Robot Programming & Maintenance Solution — Yaskawa NX100 NXC025-1 | Teach Pendant Cable Series
Where This Product Is Used
The Yaskawa NX100 NXC025-1 Teach Pendant Cable is the OEM-specified interconnect between the NX100 robot controller and the Yaskawa Programming Pendant (PP). It is deployed across a wide range of industrial automation environments:
- Automotive body welding lines — arc and spot welding cells using Motoman MA, SK, and UP series robots
- Palletizing & material handling — high-cycle pick-and-place stations requiring reliable pendant communication
- Assembly automation — precision dispensing and fastening cells where uninterrupted teach-mode access is critical
- Painting & coating booths — environments demanding robust cable shielding against EMI/RFI interference
- Maintenance & commissioning — field service teams replacing worn or damaged OEM cables to restore full teach functionality
Technical Specifications
| Part Number | NXC025-1 |
| Compatible Controller | Yaskawa NX100 |
| Cable Length | 2.5 m (8.2 ft) |
| Connector Type | OEM multi-pin shielded, keyed |
| Shielding | Braided EMI/RFI shield |
| Operating Temperature | 0 °C to +50 °C |
| IP Rating | IP54 (connector housing) |
| Weight | 323 g |
| Country of Origin | Japan |
Why Engineers Specify This Model
- OEM pin-out compliance — exact match to Yaskawa NX100 controller port; no adapter required
- Braided EMI shielding — maintains signal integrity in high-frequency welding and servo-drive environments
- Strain-relief overmold — resists flex fatigue at the connector root, extending service life in repetitive teach cycles
- Keyed connectors — prevent mis-mating and protect controller I/O during cable swap
- Drop-in replacement — no firmware or parameter changes required after installation
Complete System Bill of Materials
For a fully operational NX100 teach station, engineers typically specify:
- Yaskawa NX100 Robot Controller
- NXC025-1 Teach Pendant Cable (this item)
- Yaskawa JZRCR-NPP01B-1 Programming Pendant
- E-Stop expansion module (if multi-pendant configuration)
- Cable management conduit / festoon system for overhead routing
Compliance & Industry Standards
- Designed to Yaskawa OEM electrical specification for NX100 series
- EMC shielding meets IEC 61000-4-3 radiated immunity requirements
- RoHS compliant materials
- Compatible with ISO 10218-1 robot safety system architecture
Quality Assurance & Sourcing
Every NXC025-1 unit shipped from Konmask.com undergoes the following verification process:
- Visual inspection of connector pins, overmold, and cable jacket
- Continuity and shield-integrity test on all conductors
- Cross-reference against Yaskawa part number database before dispatch
- Packed in anti-static bag with original part label retained
We source directly from authorized Yaskawa distributors and certified industrial surplus channels. Traceability documentation available on request.
How to Source This Part
- Click Add to Cart or Contact Us for volume pricing.
- Provide your controller serial number if you need compatibility confirmation.
- Orders placed before 18:00 CST ship same business day (stock permitting).
- Global shipping available — DHL Express, FedEx IP, and sea freight for bulk orders.
- Lead time for out-of-stock units: 7–15 business days via factory order.
Application-Specific FAQ
Q: Is NXC025-1 compatible with the NX100 DX100 controller?
A: No. The NXC025-1 is specific to the NX100 controller. For DX100, please inquire about the DX100-series pendant cable.
Q: Can I extend the cable beyond 2.5 m?
A: Yaskawa does not recommend extension cables due to signal attenuation risk. Contact us for longer OEM cable options.
Q: What robots use the NX100 controller?
A: The NX100 is paired with Motoman MA, SK, UP, and ES series robots, commonly used in arc welding, handling, and assembly applications.
Q: Do you provide a warranty?
A: Yes — 90-day warranty against manufacturing defects. DOA units are replaced at no charge.
Q: Is this a new or refurbished part?
A: Please confirm with our team at the time of order. Both new OEM and tested-surplus options may be available depending on stock.
