Industrial Robot Control Solution – Yaskawa JANCD-YCP01B-E | DX100 / NX100 Series
Where This Product Is Used
The Yaskawa JANCD-YCP01B-E is the central CPU board of the DX100 and NX100 robot controller platforms — Yaskawa’s flagship multi-axis motion control systems deployed across high-throughput industrial environments worldwide. This board is the computational core that executes robot motion programs, manages I/O communication, and coordinates real-time axis interpolation.
Typical deployment environments include:
- Arc Welding Cells – Motoman MA, VA, and EA series robots performing MIG/TIG/plasma welding in automotive body shops and fabrication plants
- Spot Welding Lines – High-cycle automotive assembly with servo gun control and weld timer integration
- Material Handling & Palletizing – HP, MPL, and MPK series robots in food, beverage, and logistics facilities
- Assembly & Pick-and-Place – Electronics manufacturing, semiconductor handling, and precision assembly
- Painting & Coating – Explosion-proof robot cells requiring deterministic motion control
- Machine Tending – CNC machine loading/unloading with coordinated external axis control
Technical Specifications
| Part Number | JANCD-YCP01B-E |
| Compatible Controller | Yaskawa DX100 / NX100 |
| Cross-Reference SKUs | SGDR-AXB01A, ZNC-NIF02B-2 |
| Board Function | Main CPU / Motion Control Processor |
| Supported Robot Series | Motoman MA, VA, EA, HP, MPL, MPK, UP series |
| Communication Interfaces | MECHATROLINK-II, DeviceNet, Ethernet (model-dependent) |
| Max Controlled Axes | Up to 8 axes (robot + external) |
| Operating Temperature | 0 °C to 45 °C |
| Country of Origin | Japan |
| Weight | Approx. 300 g |
| Condition | New / Surplus / Refurbished (specify at inquiry) |
Why Engineers Specify This Model
- Drop-in Replacement – Direct board-level swap for failed or degraded JANCD-YCP01B-E units; no firmware re-flashing required when replacing like-for-like
- Deterministic Real-Time Control – Executes INFORM III motion language with microsecond-level cycle consistency critical for weld seam accuracy and coordinated multi-robot cells
- Multi-Axis Coordination – Manages synchronized motion of robot arm axes plus external positioners, conveyors, and servo tracks in a single controller instance
- Long Service Life – Designed for 24/7 industrial duty cycles; OEM-grade components rated for extended MTBF in harsh factory environments
- Broad Robot Compatibility – Single board supports the full DX100/NX100 robot family, simplifying spare parts inventory for multi-robot facilities
Complete System Bill of Materials
For a fully operational DX100/NX100 controller, the following boards and components are typically required alongside the JANCD-YCP01B-E:
- JANCD-YIF01-E – Network Interface Board
- JANCD-YSF21-E – Safety I/O Board
- JANCD-YBB01-E – Base Board / Backplane
- JANCD-YEW01-E – Servo Amplifier Interface Board
- JZNC-YRK01-1E – Robot Controller Power Supply Unit
- SGDR-AXB01A – Servo Drive Axis Board (cross-reference)
- ZNC-NIF02B-2 – Network Interface Module (cross-reference)
Contact support@konmask.com to source complete controller rebuild kits.
Compliance & Industry Standards
- CE Marked (EU Machinery Directive 2006/42/EC compliant controller platform)
- RoHS Compliant – Yaskawa DX100 platform
- ISO 10218-1 – Robots and robotic devices: Safety requirements for industrial robots
- IEC 61131-3 – Compatible controller architecture
- UL Listed controller system (UL 1740)
Quality Assurance & Sourcing
All Yaskawa boards supplied by Konmask.com undergo the following quality process:
- Visual inspection for physical damage, corrosion, and component integrity
- Functional power-on verification where applicable
- Anti-static packaging with humidity indicator cards
- Traceable lot documentation available on request
- Sourced from authorized distributors, OEM surplus channels, and certified refurbishers
We do not supply counterfeit or grey-market components. All parts are verified against Yaskawa OEM specifications before dispatch.
How to Source This Part
- Confirm your controller model – Verify your controller nameplate reads DX100 or NX100 before ordering
- Check cross-reference – SGDR-AXB01A and ZNC-NIF02B-2 are associated modules; confirm the CPU board is the failed component
- Request a quote – Email support@konmask.com with your robot model, controller serial number, and required quantity
- Lead time – In-stock units ship within 1–3 business days; sourced units typically 5–15 business days
- Bulk & OEM pricing – Volume discounts available for system integrators and MRO procurement teams
Application-Specific FAQ
Q: Is JANCD-YCP01B-E compatible with both DX100 and NX100 controllers?
A: Yes. The JANCD-YCP01B-E CPU board is used across both the DX100 and NX100 controller platforms. Always verify your controller’s backplane revision before installation.
Q: Do I need to re-teach robot positions after replacing this board?
A: If the replacement board is loaded with the same job files and system parameters (backed up from the original controller), re-teaching is not required. Always back up your controller data before any board swap.
Q: Can this board be used in a welding robot application?
A: Yes. The DX100/NX100 platform with JANCD-YCP01B-E supports arc welding, spot welding, and laser welding applications when paired with the appropriate weld interface boards and power sources.
Q: What is the warranty on this part?
A: Warranty terms vary by condition (new, surplus, refurbished). Contact us at support@konmask.com for specific warranty documentation.
Q: Do you offer technical support for installation?
A: Yes. Konmask provides pre-sales technical consultation and post-sales installation guidance for qualified engineers. Contact our team for support.
