YASKAWA SGMSH-15ACA-TV11 High-Speed Servo Motor – SGMSH Series
When a precision servo motor fails on a CNC machining center, a robotic welding cell, or a high-speed packaging line, the entire production process halts. Unplanned downtime in industrial automation can cost thousands of dollars per hour, and sourcing a certified replacement quickly is not optional — it is mission-critical. The YASKAWA SGMSH-15ACA-TV11 is engineered precisely for these high-stakes environments, delivering the torque density, encoder accuracy, and thermal resilience that modern servo-driven machinery demands.
Within YASKAWA’s SGMSH series — the company’s flagship small-frame, high-speed servo motor lineup — the SGMSH-15ACA-TV11 occupies a key mid-range position. Rated at 1.5 kW with an ultra-high-resolution serial encoder and a robust IP67-rated shaft seal option, this model is widely deployed across Asia, Europe, and North America in Σ-7 (Sigma-7) servo drive systems. YASKAWA, headquartered in Kitakyushu, Japan, is the world’s largest manufacturer of AC servo drives and motion controllers, and the SGMSH series represents the pinnacle of their precision motion engineering.
Technical Specifications
- Model Number: SGMSH-15ACA-TV11
- Brand: YASKAWA Electric Corporation
- Series: SGMSH (Sigma-7 Compatible High-Speed Servo Motor)
- Rated Output Power: 1.5 kW
- Encoder Type: 24-bit absolute serial encoder (standard configuration)
- Shaft Type: Straight shaft with key (TV11 suffix)
- Mounting: Flange mount
- Insulation Class: Class F
- Protection Rating: IP67 (shaft seal)
- Cooling Method: Self-cooled (natural convection)
- Compatible Drive Series: YASKAWA Σ-7 (SGD7S), Σ-V (SGDV)
- Country of Origin: Japan
Note: All specifications are based on YASKAWA official documentation. Contact us to confirm exact parameters for your application.
Key Features & Benefits
- Ultra-High Resolution Encoder: 24-bit absolute encoder delivers 16,777,216 pulses/rev, enabling sub-micron positioning accuracy for precision machining and semiconductor handling.
- High Torque Density: Compact SGMSH frame achieves exceptional torque-to-size ratio, reducing machine footprint without sacrificing performance.
- Vibration Suppression: Designed for seamless integration with Σ-7 drives featuring YASKAWA’s built-in vibration suppression algorithms, minimizing settling time.
- IP67 Shaft Seal: Protects against coolant ingress in CNC environments — a critical reliability factor in wet machining applications.
- Wide Speed Range: Maintains rated torque across a broad speed range, supporting both high-speed contouring and low-speed precision feed operations.
- Long Service Life: Premium-grade bearings and thermal management design extend MTBF in continuous-duty industrial cycles.
- Drop-in Replacement Compatibility: Direct mechanical and electrical compatibility with existing SGMSH-series installations minimizes retrofit engineering time.
Industry & Equipment Applications
- CNC Machining Centers: X/Y/Z axis drives on vertical and horizontal machining centers requiring high-speed, high-accuracy contouring.
- Industrial Robotics: Joint actuators in 6-axis articulated robots and SCARA robots for automotive and electronics assembly.
- Semiconductor & FPD Manufacturing: Wafer handling, die bonding, and panel transport systems demanding nanometer-level repeatability.
- Packaging Machinery: High-cycle pick-and-place, form-fill-seal, and cartoning machines in food and pharmaceutical production.
- Printing & Converting: Register control and tension management in web-fed offset and flexographic printing lines.
- Electronic Assembly (SMT): Gantry drives on surface-mount placement machines and solder paste inspection systems.
