VIPA CPU 314SB 314-2AG13 – High-Performance Standalone PLC CPU | SPEED7 Platform
Engineering Background
The VIPA CPU 314SB (314-2AG13) is a standalone programmable logic controller CPU built on VIPA’s proprietary SPEED7 architecture, delivering processing performance that significantly exceeds standard Siemens S7-300 CPUs of the same class. Designed for demanding industrial automation environments, this CPU combines high-speed instruction execution with broad compatibility with the Siemens STEP 7 / TIA Portal programming ecosystem, making it a preferred choice for system integrators and OEM machine builders seeking performance upgrades without full platform migration.
Product Positioning
The 314SB is positioned as a drop-in performance replacement for Siemens S7-314 class CPUs in existing S7-300 rack installations, while also serving as a standalone controller in new builds. Its onboard I/O capability, extended memory, and SPEED7 execution engine make it suitable for mid-to-large scale discrete and process control applications across manufacturing, energy, and infrastructure sectors.
Complete Technical Specifications
| Parameter | Specification |
|---|---|
| Order Number | 314-2AG13 |
| Series / Platform | VIPA SPEED7 / S7-300 Compatible |
| CPU Architecture | SPEED7 (proprietary high-speed VIPA core) |
| Processing Speed | Up to 0.6 ns / binary instruction (SPEED7) |
| Work Memory | 512 KB (expandable via MMC) |
| Load Memory | Up to 8 MB (MMC card) |
| Retentive Memory | 128 KB |
| Digital I/O (Onboard) | 16 DI / 16 DO (integrated) |
| Communication Interfaces | MPI/DP (integrated), optional PROFIBUS DP |
| Programming Software | Siemens STEP 7 v5.x / TIA Portal (via VIPA SPEED7 Studio) |
| Rack Compatibility | S7-300 standard rack (UR1/UR2) |
| Power Supply Voltage | DC 24 V (via backplane bus) |
| Operating Temperature | 0 °C to +60 °C |
| Storage Temperature | -40 °C to +70 °C |
| Protection Class | IP20 |
| Dimensions (W×H×D) | 40 × 125 × 130 mm (approx.) |
| Weight | approx. 500 g |
| Certifications | CE, UL, cUL |
Proven Application Environments
- Discrete Manufacturing: Assembly lines, CNC machine tool control, robotic cell coordination
- Process Industries: Chemical dosing, water treatment, HVAC automation
- Energy & Utilities: Substation automation, generator control, power distribution monitoring
- Infrastructure: Tunnel ventilation, conveyor systems, building management
- OEM Machine Builders: Packaging machinery, printing presses, textile equipment
- Retrofit / Upgrade Projects: Direct replacement for Siemens CPU 314 in existing S7-300 installations
Engineering Advantages
- SPEED7 Core: Up to 6× faster instruction execution vs. standard S7-314, reducing scan cycle times in high-I/O applications
- Siemens S7-300 Compatibility: Accepts existing STEP 7 programs with minimal or no modification — zero retraining cost
- Onboard I/O: Integrated 16 DI / 16 DO eliminates the need for a separate SM module in small-to-mid configurations
- Extended Memory: 512 KB work memory vs. 128 KB on standard CPU 314 — supports larger, more complex programs
- Standalone Operation: Can operate without a rack in standalone mode, reducing BOM cost for compact machine builds
- Long-term Availability: VIPA maintains production continuity for industrial lifecycle requirements (10+ year availability)
System Architecture & Signal Flow
The CPU 314SB mounts in slot 2 of a standard S7-300 UR rack. The SPEED7 core executes the user program cyclically, scanning onboard DI inputs, updating the process image, executing logic blocks (OB/FB/FC/DB), and writing outputs to onboard DO and any downstream SM expansion modules via the S7-300 backplane bus. MPI/DP interface supports programming, HMI communication (e.g., Siemens TP/OP panels), and peer-to-peer PLC networking. An MMC card slot provides non-volatile program storage and load memory extension.
Signal flow: Field sensors → DI (onboard/SM) → Process Image Input → CPU SPEED7 Core (OB1 cycle) → Process Image Output → DO (onboard/SM) → Field actuators
Sourcing & Quality Verification
- All units sourced through verified industrial automation distributors and authorized channel partners
- Each module inspected for physical integrity, label authenticity, and firmware version prior to dispatch
- Original VIPA packaging and documentation supplied where available
- Batch traceability records maintained for B2B procurement compliance
- Certificate of conformity available upon request for regulated industries
Procurement Process
- Inquiry: Submit your BOM or part number via email to support@konmask.com or WhatsApp +0086 19859288691
- Quotation: Receive a formal quotation with lead time, quantity availability, and unit pricing within 1 business day
- Order Confirmation: Place order via the Konmask.com storefront or via PO for B2B accounts
- Inspection & Dispatch: Module inspected, packed, and dispatched with tracking within 2–3 business days
- After-Sales Support: Technical support available for integration queries post-delivery
Technical FAQ
Q: Is the CPU 314SB (314-2AG13) a direct replacement for Siemens 6ES7 314-2AG23-0AB0?
A: Yes. The 314SB is designed as a functional replacement for the Siemens CPU 314-2 DP class. Existing STEP 7 programs can be downloaded directly in most cases. Verify hardware configuration settings in HW Config before going live.
Q: Can I use TIA Portal to program this CPU?
A: VIPA recommends SPEED7 Studio (free download) or Siemens STEP 7 v5.x. TIA Portal support is available via VIPA’s TIA compatibility layer — consult the VIPA manual for the specific firmware version.
Q: Does the onboard I/O require a separate power supply?
A: The CPU logic is powered via the S7-300 backplane (PS 307). The onboard DO outputs require a separate DC 24 V load supply connected to the front connector.
Q: What is the maximum number of expansion modules?
A: Up to 8 SM/FM/CP modules per rack, with up to 3 expansion racks (ER) via IM 360/361 interface modules — identical to standard S7-300 architecture.
Q: Is a warranty provided?
A: Konmask.com provides a 90-day functional warranty on all modules. Extended warranty and exchange programs available for volume B2B orders.
