Thermocouple Temperature Monitoring Solution – WOODWARD 5462-948 | T/C Card Series
Where This Product Is Used
The WOODWARD 5462-948 T/C Card (8 Channel) is a dedicated thermocouple input module engineered for high-reliability temperature acquisition in critical industrial control systems. Typical deployment environments include:
- Gas & Steam Turbine Control – Exhaust gas temperature (EGT) monitoring across all 8 channels simultaneously in WOODWARD governor and control systems
- Power Generation Plants – Generator protection panels requiring multi-point thermal surveillance
- Compressor Stations – Bearing and winding temperature monitoring in reciprocating and centrifugal compressor packages
- Oil & Gas Processing – Wellhead and pipeline thermal management integrated with SCADA/DCS architectures
- Industrial Furnaces & Kilns – Zone-by-zone temperature profiling for combustion optimization
- Marine Propulsion Systems – Engine room thermal monitoring on vessels using WOODWARD speed control platforms
Engineers specify this card wherever 8 independent thermocouple inputs must be conditioned, isolated, and digitized within a single compact module slot.
Technical Specifications
| Part Number | 5462-948 |
| Manufacturer | WOODWARD |
| Module Type | Thermocouple (T/C) Input Card |
| Input Channels | 8 Channels (independent) |
| Thermocouple Types Supported | J, K, T, E, R, S, B (application-dependent; confirm with system documentation) |
| Signal Conditioning | Cold junction compensation (CJC), hardware filtering |
| Isolation | Channel-to-channel and channel-to-bus isolation |
| Communication Interface | Backplane bus compatible with WOODWARD control platform |
| Operating Temperature | 0°C to +60°C (storage: -40°C to +85°C) |
| Power Supply | Supplied via backplane (refer to system power budget) |
| Weight | Approx. 300 g |
| Form Factor | Plug-in card module (rack/chassis mount) |
| Compliance | CE, UL/cUL (verify current certification status with WOODWARD) |
Note: Specifications are based on available OEM documentation. Always cross-reference with the applicable WOODWARD system manual before installation.
Why Engineers Specify This Model
- 8-Channel Density – Consolidates 8 thermocouple inputs into a single card slot, reducing rack space and wiring complexity versus discrete transmitters
- Integrated CJC – On-board cold junction compensation eliminates the need for external reference junctions, improving measurement accuracy
- Platform Native – Designed as an OEM module for WOODWARD control systems; plug-and-play compatibility with no custom driver development
- Galvanic Isolation – Protects the control backplane from ground loops and common-mode noise inherent in industrial thermocouple wiring
- Proven Field Record – Widely deployed in turbine OEM packages globally; long service history in harsh environments
- Simplified Spare Parts Management – Single SKU covers all 8 channels; reduces spare parts inventory overhead for plant maintenance teams
Complete System Bill of Materials
The 5462-948 T/C Card is typically specified alongside the following WOODWARD components for a complete control system build or repair:
- WOODWARD MicroNet TMR / MicroNet Plus controller chassis
- WOODWARD Power Supply Module (e.g., 5464-xxx series)
- WOODWARD Analog Output Card (e.g., 5462-xxx series)
- WOODWARD Digital I/O Card (e.g., 5463-xxx series)
- WOODWARD Communication Gateway / Ethernet Module
- Thermocouple extension cables (type-matched, shielded)
- Terminal block assemblies and DIN rail hardware
Contact support@konmask.com for a complete BOM quotation or system-level sourcing support.
Compliance & Industry Standards
- CE Marking – European conformity for EMC and low-voltage directives
- UL/cUL Listed – North American safety certification (verify current listing with WOODWARD)
- IEC 61511 / IEC 61508 – Functional safety framework applicable to process industry SIS deployments
- IEEE 1613 – Environmental and testing requirements for communications networking devices in electric power substations (where applicable)
- RoHS Compliant – Restriction of hazardous substances in electrical and electronic equipment
Compliance status should be confirmed against the specific firmware and hardware revision in use. Konmask supplies OEM-original parts; counterfeit-free sourcing is our baseline commitment.
Quality Assurance & Sourcing
Konmask.com sources the WOODWARD 5462-948 exclusively through verified industrial distribution channels and authorized surplus networks. Every unit offered is subject to:
- Visual & Physical Inspection – Board-level inspection for damage, corrosion, and component integrity
- Label & Serialization Verification – OEM part number, revision, and date code cross-checked against WOODWARD documentation
- Functional Test (where applicable) – Bench-level power-on and communication verification prior to shipment
- Anti-Static Packaging – ESD-safe bags and foam-lined cartons for transit protection
- Traceability Documentation – Certificate of conformance and sourcing records available on request
We do not sell gray-market, refurbished-as-new, or counterfeit parts. If a unit does not meet our inspection criteria, it is not listed.
How to Source This Part
- Submit an RFQ – Email support@konmask.com with your required quantity, delivery timeline, and destination country
- Receive a Quotation – We respond within 1 business day with pricing, lead time, and stock confirmation
- Place Your Order – Secure checkout via Konmask.com or proforma invoice for bank transfer (T/T)
- Shipment & Tracking – DHL / FedEx / UPS express with full tracking; export documentation included for international orders
- After-Sales Support – Technical questions and warranty claims handled directly by our engineering team
For urgent plant shutdowns or emergency procurement, call +0086 19859288691 for priority handling.
Application-Specific FAQ
Q: Is the 5462-948 compatible with WOODWARD MicroNet TMR systems?
A: Yes. The 5462-948 is designed for WOODWARD’s MicroNet platform family. Confirm slot compatibility with your specific chassis revision using the WOODWARD system manual.
Q: Which thermocouple types does this card support?
A: The card supports standard industrial thermocouple types (J, K, T, E, R, S, B). The active type is configured via the WOODWARD application software. Consult your system configuration file for the type in use.
Q: Can I use this card as a direct replacement for a failed unit without reconfiguration?
A: In most cases, yes — provided the replacement unit shares the same hardware revision. The configuration is stored in the controller, not the card. Always verify revision compatibility before hot-swapping.
Q: Do you offer exchange or repair services for the 5462-948?
A: We offer outright sale of tested units. For repair or exchange programs, contact us at support@konmask.com to discuss options.
Q: What is the lead time for this part?
A: Lead time depends on current stock. In-stock units ship within 2–3 business days. Out-of-stock units are sourced within 2–4 weeks. Contact us for real-time availability.
Q: Can Konmask provide export documentation for international shipments?
A: Yes. We provide commercial invoice, packing list, certificate of origin, and ECCN/HTS classification documentation for all international orders.