System Integration & Compatible Parts
The SGMSH-15ACA-TV11 is designed for plug-and-play integration within YASKAWA’s Σ-7 ecosystem. Commonly paired components include:
- Servo Drives: SGD7S-120A000A (1.5 kW Σ-7 amplifier), SGDV-120A01A (Σ-V compatible)
- Encoder Cables: JZSP-CVP02-XX-E (absolute encoder cable, various lengths)
- Power Cables: JZSP-CMP00-XX-E (motor power cable)
- Regenerative Resistors: JUSP-RA04-E (for high-inertia load applications)
- Couplings & Reducers: Compatible with standard servo-grade jaw couplings and planetary gearboxes (ratio selection based on load inertia)
Contact our technical team for a complete BOM and wiring diagram for your specific machine configuration.
Our Quality Assurance Process
- Source Verification: All YASKAWA products are sourced from authorized distributors or directly from YASKAWA’s regional warehouses. We do not handle grey-market or counterfeit goods.
- Incoming Inspection: Each unit undergoes visual inspection, label verification (model code, date code, serial number), and packaging integrity check upon receipt.
- Functional Testing (on request): For critical applications, we can arrange pre-shipment run-in testing with a compatible Σ-7 drive and provide a test report.
- Secure Packaging: Motors are shipped in anti-static foam-lined cartons with desiccant packs to prevent moisture ingress during international transit.
- Traceability: Full lot traceability maintained for warranty and compliance purposes.
How to Order
- Submit an Inquiry: Use the contact form on this page or email support@konmask.com with your required quantity and delivery timeline.
- Receive a Quote: Our team will respond within 1 business day with pricing, lead time, and stock availability.
- Confirm & Pay: We accept T/T (bank transfer), PayPal, and other B2B payment methods. Proforma invoice issued upon order confirmation.
- Shipment & Tracking: Orders are dispatched via DHL, FedEx, or UPS Express. Full tracking information provided within 24 hours of dispatch.
- After-Sales Support: Our engineering team is available for installation guidance and compatibility troubleshooting post-delivery.
Why Choose Konmask.com?
- Industrial Automation Specialists: We focus exclusively on PLC, DCS, servo, and motion control components — not a generalist marketplace.
- Verified Stock & Fast Quotes: Real-time inventory checks with same-day quotation for most in-stock items.
- Global Shipping Expertise: Experienced in export documentation, customs compliance, and international logistics for industrial components.
- Technical Pre-Sales Support: Our engineers can assist with compatibility verification, parameter matching, and system integration advice before you buy.
- Competitive Pricing: Direct sourcing relationships allow us to offer competitive pricing without compromising on authenticity.
- Trusted by Engineers Worldwide: Serving customers in manufacturing, OEM, and MRO sectors across 30+ countries.
Frequently Asked Questions
Q: Is the SGMSH-15ACA-TV11 compatible with YASKAWA Σ-V drives?
A: Yes, the SGMSH series is compatible with both Σ-V (SGDV) and Σ-7 (SGD7S) servo amplifiers, provided the power rating and encoder interface are correctly matched. Contact us to confirm compatibility with your specific drive model.
Q: What does the “TV11” suffix mean in the model number?
A: The suffix encodes specific mechanical and option configurations — including shaft type, brake option, and encoder variant. “TV11” typically denotes a straight shaft with key, no holding brake, and standard absolute encoder. Please confirm with our team for your exact application requirements.
Q: Do you supply the matching servo drive (amplifier) as well?
A: Yes. We stock a wide range of YASKAWA Σ-7 and Σ-V servo amplifiers. We can quote the complete drive-motor set to ensure compatibility and simplify your procurement.
Q: What is the lead time for the SGMSH-15ACA-TV11?
A: Lead time depends on current stock levels. In-stock items typically ship within 3–5 business days. For out-of-stock items, standard lead time is 4–8 weeks from YASKAWA’s factory. Contact us for a real-time availability check.
Q: Can you provide a warranty for this product?
A: Yes. We offer a standard 12-month warranty against manufacturing defects on all genuine YASKAWA products supplied by Konmask.com.
Q: Do you accept returns or exchanges?
A: Unused, unopened items in original packaging may be returned within 30 days of receipt. Please contact our support team to initiate a return authorization.
