WOODWARD 5417-175 Cable Assembly — Interconnect Harness | WOODWARD Governor Control Platform
Engineering Background: WOODWARD governor and turbine control systems are mission-critical infrastructure across power generation, oil & gas processing, and water treatment facilities worldwide. The 5417-175 Cable Assembly serves as the dedicated interconnect harness within WOODWARD’s governor control architecture, providing the signal and power routing backbone between the controller chassis and field-mounted actuators or sensors. In distributed control topologies, cable assembly integrity is a primary determinant of system reliability — a degraded or non-OEM harness introduces impedance mismatch, EMI susceptibility, and potential ground-loop faults that can trigger spurious trips or governor instability.
Product Positioning: The 5417-175 is a factory-terminated, application-specific cable assembly engineered to WOODWARD’s internal wiring specifications. Unlike generic industrial cable assemblies, this part number carries defined conductor gauge, shielding topology, connector pinout, and strain-relief geometry matched to the target control module. It is not interchangeable with adjacent WOODWARD cable part numbers without engineering verification of connector type and signal mapping. Suitable for new installations, scheduled maintenance replacements, and emergency spares programs where OEM traceability is required.
Complete Technical Specifications
Electrical
- Part Number: 5417-175
- Assembly Type: Multi-conductor shielded cable assembly, factory-terminated
- Conductor Configuration: Per WOODWARD internal wiring standard (application-specific)
- Shielding: Overall foil/braid shield with drain wire; 85%+ coverage
- Voltage Rating: Compatible with WOODWARD low-voltage control circuits (typically 24 VDC / 120 VAC signal levels)
- Connector Type: OEM-specified, keyed, locking — per WOODWARD governor module interface
- Impedance: Matched to WOODWARD signal chain requirements
Mechanical
- Weight: Approx. 300 g (as listed)
- Termination: Factory-crimped and tested; strain-relief boots on both ends
- Cable Jacket: PVC or equivalent industrial-grade outer jacket
- Bend Radius: Per WOODWARD installation guidelines
Environmental
- Operating Temperature: –20°C to +70°C (typical WOODWARD control cabinet rating)
- Humidity: 5–95% RH, non-condensing
- Installation Environment: Indoor control cabinet / enclosed panel; not rated for direct outdoor exposure
Certifications
- Manufactured to WOODWARD quality management system (ISO 9001-aligned)
- RoHS compliance per WOODWARD standard product policy
- CE marking applicability per end-system certification
Data source: WOODWARD published product documentation, OEM part number cross-reference, and supplier technical records. Specifications subject to revision per WOODWARD engineering change notices.
Proven Application Environments
- Power Generation / Gas Turbine: Gas turbine governor control panels — continuous duty, high-vibration enclosures requiring secure locking connectors and shielded signal integrity.
- Power Generation / Steam Turbine: Steam turbine speed control systems — high-temperature ambient cabinets where OEM cable routing prevents thermal derating of adjacent components.
- Oil & Gas / Upstream Compression: Reciprocating compressor engine governor systems — environments with hydrocarbon vapor, requiring jacket integrity and sealed connector interfaces.
- Petrochemical / Process Control: Refinery turbine-driven pump control — where spurious trips from cable faults carry significant process safety and production cost consequences.
- Water Treatment / Pumping Stations: Variable-speed pump governor control — humid, corrosive environments where shielded OEM assemblies prevent ground-loop interference on 4–20 mA control loops.
- Marine / Offshore Power: Diesel generator governor control on offshore platforms — salt-air environments with strict OEM traceability requirements for class society audits.
Engineering Advantages
- For high-vibration turbine enclosures, this cable assembly maintains connector seating integrity, because the OEM locking mechanism and strain-relief geometry are co-designed with the mating WOODWARD module chassis.
- For EMI-sensitive governor signal circuits, this cable assembly preserves signal fidelity, because the factory-applied shielding topology and drain wire termination are matched to WOODWARD’s internal grounding scheme.
- For scheduled maintenance outages with tight return-to-service windows, this cable assembly enables direct drop-in replacement, because OEM pinout and connector keying eliminate field wiring verification steps.
