WOODWARD 5462-408 Digital Speed Sensor | Replacement, Equivalent & Selection Guide
The WOODWARD 5462-408 is a precision digital speed sensor designed for turbine control, engine management, and industrial automation applications. This page provides full technical specifications, compatible replacement models, selection guidance, and sourcing information to help engineers and procurement teams make confident decisions.
Technical Specifications
- Manufacturer: WOODWARD
- Part Number: 5462-408
- Type: Digital Speed Sensor (Magnetic Pickup / Hall Effect)
- Output Signal: Digital pulse (TTL-compatible)
- Operating Voltage: Typically 5–24 VDC (verify with datasheet)
- Frequency Range: Suitable for high-speed turbine and engine shaft monitoring
- Connector Type: Industrial-grade, vibration-resistant
- Operating Temperature: -40°C to +125°C (typical industrial range)
- Protection Rating: IP67 or equivalent (confirm with OEM datasheet)
- Weight: Approx. 300 g
- Compliance: CE, RoHS (verify current certification status)
Note: Always cross-reference with the official WOODWARD datasheet before installation.
Compatible Replacement & Equivalent Models
The following models are commonly evaluated as functional replacements or equivalents for the WOODWARD 5462-408. Compatibility must be verified against your specific system requirements:
- WOODWARD 5462-407 — Previous revision; verify signal output compatibility
- WOODWARD 5462-409 — Upgraded variant; check connector and voltage specs
- Bently Nevada 330180-X1-CN — Proximity probe alternative for shaft speed; requires signal conditioning
- Honeywell 1GT101DC — Hall-effect speed sensor; verify mounting thread and gap distance
- Pepperl+Fuchs NJ4-12GK-N — Inductive proximity sensor; suitable for gear-tooth speed detection
- Turck BI2-EG08-AP6X — Compact inductive sensor; confirm output signal type
⚠ Disclaimer: Third-party equivalents require engineering validation. Konmask.com supplies OEM-grade and verified aftermarket parts only.
Why Choose the Original Model
- OEM Precision: Factory-calibrated for WOODWARD turbine and engine control systems
- Guaranteed Compatibility: Drop-in fit for existing WOODWARD control panels without signal reconfiguration
- Long Service Life: Engineered for continuous operation in harsh industrial environments
- Regulatory Compliance: Meets OEM certification requirements for safety-critical applications
- Reduced Commissioning Risk: No re-tuning or parameter adjustment required when replacing like-for-like
Typical Applications
- Gas turbine and steam turbine speed monitoring
- Diesel and gas engine overspeed protection systems
- Compressor and pump shaft speed feedback
- Power generation and co-generation plant control
- Marine propulsion and auxiliary engine management
- Industrial HVAC and rotating machinery monitoring
System Compatibility
The WOODWARD 5462-408 is designed to interface with WOODWARD control platforms including:
- WOODWARD MicroNet TMR / MicroNet Plus
- WOODWARD 505 / 505E Digital Governor
- WOODWARD NetCon 5000
- WOODWARD ProTech TPS / GII Overspeed Protection
- Third-party DCS/PLC systems with compatible digital pulse input modules (verify signal conditioning requirements)
Selection Guide
Use the following criteria to select the correct speed sensor for your application:
- Signal Type: Confirm whether your controller requires magnetic pickup (passive) or active digital output (powered)
- Supply Voltage: Match sensor operating voltage to your control panel’s I/O card specifications
- Mounting Thread: Verify thread size (M18, M12, or custom) and installation depth
- Air Gap: Confirm recommended gap distance between sensor tip and gear tooth
- Frequency Range: Ensure sensor bandwidth covers your maximum shaft RPM × gear tooth count
- Environment: Select IP rating and temperature range appropriate for your installation zone
- Certification: For hazardous areas (ATEX/IECEx), confirm the sensor’s explosion-proof rating
Not sure which model fits your system? Contact our technical team at support@konmask.com for a free selection consultation.
Quality Assurance & Sourcing
- Source: Authorized distributors and verified OEM supply chains
- Inspection: Each unit undergoes visual, dimensional, and functional verification before shipment
- Traceability: Full batch traceability with documentation available on request
- Warranty: 12-month warranty against manufacturing defects
- Counterfeit Prevention: We do not source from grey-market or unverified channels
How to Order
- Confirm part number: WOODWARD 5462-408
- Specify quantity and required delivery timeline
- Submit your inquiry via the product page or email support@konmask.com
- Receive quotation with lead time, pricing, and shipping options within 24 hours
- Confirm order and receive tracking information upon dispatch
For urgent requirements or bulk orders, call us directly: +0086 19859288691
Replacement & Compatibility FAQ
Q: Can I use a third-party equivalent instead of the OEM 5462-408?
A: In many cases yes, but engineering validation is required. Signal output type, voltage, mounting dimensions, and gap distance must all match. Contact us for a compatibility assessment.
Q: Is the 5462-408 still in production?
A: WOODWARD periodically revises part numbers. We maintain stock of current and legacy variants. Contact us to confirm availability.
Q: What is the lead time for this part?
A: Standard lead time is 3–7 business days for in-stock units. Custom or low-volume OEM parts may require 2–4 weeks.
Q: Do you provide installation support?
A: We provide technical documentation and pre-sales consultation. On-site installation support is available through our partner network.
Q: Can I return the part if it is not compatible?
A: Yes, unused parts in original packaging may be returned within 30 days. Please contact support before returning.
