Yaskawa DX100 CPS-520F / JZNC-YPS01-E / 158129-3 / JEPMC-W6002-01 — Servo Driver Communication Cable | DX100 Robot Controller Platform
Engineering Background
The Yaskawa DX100 is a high-performance robot controller platform widely deployed in arc welding, material handling, assembly, and painting automation lines. The internal servo communication architecture relies on a dedicated cable harness to maintain real-time, low-latency signal integrity between the power supply unit (CPS-520F) and the servo driver board (JZNC-YPS01-E). Part numbers 158129-3 and JEPMC-W6002-01 are OEM cross-references for the same assembly, ensuring backward compatibility across DX100 controller revisions.
Product Positioning
This cable is a critical consumable and spare part for maintenance engineers responsible for Yaskawa DX100 robot cells. Connector degradation, insulation fatigue, or signal noise on this harness directly causes servo alarm faults (e.g., A.810, A.820 series), unplanned downtime, and production loss. Stocking a verified OEM replacement eliminates lead-time risk during emergency maintenance windows.
Complete Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Yaskawa Electric Corporation |
| Part Number (Primary) | CPS-520F |
| Cross-Reference 1 | JZNC-YPS01-E |
| Cross-Reference 2 | 158129-3 |
| Cross-Reference 3 | JEPMC-W6002-01 |
| Compatible Controller | Yaskawa DX100 |
| Cable Function | Servo Driver Communication / Power Supply Interface |
| Signal Type | Serial communication (servo encoder / drive bus) |
| Country of Origin | Japan |
| Approximate Weight | 600 g |
| Condition | New OEM / Surplus New |
Proven Application Environments
- Yaskawa Motoman DX100 robot controller (all axis configurations)
- Arc welding robot cells (MA, VA series robots)
- Material handling and palletizing lines
- Automotive body-in-white assembly automation
- Painting and coating robot systems
- Multi-robot coordinated motion systems using DX100 as master controller
Engineering Advantages
- OEM Genuine Part: Manufactured to Yaskawa’s original electrical and mechanical tolerances — no signal degradation risk from aftermarket substitutes.
- Multi-PN Compatibility: CPS-520F, JZNC-YPS01-E, 158129-3, and JEPMC-W6002-01 are verified cross-references for the same assembly, simplifying procurement across different BOM revisions.
- Plug-and-Play Replacement: No firmware changes or parameter adjustments required upon installation.
- Reduces Servo Alarm Risk: Eliminates communication faults caused by cable wear, connector oxidation, or insulation breakdown.
- Long-Term Availability: Sourced from authorized distribution channels and verified surplus stock to support legacy DX100 installations.
System Architecture & Signal Flow
In the DX100 controller cabinet, the CPS-520F power supply unit provides regulated DC power to the servo amplifier boards. The JEPMC-W6002-01 / JZNC-YPS01-E cable assembly carries both power and serial communication signals between the CPS-520F and the servo driver module. Signal integrity on this harness is critical for encoder feedback accuracy and real-time torque/speed control loop performance. Any impedance mismatch or connector fault on this cable will manifest as servo communication alarms and axis disable events.
Sourcing & Quality Verification
- All parts are sourced from authorized Yaskawa distributors or verified OEM surplus channels.
- Each unit undergoes visual inspection and connector continuity verification prior to shipment.
- Part numbers are cross-checked against Yaskawa’s official parts database to confirm compatibility.
- Packaging includes original or equivalent anti-static protection for connector and cable integrity during transit.
Procurement Process
- Add to cart and complete checkout — secure payment via major credit cards, PayPal, and wire transfer accepted.
- Order confirmation and proforma invoice issued within 1 business day.
- Stock availability confirmed; lead time communicated within 24 hours for non-stock items.
- Ships from warehouse within 1–3 business days; DHL / FedEx / UPS express options available.
- Tracking number provided upon dispatch; customs documentation (commercial invoice, packing list) included.
Technical FAQ
Q: Are CPS-520F, JZNC-YPS01-E, 158129-3, and JEPMC-W6002-01 the same part?
A: Yes. These are Yaskawa OEM cross-reference part numbers for the same servo driver communication cable assembly used in the DX100 controller platform.
Q: Which DX100 robot models is this cable compatible with?
A: This cable is compatible with all Yaskawa Motoman robots controlled by the DX100 controller, including MA, VA, HP, and UP series robots.
Q: What servo alarms does a faulty cable typically cause?
A: Common symptoms include A.810 (encoder communication error), A.820 (encoder data error), and intermittent axis disable faults. Replacing this cable resolves communication-layer faults.
Q: Can I use this cable on a DX200 or YRC1000 controller?
A: No. This cable is specifically designed for the DX100 platform. DX200 and YRC1000 use different servo communication architectures and connector types.
Q: Do you provide a warranty?
A: Yes. We offer a 90-day warranty against manufacturing defects. DOA (Dead on Arrival) units are replaced at no charge.