- For facilities with ISO 55000 asset management programs, this cable assembly supports full OEM traceability, because the WOODWARD part number links directly to the original design specification and revision history.
- For petrochemical sites with functional safety requirements (IEC 61511), this cable assembly reduces modification risk, because using OEM interconnects preserves the validated safety instrumented system (SIS) configuration.
- For procurement teams managing multi-site spare parts standardization, this cable assembly simplifies inventory governance, because a single WOODWARD part number applies consistently across all installations using the same governor module variant.
System Architecture & Signal Flow
The 5417-175 Cable Assembly routes control signals and/or power between the WOODWARD governor controller chassis and its associated actuator, sensor, or I/O expansion module. Signal flow is unidirectional or bidirectional depending on the connected module pair — typically carrying speed reference signals, actuator position feedback, or discrete I/O between the main control card and field interface. The shielded construction ensures that high-frequency noise from adjacent VFDs, contactors, or power cables does not corrupt the low-level governor control signals.
Compatible Modules: Compatibility is determined by the connector interface and signal mapping of the target WOODWARD governor platform (e.g., WOODWARD 505, 505E, MicroNet, NetCon series). Verification of the specific governor model and slot assignment is required before ordering.
Substitution Conditions: No direct substitution with non-OEM cable assemblies is recommended for safety-classified or warranty-active systems. For legacy systems where OEM supply is constrained, a custom-fabricated replacement requires full connector pinout verification, shielding continuity test, and engineering sign-off.
Sourcing & Quality Verification
Konmask.com sources WOODWARD components through established industrial automation supply channels, prioritizing OEM-traceable stock. All units undergo a 4-step incoming inspection before dispatch:
- Part Number Verification: Physical label and packaging cross-checked against WOODWARD part number 5417-175 and revision level.
- Connector Integrity Check: Visual and tactile inspection of both terminations — locking tabs, pin seating, and strain-relief condition.
- Continuity & Shield Test: End-to-end conductor continuity and shield isolation verified with calibrated test equipment.
- Packaging & ESD Compliance: Confirmed anti-static packaging and humidity indicator card before shipment.
Available Documentation: Certificate of Conformance (CoC), packing list with part number and serial/lot reference, test record on request, and WOODWARD OEM datasheet where publicly available.
Procurement Process
- Inquiry Submission: Submit part number 5417-175, required quantity, and delivery timeline via support@konmask.com or the product page inquiry form. Include the target WOODWARD governor model for compatibility confirmation.
- Quotation & Stock Confirmation: A technical quotation with confirmed stock status, lead time, and pricing is issued within 24 hours of inquiry receipt on business days.
- Order & Dispatch: Upon purchase order confirmation, units are inspected, packaged, and dispatched with full documentation. Express freight options are available for emergency maintenance requirements.
Technical Support: Pre-sales compatibility consultation, installation reference guidance, and post-delivery technical queries are handled by Konmask’s engineering support team. Support is available via email and phone for B2B accounts.
Technical FAQ
Q: Is the 5417-175 compatible with all WOODWARD governor platforms?
A: No. The 5417-175 is application-specific. Compatibility depends on the connector interface and signal assignment of the target WOODWARD module. Provide the governor model number and slot reference when inquiring — Konmask’s technical team will confirm compatibility before order confirmation.
Q: Can the 5417-175 be substituted with a different WOODWARD cable assembly part number?
A: Adjacent WOODWARD cable part numbers (e.g., 5417-174, 5417-176) may differ in length, connector type, or conductor count. Substitution requires engineering verification of the full pinout and physical fit. Konmask can assist with cross-reference analysis upon request.
Q: Does this cable assembly meet the requirements for use in IEC 61511 safety instrumented systems?
A: The 5417-175 is an OEM WOODWARD component. Its use in a SIS application is subject to the overall system safety validation performed by the end-user’s functional safety engineer. Using OEM interconnects preserves the validated hardware configuration; however, formal SIL suitability determination remains the responsibility of the system integrator or end-user per IEC 61511 requirements.
