet capable operator panel. It is compatible with major PLC platforms and communication protocols, making it a versatile choice for retrofit and greenfield projects alike. Konmask.com supplies this unit with full traceability and quality verification to meet the procurement standards of industrial engineering teams.
Complete Technical Specifications
| Part Number | BKDC-16-0045 |
| Brand / Manufacturer | UNIOP |
| Product Category | Operator Interface / HMI Panel |
| SKU | BKDC-16-0045 |
| Weight | 200 g (approx.) |
| Communication Interfaces | Serial (RS-232 / RS-485), proprietary UNIOP bus (verify with datasheet) |
| Display Type | Operator keypad / display panel (refer to UNIOP BKDC series datasheet for exact display specs) |
| Operating Temperature | 0 °C to +55 °C (typical for UNIOP BKDC series) |
| Storage Temperature | -20 °C to +70 °C |
| Protection Rating | IP65 front panel (typical; confirm with official datasheet) |
| Power Supply | 24 V DC (typical for UNIOP BKDC series) |
| Mounting | Panel cut-out, front-mount |
| Compliance | CE marked (verify current certification status) |
| Condition | New / Surplus New / Refurbished (specify at order) |
Note: Always cross-reference with the official UNIOP BKDC-16-0045 datasheet for application-critical parameters. Contact support@konmask.com for the latest technical documentation.
Proven Application Environments
- Discrete Manufacturing: Machine tool control panels, assembly line HMI stations
- Packaging Machinery: Operator interface for filling, sealing, and labeling equipment
- Plastics & Rubber Processing: Injection molding machine operator panels
- Food & Beverage: Process parameter display and adjustment in hygienic environments
- HVAC & Building Automation: Compact operator terminals for BMS integration
- Water Treatment: Remote operator stations for pump and valve control
- OEM Machine Builders: Embedded HMI for custom automation equipment
Engineering Advantages
- Compact Form Factor: Optimized for panel-mount installations with minimal footprint, ideal for space-constrained control cabinets.
- UNIOP Ecosystem Compatibility: Seamlessly integrates with UNIOP programming software (eSigner / Designer) for rapid application development.
- Multi-Protocol Support: Compatible with a broad range of PLC brands via serial communication, reducing integration complexity.
- Rugged Industrial Design: Built to withstand vibration, EMI, and temperature variations typical of factory-floor environments.
- Operator-Centric UX: Intuitive keypad layout minimizes operator training time and reduces input errors during production.
- Long Product Lifecycle: UNIOP’s commitment to spare parts availability supports long-term machine maintenance strategies.
System Architecture & Signal Flow
The BKDC-16-0045 operates as the human-facing node in a PLC-based control architecture. The typical signal flow is as follows:
- PLC / Controller → Serial communication link (RS-232/RS-485 or UNIOP proprietary protocol)
- UNIOP BKDC-16-0045 → Receives process data, displays status, accepts operator input
- Operator Input → Transmitted back to PLC as setpoint changes, mode selections, or alarm acknowledgments
- PLC → Executes control logic and updates field devices (actuators, drives, valves)
This architecture ensures deterministic, low-latency operator interaction with the control system, supporting both local and supervisory control modes.
Sourcing & Quality Verification
- Authorized & Surplus Channels: Konmask.com sources UNIOP components through verified distributor networks and surplus channels with documented chain of custody.
- Incoming Inspection: Each unit undergoes visual inspection, label verification, and functional pre-check prior to dispatch.
- Authenticity Assurance: Part numbers, date codes, and manufacturer markings are verified against UNIOP reference standards.
- Packaging Integrity: Units are shipped in anti-static, moisture-barrier packaging with appropriate cushioning for international freight.
- Documentation: Test reports and inspection records available upon request for critical procurement projects.
Procurement Process
- Inquiry: Submit your BOM or part number to support@konmask.com or via the product page for a formal quotation.
- Quotation: Receive a detailed quote including unit price, lead time, shipping options, and payment terms within 1 business day.
- Order Confirmation: Purchase order accepted via email, Shopify checkout, or bank transfer (T/T).
- Quality Check & Dispatch: Unit inspected, packed, and dispatched with tracking information provided.
- After-Sales Support: Technical assistance and warranty claims handled directly by the Konmask engineering team.
Lead Time: Typically 3–7 business days for in-stock units; 2–4 weeks for sourced/special orders.
Minimum Order Quantity: 1 unit.
Bulk Pricing: Available for orders of 5+ units — contact us for a volume discount schedule.
Technical FAQ
Q: Is the UNIOP BKDC-16-0045 compatible with Siemens S7 PLCs?
A: UNIOP panels support a wide range of PLC brands via configurable communication drivers. Compatibility with specific Siemens S7 models depends on the firmware version and driver configuration. Contact us for a compatibility confirmation before ordering.
Q: What programming software is required?
A: UNIOP panels in the BKDC series are typically programmed using UNIOP eSigner or Designer software. Please confirm the exact software version required for BKDC-16-0045 with our technical team.
Q: Can I get a warranty on this unit?
A: Yes. Konmask.com provides a standard 90-day warranty on all verified units covering manufacturing defects. Extended warranty options are available — inquire at order placement.
Q: Do you provide the original UNIOP datasheet?
A: Yes. The official UNIOP BKDC-16-0045 datasheet and any available application notes can be provided upon request. Email support@konmask.com.
Q: What are the shipping options for international orders?
A: We ship worldwide via DHL, FedEx, and UPS Express. Freight cost and Incoterms (EXW / DAP / DDP) are confirmed at quotation stage. Import duties and taxes are the buyer’s responsibility unless DDP is agreed.
