Yaskawa JZRCR-YPP01-1 / JZRCR-YPP21-1 / SRDA-SDB95A01A-E – DC24V Power Supply Board | DX100 & DX200 Robot Controller Platform
The Yaskawa JZRCR-YPP01-1 (also catalogued as JZRCR-YPP21-1 and board-level reference SRDA-SDB95A01A-E) is the dedicated DC 24 V regulated power supply board engineered for Yaskawa Motoman DX100 and DX200 robot controller cabinets. Rated at 10Y-06A and carrying the MODEL MCNB hardware revision, this board provides stable low-voltage bus power to the controller’s CPU, I/O, and communication backplane — making it a mission-critical component in any Motoman robotic cell.
Konmask.com sources this unit directly from verified industrial surplus channels and subjects every board to functional power-on verification before dispatch, giving procurement engineers a reliable, traceable alternative to OEM lead times that can exceed 12–16 weeks.
Complete Technical Specifications
- Manufacturer: Yaskawa Electric Corporation (安川電機)
- Primary Part Number: JZRCR-YPP01-1
- Alternate Part Numbers: JZRCR-YPP21-1 / SRDA-SDB95A01A-E
- Hardware Revision: MODEL MCNB
- Rating Code: 10Y-06A
- Output Voltage: DC 24 V regulated
- Compatible Controllers: Yaskawa Motoman DX100, DX200
- Function: Controller backplane power supply — CPU, I/O, and communication bus
- Form Factor: PCB module (plug-in board)
- Country of Origin: Japan
- Weight (approx.): 300 g
- Condition: Used / Refurbished – Functionally tested
Proven Application Environments
- Automotive body-in-white welding and assembly lines using Motoman MA, MH, or HP series robots
- General-purpose 6-axis robot cells with DX100 / DX200 controller cabinets
- Palletising, material handling, and pick-and-place systems requiring continuous 24/7 operation
- Semiconductor and electronics manufacturing with strict uptime SLA requirements
- Maintenance depots and robot service centres holding critical spare inventory
Engineering Advantages
- Drop-in replacement: Identical connector footprint and mounting pattern to OEM — no wiring modification required
- Dual part-number coverage: JZRCR-YPP01-1 and JZRCR-YPP21-1 are functionally interchangeable; SRDA-SDB95A01A-E is the PCB silk-screen reference — all three identifiers resolve to this single unit
- Stable DC 24 V output: Supplies clean regulated voltage to prevent CPU resets and I/O communication faults caused by bus voltage sag
- Tested before shipment: Each unit undergoes power-on functional verification at Konmask’s facility
- Immediate availability: In-stock dispatch vs. OEM lead times of 12–16 weeks
System Architecture & Signal Flow
Within the DX100/DX200 cabinet, the JZRCR-YPP01-1 board receives AC mains input from the primary power unit and converts it to a stable DC 24 V rail. This rail feeds:
- The YCP01 / YCP21 CPU board (controller logic and teach-pendant communication)
- The I/O backplane (digital I/O, safety relay circuits, and fieldbus interface cards)
- Auxiliary 24 V loads such as cabinet fans, door interlocks, and brake release circuits
A failure on this board typically manifests as controller power-on fault codes (e.g., ALARM 0010 – Control Power Supply Fault), random CPU resets, or complete cabinet dead-on-arrival conditions. Replacing this board is the first-line corrective action recommended in Yaskawa’s DX100/DX200 maintenance manual.
Sourcing & Quality Verification
- Source: Verified industrial surplus — decommissioned from operational Motoman cells
- Inspection: Visual inspection (no burnt components, cracked PCB, or corroded connectors) + power-on functional test
- Traceability: Each unit is logged with a unique internal reference number available on request
- Packaging: Anti-static bag + foam-lined carton; ESD-safe handling throughout
- Warranty: 90-day return-to-base warranty against functional defects
Procurement Process
- Confirm your controller cabinet model (DX100 or DX200) and cross-reference the part number on the board label (JZRCR-YPP01-1, JZRCR-YPP21-1, or SRDA-SDB95A01A-E)
- Place order via Konmask.com — payment by T/T, PayPal, or credit card accepted
- Receive dispatch confirmation with tracking within 1 business day
- International shipping available; DDP (Delivered Duty Paid) terms available on request for EU and North American buyers
- For volume orders (>3 units) or blanket PO arrangements, contact support@konmask.com for preferential pricing
Technical FAQ
Q: Are JZRCR-YPP01-1 and JZRCR-YPP21-1 the same board?
A: Yes. Yaskawa revised the part number from YPP01-1 to YPP21-1 in a later production run; both are electrically and mechanically identical and are fully interchangeable.
Q: What is SRDA-SDB95A01A-E?
A: This is the PCB-level silk-screen identifier printed on the board itself. Yaskawa uses a separate assembly part number (JZRCR-YPP01-1) for ordering purposes. Both refer to the same physical board.
Q: Will this board work in a DX200 controller as well as DX100?
A: Yes. The DX100 and DX200 share the same power supply board architecture. This unit is confirmed compatible with both platforms.
Q: What fault codes indicate this board has failed?
A: Common indicators include Yaskawa alarm codes related to control power supply faults, intermittent CPU resets, and teach-pendant communication loss. Refer to your DX100/DX200 maintenance manual Section 7 for the full fault code list.
Q: Do you offer an exchange / core return program?
A: Yes. Contact us before ordering to discuss core exchange pricing if you have a faulty unit to return.
