WOODWARD UMT1 UMT145B A3 LR20523 – Universal Microprocessor Control Module | WOODWARD UMT Series
Engineering Background
WOODWARD is a globally recognized leader in energy control solutions, with over a century of engineering heritage in turbine, engine, and industrial process control systems. The UMT (Universal Microprocessor Technology) series represents WOODWARD’s commitment to delivering high-reliability, field-proven control intelligence for demanding industrial environments.
Product Positioning
The WOODWARD UMT1 UMT145B A3 LR20523 Control Module is a precision microprocessor-based control unit designed for integration into WOODWARD governor and control systems. It serves as the computational core for turbine speed governing, load sharing, and process control applications across power generation, oil & gas, and heavy industrial sectors. Procurement engineers sourcing replacement or spare modules for WOODWARD-based control architectures will find this unit a direct, specification-matched solution.
Complete Technical Specifications
| Manufacturer | WOODWARD |
| Part Number / Model | UMT1 UMT145B A3 LR20523 |
| Series | UMT (Universal Microprocessor Technology) |
| Module Type | Microprocessor Control Module |
| Form Factor | Card/Board Module (rack-mountable) |
| Application | Turbine governor control, speed/load regulation, process control |
| Compatibility | WOODWARD UMT-series governor and control chassis |
| Revision | A3 |
| Reference Drawing | LR20523 |
| Weight (approx.) | 500 g |
| Condition | New / Surplus New / Refurbished (specify at inquiry) |
| Warranty | 12 months (subject to application) |
| Country of Origin | USA |
Proven Application Environments
- Power Generation: Gas turbine and steam turbine governor systems requiring precise speed and load control
- Oil & Gas: Compressor and pump drive control in upstream and midstream facilities
- Marine Propulsion: Engine control systems aboard vessels requiring WOODWARD governor integration
- Industrial Process: Critical process machinery where microprocessor-based closed-loop control is mandated
- Utilities & Co-generation: Parallel operation and load sharing in distributed generation plants
Engineering Advantages
- Direct OEM Replacement: Exact part number match eliminates re-engineering or reconfiguration downtime
- Microprocessor Precision: UMT architecture delivers deterministic control response critical for turbine governing
- Proven Field Reliability: WOODWARD UMT modules are deployed in thousands of installations globally across decades of service
- Revision-Controlled Design: A3 revision designation ensures compatibility traceability within WOODWARD’s engineering change management system
- Reduced MTTR: Plug-and-play module replacement minimizes mean time to repair in critical plant shutdowns
System Architecture & Signal Flow
The UMT145B A3 module operates as the central processing unit within the WOODWARD UMT governor chassis. It receives analog and digital input signals from field sensors (speed pickups, pressure transducers, temperature sensors), executes the configured control algorithm in real time, and outputs actuator drive signals to fuel control valves or variable geometry mechanisms. Communication with operator HMI and supervisory SCADA systems is facilitated through the module’s serial or network interface ports as defined by the LR20523 reference drawing.
Signal flow summary:
- Field sensors → Analog/Digital Input conditioning → UMT1 CPU processing → PID/control algorithm execution → Actuator output signals
- Supervisory interface: Serial RS-232/RS-485 or proprietary WOODWARD network protocol
Sourcing & Quality Verification
- All modules are inspected upon receipt and prior to dispatch
- Functional testing available upon request (test report provided)
- Traceability documentation (OEM labels, revision markings, serial numbers) preserved and photographed
- Anti-static packaging with humidity indicator cards for safe international transit
- Certificate of Conformance (CoC) available for regulated procurement environments
Procurement Process
- Inquiry: Submit your RFQ with required quantity, delivery timeline, and condition preference via email or the contact form
- Quotation: Receive a formal quotation with unit price, lead time, and shipping options within 24 business hours
- Order Confirmation: Purchase order accepted; proforma invoice issued for payment processing
- Quality Check & Dispatch: Module inspected, photographed, and packed; tracking number provided upon shipment
- After-Sales Support: Technical assistance available post-delivery for installation verification
Technical FAQ
Q: Is this module compatible with all WOODWARD UMT chassis variants?
A: The UMT145B A3 is designed for specific UMT-series chassis. Please confirm your chassis model number with our technical team prior to ordering to ensure pin and firmware compatibility.
Q: Can you provide the original WOODWARD datasheet or drawing LR20523?
A: We can share available technical documentation upon request under NDA where applicable. Contact our support team.
Q: What is the lead time for this module?
A: In-stock units ship within 3–5 business days. Ex-stock sourcing lead time is typically 2–4 weeks depending on global availability.
Q: Do you offer exchange/repair services?
A: Yes. Core exchange and third-party repair/refurbishment services are available. Contact us with your defective unit details for a repair quotation.
Q: Is this a genuine WOODWARD part?
A: All units sourced by Konmask are genuine OEM parts. We do not deal in counterfeit or unauthorized reproductions. Traceability documentation is provided with every shipment.
