Industrial Robot Programming Solution – Yaskawa SRDA-SDA21A01A-E / JZNC-XPP02B / JZNC-XPP04B | Teach Pendant Series
Where This Product Is Used
The Yaskawa Teach Pendant Keysheet Film is a precision replacement overlay designed for Motoman industrial robot teach pendants. It is deployed across a wide range of automation-intensive environments where operator interface clarity is mission-critical:
- Automotive Body Welding Lines – Motoman robots performing spot and arc welding require frequent pendant interaction; worn keysheet films cause mis-keying and production stoppages.
- Electronics Assembly & SMT Lines – High-cycle pick-and-place cells where operators teach new waypoints daily accelerate keysheet wear.
- Palletizing & Material Handling – Warehouse and logistics automation using Yaskawa GP/HP series robots with JZNC-XPP02B/XPP04B pendants.
- Painting & Coating Booths – Solvent-rich environments degrade overlay adhesion; periodic replacement maintains legibility and safety compliance.
- Food & Beverage Processing – Frequent washdown cycles accelerate surface wear on pendant overlays.
- Maintenance & Retrofit Projects – MRO teams restoring legacy Motoman cells to OEM specification before recommissioning.
Technical Specifications
- Compatible Part Numbers: SRDA-SDA21A01A-E, JZNC-XPP02B, JZNC-XPP04B
- Manufacturer: Yaskawa Electric Corporation
- Series: Motoman NX / DX100 / DX200 Teach Pendant
- Component Type: Keysheet Film / Button Overlay
- Material: Polyester film with pressure-sensitive adhesive
- Weight: Approx. 300 g (packaged)
- Country of Origin: Japan
- HS Code: 8473.30
- Condition: New / OEM-equivalent
Why Engineers Specify This Model
- OEM Dimensional Accuracy – Laser-cut to match the exact key matrix of JZNC-XPP02B and JZNC-XPP04B pendants; no trimming required.
- Chemical Resistance – Resistant to cutting fluids, lubricants, and mild solvents common in machining and welding environments.
- High-Contrast Legends – Crisp silk-screened legends restore full operator readability, reducing mis-key errors and improving cycle-time consistency.
- Adhesive Stability – Pressure-sensitive adhesive maintains bond across –10 °C to +60 °C operating range without bubbling or peeling.
- Rapid Swap – Field replacement takes under 10 minutes with no special tools, minimizing robot downtime.
- Genuine Yaskawa Lineage – Sourced from authorized Yaskawa distribution channels; traceable to OEM part numbers for audit compliance.
Complete System Bill of Materials
For a full teach pendant restoration or spare-parts kit, engineers typically source the following alongside this keysheet film:
- Yaskawa JZNC-XPP02B Teach Pendant (complete unit)
- Yaskawa JZNC-XPP04B Teach Pendant (complete unit)
- SRDA-SDA21A01A-E Servo Drive / Controller Board
- Pendant cable assembly (DX100/DX200 compatible)
- Emergency stop button module
- Pendant holster / cradle bracket
Contact support@konmask.com for bundle pricing on multi-unit MRO orders.
Compliance & Industry Standards
- Compatible with ISO 10218-1 industrial robot safety requirements
- Supports OSHA 1910.217 machine guarding legibility requirements (clear key labeling)
- RoHS-compliant materials
- CE-compatible for EU machinery directive environments
- Traceable part numbers support ISO 9001 maintenance record-keeping
Quality Assurance & Sourcing
Konmask.com sources Yaskawa components through verified industrial distribution channels. Every unit undergoes:
- Visual inspection for print registration and adhesive coverage
- Part number verification against Yaskawa OEM documentation
- Anti-static packaging to prevent ESD damage during transit
- Batch traceability records retained for 3 years
How to Source This Part
- Add to Cart – Click Buy Now for immediate checkout or Add to Cart for multi-line orders.
- Request a Quote – For quantities ≥ 5 units or bundled BOM orders, email support@konmask.com with your PO requirements.
- Lead Time – In-stock units ship within 1–3 business days; EXW Xiamen, China. DDP and DAP Incoterms available on request.
- Payment – T/T, PayPal, credit card, and LC accepted for qualified buyers.
- Export Documentation – Commercial invoice, packing list, and COO certificate provided for all international shipments.
Application-Specific FAQ
Q: Is this keysheet film compatible with both JZNC-XPP02B and JZNC-XPP04B pendants?
A: Yes. The overlay is dimensionally identical for both pendant variants. Verify your pendant model number on the rear label before ordering.
Q: Can this film be applied without disassembling the pendant?
A: Yes. The pressure-sensitive adhesive allows surface application over the existing keypad frame. Clean the surface with isopropyl alcohol before application for best adhesion.
Q: What robot controllers are compatible with the JZNC-XPP02B/XPP04B pendant?
A: These pendants are used with Yaskawa DX100 and DX200 robot controllers, commonly paired with Motoman MA, MH, HP, and GP series manipulators.
Q: Do you offer OEM certificates or test reports?
A: Yes. Certificates of conformance and sourcing documentation are available upon request for quality audit purposes.
Q: What is the typical replacement interval?
A: In high-cycle environments (>16 hours/day), keysheet films typically require replacement every 12–18 months. Lower-duty applications may extend to 3+ years.
