Closed-Loop Vector Control Solution – YASKAWA PG-B1 73600-A0024 | VS-616G5 Series
Where This Product Is Used
The YASKAWA PG-B1 (Part No. 73600-A0024) is a pulse generator (PG) speed feedback option card designed for installation in YASKAWA VS-616G5 and VS-616PC5 series AC variable frequency drives. It enables closed-loop vector control by feeding real-time encoder signals back to the drive’s control board, making it indispensable in applications where precise speed regulation and torque control are critical.
- CNC Machining Centers – Spindle speed accuracy for milling, turning, and grinding operations
- Textile & Fiber Processing – Tension control and synchronization across multi-axis winding lines
- Paper & Printing Machines – Web tension regulation requiring tight speed loop closure
- Crane & Hoist Systems – Load-dependent torque control with anti-sway positioning
- Pump & Fan Drives – Energy-optimized closed-loop flow control in HVAC and water treatment
- Conveyor & Material Handling – Synchronized multi-drive lines in automotive and logistics facilities
- Elevator & Escalator Drives – Smooth start/stop with encoder-verified speed profiles
Technical Specifications
| Parameter | Specification |
|---|---|
| Part Number | 73600-A0024 |
| Model | PG-B1 |
| Compatible Drive Series | YASKAWA VS-616G5, VS-616PC5 |
| Card Type | PG Speed Feedback Option Card |
| Control Mode Enabled | Closed-Loop Vector (Flux Vector) |
| Encoder Input | Incremental A/B phase pulse encoder |
| Max Input Frequency | 300 kHz |
| Power Supply | +12 V DC (supplied by drive) |
| Interface | Option card slot (CN5) on VS-616G5 control board |
| Weight | 680 g (packaged) |
| Country of Origin | Japan |
Why Engineers Specify This Model
- OEM-Exact Replacement – Direct plug-in to the VS-616G5 option slot; no wiring modification required
- High-Resolution Speed Feedback – Supports encoders up to 300 kHz for sub-RPM accuracy in demanding servo-like applications
- Flux Vector Performance – Unlocks the drive’s full closed-loop vector algorithm, delivering ±0.01% speed regulation
- Robust Signal Conditioning – Built-in line driver receiver tolerates long cable runs in electrically noisy industrial environments
- Proven Field Reliability – YASKAWA option cards are manufactured to the same quality standards as the parent drive, ensuring long MTBF in 24/7 production environments
- Simplified Commissioning – Recognized automatically by the VS-616G5 firmware; parameter A1-02 set to 3 activates closed-loop vector mode
Complete System Bill of Materials
For a fully configured closed-loop vector drive system using the VS-616G5 with PG-B1, engineers typically specify:
- YASKAWA VS-616G5 AC Drive (select kW rating per motor nameplate)
- YASKAWA PG-B1 73600-A0024 – PG Speed Feedback Card (this item)
- Incremental Encoder (1024 PPR recommended; A/B phase, line driver output)
- Shielded encoder cable (twisted pair, ≤50 m recommended)
- YASKAWA SI-B Option Card (if PROFIBUS-DP fieldbus integration is required)
- YASKAWA DriveWizard Plus software (for parameter backup and diagnostics)
Compliance & Industry Standards
- Manufactured under ISO 9001 certified quality management system
- Compliant with CE / UL / cUL directives as part of the VS-616G5 drive system
- RoHS compliant (lead-free PCB assembly)
- Designed to IEC 61800-5-1 (Safety requirements for adjustable speed electrical power drive systems)
Quality Assurance & Sourcing
Konmask.com sources YASKAWA option cards through authorized industrial distribution channels and verified surplus inventory networks. Every unit undergoes the following before dispatch:
- Visual inspection for PCB damage, burnt components, and connector integrity
- Part number and date code verification against YASKAWA documentation
- Anti-static packaging with humidity indicator card
- Photographic documentation available on request
We carry stock of both new-in-box and tested-used units. Condition is clearly stated at time of quotation.
How to Source This Part
Ready to order or need a formal quotation for your procurement team?
- Online: Add to cart directly on this page for in-stock units
- Email RFQ: support@konmask.com – include your drive model, required quantity, and delivery timeline
- Phone / WhatsApp: +0086 19859288691 (Mon–Sat, 09:00–18:00 CST)
- Lead Time: In-stock orders ship within 1–2 business days; DHL / FedEx express available worldwide
Application-Specific FAQ
Q: Is the PG-B1 compatible with the VS-616G3 or VS-616G7 series?
A: No. The PG-B1 (73600-A0024) is specifically designed for the VS-616G5 and VS-616PC5 option slot. For VS-616G3, the correct card is PG-A1; for VS-616G7, please consult the drive’s option card compatibility table.
Q: What encoder PPR (pulses per revolution) does the PG-B1 support?
A: The PG-B1 accepts encoders from 60 PPR to 60,000 PPR. The value is set via drive parameter F1-01. 1024 PPR is the most common selection for general-purpose closed-loop vector applications.
Q: Can I use an open-collector encoder output with the PG-B1?
A: The PG-B1 is designed for line driver (RS-422 differential) encoder outputs. Open-collector encoders require an external pull-up resistor network or a signal converter; consult YASKAWA application note TM.AFD.12 for wiring guidance.
Q: Will the drive fault if the PG-B1 is installed but no encoder is connected?
A: Yes. With A1-02 = 3 (closed-loop vector), the drive will generate a PGO (PG Open) fault at startup if no encoder signal is detected. Ensure encoder wiring is complete before energizing.
Q: Do you provide a warranty on this card?
A: Yes. New-in-box units carry a 12-month warranty. Tested-used units carry a 90-day warranty. Contact us for full warranty terms.
