YASKAWA CPS-150F – Regulated Industrial Power Supply Unit | MP900 / MP2000 Series Platform
Engineering Background: The CPS-150F is the dedicated power supply module engineered by YASKAWA Electric Corporation for its MP900 and MP2000 series machine controllers. Designed to deliver stable, regulated DC power in demanding industrial environments, it forms the backbone of the controller rack’s power architecture — ensuring clean, uninterrupted energy delivery to CPU, I/O, and communication modules under continuous production loads.
Product Positioning: Targeting OEM machine builders, system integrators, and MRO procurement engineers who require a direct OEM-equivalent replacement or new-build component for YASKAWA MP-series control systems. The CPS-150F is not a generic PSU — it is a precision-matched module with YASKAWA’s proprietary connector footprint, protection logic, and thermal management profile.
Complete Technical Specifications
- Part Number: CPS-150F
- Manufacturer: YASKAWA Electric Corporation
- Compatible Platform: MP900 Series, MP2000 Series Machine Controllers
- Rated Output Power: 150 W
- Input Voltage: AC 100–240 V, 50/60 Hz (wide-range universal input)
- Output Voltage: DC 5 V / DC 24 V (dual-rail regulated output)
- Regulation Accuracy: ±1% (full load, nominal input)
- Overcurrent Protection: Built-in hardware OCP with auto-recovery
- Overvoltage Protection: Hardware OVP latch
- Mounting Style: Rack-mount (YASKAWA MP-series backplane slot)
- Cooling Method: Forced-air convection (internal fan)
- Operating Temperature: 0 °C to +55 °C
- Storage Temperature: −20 °C to +85 °C
- Humidity: 10–90% RH (non-condensing)
- Weight: Approx. 780 g
- Country of Origin: Japan
- Compliance: CE, UL, RoHS
Proven Application Environments
- CNC Machining Centers: Powers MP2000-based motion controllers in 5-axis machining centers requiring sub-millisecond power stability for interpolation accuracy.
- Semiconductor Wafer Handling: Deployed in YASKAWA MOTOMAN robot controllers integrated with MP900 CPUs for cleanroom wafer transfer systems.
- Packaging & Labeling Lines: Supplies regulated power to MP2000 multi-axis servo systems coordinating pick-and-place, sealing, and label application at high cycle rates.
- Textile & Winding Machinery: Provides stable DC rails for tension-control servo drives in yarn winding and fabric processing equipment.
- Printing Press Automation: Supports register-control MP-series controllers where power ripple directly impacts print registration accuracy.
- Elevator & Hoist Control Panels: Used in safety-rated control cabinets where redundant power integrity is mandated by EN 81 standards.
Engineering Advantages
- OEM-Matched Connector Footprint: Direct plug-in replacement — no wiring modification, no adapter bracket required for MP900/MP2000 racks.
- Dual-Rail Regulated Output: Simultaneous 5 V (logic) and 24 V (I/O) rails eliminate the need for external DC-DC converters in the control cabinet.
- Hardware Protection Stack: OCP + OVP + thermal shutdown with auto-recovery minimizes unplanned downtime versus generic PSU alternatives.
- Wide-Range AC Input: 100–240 V universal input supports global deployment without input transformer changes.
- Compact Rack Form Factor: Occupies a single slot in the MP-series backplane, preserving rack space for additional I/O or communication modules.
- YASKAWA Firmware Compatibility: Power-good signal timing is calibrated to MP-series CPU boot sequence — prevents false fault codes on controller startup.
System Architecture & Signal Flow
In a typical MP2000-series control rack, the CPS-150F occupies the leftmost slot of the base unit. AC mains enter via the module’s terminal block; the internal switching converter generates regulated 5 VDC and 24 VDC rails distributed across the backplane bus. A power-good (PG) signal is asserted to the CPU module within 200 ms of stable output — gating the CPU’s boot sequence. The 24 V rail simultaneously powers field-side I/O modules and digital output drivers. Fault conditions (OCP/OVP/thermal) pull the PG signal low, triggering a controlled CPU shutdown and logging a fault event in the MP-series system log.
Sourcing & Quality Verification
- All units sourced through authorized YASKAWA distribution channels or verified OEM-surplus with full traceability documentation.
- Each unit undergoes incoming inspection: visual check, label authenticity verification, and functional power-on test (output voltage, PG signal timing).
- Serialized units include YASKAWA factory date code — verifiable against YASKAWA’s production records upon request.
- Anti-counterfeit measures: holographic label inspection, PCB marking cross-check, and connector pin-out verification against YASKAWA service manual.
- Konmask.com provides a 12-month warranty on all CPS-150F units shipped.
Procurement Process
- Submit your inquiry via support@konmask.com or the on-page RFQ form with your required quantity and delivery timeline.
- Receive a formal quotation with unit price, lead time, and shipping options within 24 business hours.
- Confirm purchase order — payment via T/T, PayPal, or credit card accepted.
- Unit ships within 1–3 business days from Xiamen, China via DHL Express, FedEx, or UPS with full tracking.
- Post-delivery technical support available via email or WhatsApp for installation verification.
Technical FAQ
Q: Is the CPS-150F compatible with both MP900 and MP2000 series racks?
A: Yes. The CPS-150F is the standard power supply module for both MP900 and MP2000 series base units. Verify your rack model against YASKAWA’s hardware manual (SIEP C880700 series) to confirm slot compatibility.
Q: Can the CPS-150F be used as a standalone 24 VDC power supply?
A: No. The CPS-150F is designed exclusively for installation in YASKAWA MP-series backplane racks. Its output connector and PG signal logic are proprietary to the MP-series architecture.
Q: What is the replacement procedure if the CPS-150F fails in service?
A: Power down the control rack, remove the failed module by releasing the front-panel locking lever, slide out the unit, insert the replacement CPS-150F, and restore power. No firmware reconfiguration is required — the CPU recognizes the module automatically.
Q: Do you provide a test report or incoming inspection certificate?
A: Yes. A functional test report is available upon request for orders of 3 units or more. Contact support@konmask.com to include this in your order requirements.
Q: What is the lead time for bulk orders (10+ units)?
A: Typical lead time for bulk orders is 5–10 business days depending on current stock levels. Contact us early to reserve allocation.
