Westinghouse 5X00106G02 – 8-Channel Analog Input Module | WDPF Distributed Control System
Engineering Background: The Westinghouse WDPF (Westinghouse Distributed Processing Family) platform was engineered for mission-critical process control in power generation, petrochemical, and heavy industrial environments. Introduced in the 1980s and continuously refined through the 1990s, WDPF remains operational in hundreds of baseload power plants and refinery control rooms worldwide due to its deterministic scan cycle, robust I/O architecture, and proven field reliability.
Product Positioning: The 5X00106G02 is an 8-channel analog input module designed for the WDPF DCS I/O subsystem. It conditions and digitizes field-level analog signals—current loops, voltage references, and thermocouple/RTD inputs—and delivers engineering-unit values to the WDPF controller over the proprietary WEStation data highway. This module is the preferred replacement for aging 5X00106G01 units and is fully backward-compatible within the WDPF rack infrastructure.
Complete Technical Specifications
- Part Number: 5X00106G02
- Manufacturer: Westinghouse Electric Corporation (now Emerson / Ovation legacy)
- Platform: WDPF (Westinghouse Distributed Processing Family) DCS
- Module Type: Analog Input (AI)
- Number of Channels: 8 differential analog input channels
- Input Signal Types: 4–20 mA current loop; 0–5 V / 1–5 V / 0–10 V voltage; thermocouple (J, K, T, E, R, S, B types); RTD (Pt100, Ni120)
- Resolution: 12-bit A/D conversion (4096 counts)
- Accuracy: ±0.1% of full scale (typical, at 25 °C)
- Input Impedance: >1 MΩ (voltage mode); 250 Ω burden (current mode)
- Common Mode Rejection: >120 dB at 50/60 Hz
- Isolation: 500 V DC channel-to-bus isolation
- Scan Rate: Configurable per WDPF controller scan period (typical 100 ms)
- Power Supply: +5 V DC from WDPF backplane (supplied by rack PSU)
- Power Consumption: ≤3.5 W
- Operating Temperature: 0 °C to +60 °C
- Storage Temperature: –40 °C to +85 °C
- Relative Humidity: 5%–95% non-condensing
- Form Factor: Single-width WDPF I/O module card
- Weight: Approx. 320 g
- Certifications: CE, UL listed (original OEM certification)
Proven Application Environments
- Power Generation: Coal, gas turbine, and nuclear plant DCS I/O expansion and module replacement
- Petrochemical & Refining: Continuous process monitoring of temperature, pressure, and flow analog loops
- Pulp & Paper: Multi-zone temperature profiling via thermocouple inputs on WDPF controllers
- Water Treatment: Analog sensor integration for pH, dissolved oxygen, and turbidity transmitters
- Steel & Metals: Furnace temperature control and rolling mill process variable acquisition
Engineering Advantages
- Drop-in Compatibility: Direct replacement for 5X00106G01 with no firmware or configuration changes required in the WDPF engineering workstation
- High CMR: >120 dB common mode rejection suppresses 50/60 Hz industrial noise on long field cable runs
- Galvanic Isolation: 500 V channel-to-bus isolation protects the controller backplane from field-side ground faults
- Deterministic Scan: Synchronized to WDPF controller scan cycle, ensuring consistent latency for closed-loop PID control
- Multi-Signal Flexibility: Single module supports mA, voltage, TC, and RTD inputs—reducing spare-parts inventory complexity
- Proven MTBF: Field data from power plant installations demonstrates >100,000-hour MTBF under continuous operation
System Architecture & Signal Flow
Field transmitters connect to the WDPF termination panel via shielded twisted-pair cables. The 5X00106G02 module plugs into the WDPF I/O rack backplane, where it receives +5 V power and communicates over the proprietary WEStation serial data highway. The module’s on-board A/D converter samples each channel sequentially, applies linearization (for TC/RTD inputs), performs cold-junction compensation, and places the engineering-unit result in the WDPF data table for the controller to read on each scan. Diagnostic status bits (open-circuit, over-range, under-range) are reported back to the WDPF operator console in real time.
Sourcing & Quality Verification
- Source: Decommissioned surplus from controlled plant shutdowns and OEM-authorized distributors
- Inspection: Each unit undergoes visual inspection, board-level cleaning, and functional power-on verification before listing
- Authenticity: Original Westinghouse part labels, revision markings, and date codes verified; no counterfeit or remarked components
- Packaging: Anti-static bag + foam-lined carton; ESD-safe handling throughout
- Warranty: 90-day operational warranty against DOA; exchange or full refund
Procurement Process
- Submit your RFQ via support@konmask.com or WhatsApp +0086 19859288691
- Receive stock confirmation, photos, and test report within 24 hours
- Payment: T/T, PayPal, or credit card via Shopify Payments
- Shipping: DHL / FedEx Express worldwide; EXW Xiamen available for bulk orders
- Lead time: In-stock units ship within 1–2 business days
Technical FAQ
Q: Is the 5X00106G02 compatible with the WDPF II controller?
A: Yes. The module is compatible with both original WDPF and WDPF II controller generations, provided the rack backplane is a standard WDPF I/O chassis.
Q: Can this module be used with Ovation DCS after migration?
A: No. Ovation uses a different I/O bus architecture. The 5X00106G02 is specific to the WDPF platform. Ovation equivalents are separate part numbers.
Q: What is the difference between G01 and G02 revisions?
A: The G02 revision incorporates an improved A/D converter with enhanced noise immunity and extended thermocouple type support (added R, S, B types). It is a direct functional superset of G01.
Q: Do you provide a test report?
A: Yes. A functional test report is available upon request for each unit prior to shipment.
Q: Can I return the module if it does not work in my system?
A: Yes. We offer a 90-day DOA warranty with exchange or full refund, subject to our returns policy.
