VIBRO METER VM600 MPC4 – Machine Protection Card | VM600 Platform
Engineering Background
The VM600 platform by VIBRO METER (a Meggitt company) is the industry benchmark for continuous machinery protection and condition monitoring in critical rotating equipment. Deployed across power generation, oil & gas, petrochemical, and heavy industrial facilities worldwide, the VM600 rack-based system provides deterministic, SIL-capable protection with sub-millisecond response times.
Product Positioning
The MPC4 (Machine Protection Card), P/N 200-510-076-114, is a four-channel analog input protection module designed for the VM600 chassis. It continuously monitors vibration, position, and process signals against user-configured danger and alert thresholds, triggering relay outputs to protect turbomachinery from catastrophic failure. This card is a direct OEM replacement and is fully compatible with existing VM600 rack configurations without firmware re-flashing or recalibration of adjacent modules.
Complete Technical Specifications
- Manufacturer: VIBRO METER (Meggitt SA)
- Part Number: 200-510-076-114
- Module Type: Machine Protection Card (MPC4)
- Platform: VM600
- Input Channels: 4 × analog (configurable per channel)
- Accepted Signal Types: Velocity, acceleration, displacement (eddy-current / proximity), DC process signals
- Protection Thresholds: Alert (1st level) & Danger (2nd level), independently configurable per channel
- Response Time: < 1 ms (hardware relay trip)
- Relay Outputs: Dedicated per-channel and system-level relay outputs
- Communication: Backplane bus to VM600 rack controller (RMC/AMC modules)
- Power Supply: Supplied via VM600 rack backplane (redundant PSU compatible)
- Operating Temperature: 0 °C to +60 °C
- Storage Temperature: −25 °C to +70 °C
- Humidity: 5 % to 95 % RH, non-condensing
- Form Factor: Single-slot Eurocard module
- Weight: Approx. 400 g
- Compliance: CE, IEC 61511 (SIL-capable architecture)
- Country of Origin: Switzerland
Proven Application Environments
- Gas turbines and steam turbines (power generation & combined-cycle plants)
- Centrifugal and axial compressors (upstream & midstream oil and gas)
- Large pumps and fans in petrochemical and refinery service
- Hydro turbines and generator sets
- Marine propulsion and offshore platform machinery
- Industrial blowers and critical HVAC rotating equipment
Engineering Advantages
- Hardware-level trip speed: Relay actuation in < 1 ms eliminates software latency risk in emergency shutdown scenarios.
- Per-channel independence: Each of the 4 channels operates autonomously — a single-channel fault does not mask or disable adjacent channels.
- Hot-swap compatible: Designed for live rack insertion/removal in VM600 systems with redundant power, minimizing planned downtime.
- Wide sensor compatibility: Accepts signals from eddy-current probes, velocity transducers, and accelerometers without external signal conditioning.
- Backward compatible: Drop-in replacement for earlier MPC4 revisions within the VM600 ecosystem — no rack reconfiguration required.
- Long service life: Industrial-grade components rated for continuous 24/7 operation in harsh environments.
System Architecture & Signal Flow
Field sensors connect to the MPC4 front-panel BNC/terminal inputs. Each channel independently conditions the raw signal, applies configured bandpass filtering, and computes the protection parameter (e.g., peak-to-peak displacement, RMS velocity). The computed value is compared in real time against the programmed Alert and Danger setpoints. On threshold breach, the dedicated hardware relay trips within < 1 ms. Simultaneously, the digitized value is transmitted over the VM600 backplane to the rack controller (RMC16 or AMC8) for data logging, trending, and SCADA/DCS integration via Modbus, Profibus, or OPC-UA.
Sourcing & Quality Verification
- Source: Konmask.com sources VM600 modules from decommissioned OEM-maintained systems and authorized distribution channels.
- Inspection: Every card undergoes visual inspection, board-level continuity check, and functional power-on verification prior to listing.
- Packaging: Anti-static ESD bag + foam-lined carton; humidity indicator card included for long-distance shipment.
- Documentation: Original VIBRO METER datasheet and test record available upon request.
- Warranty: 90-day replacement warranty against DOA (Dead on Arrival) defects.
Procurement Process
- Submit inquiry via support@konmask.com or WhatsApp +0086 19859288691 with your PO number and required delivery date.
- Receive proforma invoice with lead time confirmation (typically 1–3 business days for in-stock items).
- Payment via T/T bank transfer, PayPal, or Alibaba Trade Assurance.
- Shipment via DHL / FedEx / UPS with full tracking; export documentation (commercial invoice, packing list, COO) provided.
- Post-delivery technical support available for installation and commissioning queries.
Technical FAQ
Q: Is this card compatible with the VM600 MkII rack?
A: Yes. The MPC4 200-510-076-114 is compatible with all standard VM600 rack variants. Confirm your rack backplane revision with our technical team if uncertain.
Q: Can the MPC4 replace an older MPC4 with a different sub-revision suffix?
A: In most cases yes — VIBRO METER maintains backward compatibility within the MPC4 family. We recommend sharing your existing card’s full label data for confirmation before ordering.
Q: Do you provide the VM600 configuration software (VMConfig)?
A: VMConfig is licensed separately by Meggitt. We can advise on obtaining the correct software version for your firmware revision.
Q: What is the lead time for out-of-stock units?
A: Typical sourcing lead time is 4–8 weeks for new OEM stock. Contact us for expedited options.
