Yaskawa JZNC-XPP02B – Teach Pendant for XRC Robot Controller | Motoman XRC Platform
Engineering Background: The Yaskawa JZNC-XPP02B is the OEM-designated teach pendant engineered exclusively for the Yaskawa Motoman XRC robot controller series. Developed by Yaskawa Electric Corporation — a global leader in motion control and industrial robotics — this pendant delivers the precise, low-latency operator interface required for high-reliability robot programming in demanding production environments.
Product Positioning: Designed for automation engineers and system integrators who require a verified, drop-in replacement or spare pendant for existing XRC-based robot cells. The JZNC-XPP02B eliminates compatibility risk and reduces commissioning time, making it the preferred choice for MRO procurement and new cell builds alike.
Complete Technical Specifications
- Part Number: JZNC-XPP02B
- Manufacturer: Yaskawa Electric Corporation
- Compatible Controller: Yaskawa Motoman XRC Series
- Device Type: Robot Teach Pendant (Programming Terminal)
- Country of Origin: Japan
- Unit Weight: 1,040 g (approx. 2.29 lbs)
- Interface: Dedicated XRC controller cable connector
- Display: Integrated LCD panel with backlight
- Input Method: Membrane keypad with dedicated function keys
- Emergency Stop: Integrated E-Stop button (IEC 60204-1 compliant)
- Deadman Switch: Three-position enabling device
- Operating Mode: Teach / Play / Remote
- Language Support: Multi-language menu (English / Japanese)
- Condition Available: New OEM / Refurbished / Tested Used
Proven Application Environments
- Automotive body welding and assembly lines (MIG/TIG/Spot)
- Arc welding and plasma cutting robot cells
- Material handling and palletizing systems
- Paint and coating automation booths
- General-purpose pick-and-place and machine tending
- MRO replacement for existing Yaskawa XRC installations
Engineering Advantages
- OEM Compatibility: Plug-and-play with all Yaskawa Motoman XRC controller variants — no firmware modification required.
- Ergonomic Design: Balanced grip geometry reduces operator fatigue during extended teach sessions.
- Safety-Certified Enabling Device: Three-position deadman switch meets ISO 10218-1 robot safety standards.
- Durable Construction: Industrial-grade housing rated for factory floor environments with resistance to oils, dust, and vibration.
- Full Function Access: Direct access to all XRC motion, I/O, alarm, and job management functions from a single interface.
System Architecture & Signal Flow
The JZNC-XPP02B connects directly to the XRC controller’s teach pendant port via a dedicated shielded cable. Communication is handled through the XRC’s internal serial bus, transmitting operator commands (joint jog, Cartesian jog, job execution, I/O monitoring) to the controller CPU in real time. The integrated E-Stop circuit is hardwired into the controller’s safety relay chain, ensuring fail-safe operation independent of software state.
Signal Path: Operator Input → Pendant Keypad Matrix → XRC Serial Interface → Controller CPU → Servo Amplifier → Robot Axes
Sourcing & Quality Verification
- All units sourced from verified Yaskawa authorized channels or certified industrial surplus with full traceability.
- Pre-shipment functional test: power-on, display check, keypad scan, E-Stop circuit continuity, and deadman switch verification.
- Units shipped with anti-static packaging and physical inspection report on request.
- Batch and serial number documentation available for quality audit purposes.
Procurement Process
- Submit your inquiry with required quantity and condition preference (New / Refurbished / Tested Used).
- Receive a formal quotation with lead time and shipping options within 24 business hours.
- Confirm order — payment via T/T, PayPal, or credit card accepted.
- Unit dispatched with tracking number; typical transit 3–7 business days (DHL / FedEx / UPS).
- Post-delivery technical support available via email or WhatsApp.
Technical FAQ
Q: Is the JZNC-XPP02B compatible with the Yaskawa NX100 or DX100 controller?
A: No. The JZNC-XPP02B is designed exclusively for the XRC controller series. For NX100, the correct pendant is JZNC-XPP11; for DX100, use JZNC-XPP21.
Q: Can I use this pendant without a deadman switch?
A: No. The three-position enabling device is a mandatory safety interlock for teach mode operation per ISO 10218-1. Bypassing it is not permitted.
Q: What is the cable length?
A: Standard OEM cable length is approximately 8 meters. Custom cable extensions are available — contact us for specifications.
Q: Do you provide a warranty?
A: Yes. All tested and refurbished units carry a 90-day functional warranty. New OEM units carry the standard Yaskawa warranty terms.
Q: Can you provide a certificate of conformance or test report?
A: Yes, available upon request for quality-critical procurement.
