YASKAWA SGM-02U3B4L – 200W AC Servo Motor | Sigma Series
Engineering Background
The YASKAWA SGM-02U3B4L is a compact, high-response AC servo motor from YASKAWA Electric Corporation’s renowned Sigma (Σ) Series platform — one of the most widely deployed servo families in precision manufacturing, semiconductor equipment, and industrial robotics worldwide. YASKAWA’s servo technology is trusted by OEMs and system integrators across Asia, Europe, and North America for its exceptional torque linearity, encoder accuracy, and long-term reliability in demanding duty cycles.
Product Positioning
This unit is engineered for applications requiring precise speed and position control at the 200W power class. It pairs natively with YASKAWA SGDV/SGDH series servo drives and is a direct replacement or upgrade component for existing Sigma-II and Sigma-III motion systems. Procurement engineers sourcing for MRO, line expansion, or new machine builds will find this motor a verified, specification-matched solution available through Konmask.com’s industrial automation inventory.
Complete Technical Specifications
- Part Number / SKU: 023PLX0100-23 | SGM-02U3B4L | 10.004.22 | RKH/W 500L | 0040-99736
- Manufacturer: YASKAWA Electric Corporation
- Series / Platform: Sigma (Σ) Series – SGM Family
- Motor Type: AC Servo Motor (Brushless Permanent Magnet)
- Rated Output Power: 200 W (0.2 kW)
- Rated Torque: 0.637 N·m
- Rated Speed: 3,000 rpm
- Maximum Speed: 5,000 rpm
- Encoder Type: Incremental / Absolute (per suffix configuration)
- Shaft Configuration: Straight shaft with key (per RKH/W designation)
- Cable Length: 500L (500 mm encoder/power cable)
- Frame Size: 60 mm flange (NEMA / IEC compatible)
- Ingress Protection: IP65 (shaft seal standard)
- Insulation Class: Class F
- Ambient Temperature: 0°C to +40°C (operating); -20°C to +65°C (storage)
- Weight: Approx. 2.6 kg
- Compliance: CE, UL, RoHS
Proven Application Environments
- CNC machining centers and turning lathes (axis feed drives)
- Semiconductor wafer handling and pick-and-place equipment
- Packaging machinery (form-fill-seal, labeling, cartoning)
- Robotic arm joints and SCARA robot axes
- Textile and printing machine web tension control
- Electronic assembly SMT lines and PCB drilling machines
- Medical device manufacturing equipment
Engineering Advantages
- High Torque Density: Compact 60 mm frame delivers 0.637 N·m continuous torque — ideal for space-constrained machine designs.
- Wide Speed Range: 3,000 rpm rated / 5,000 rpm max enables both high-speed positioning and low-speed torque applications.
- Native Drive Compatibility: Plug-and-play integration with YASKAWA SGDV, SGDH, and SGDS servo amplifiers — no parameter mapping required.
- IP65 Sealing: Shaft-end seal protects against coolant splash and fine particulate ingress in machine tool environments.
- Low Cogging Torque: Smooth velocity control at low speeds, critical for precision contouring and tension control.
- Proven MTBF: YASKAWA servo motors are rated for >30,000 hours MTBF under standard operating conditions.
System Architecture & Signal Flow
The SGM-02U3B4L operates within a closed-loop servo system architecture:
- Controller (PLC/CNC/Motion Controller) → issues position/speed/torque commands via pulse train, analog ±10V, or MECHATROLINK-II/III fieldbus
- YASKAWA Servo Drive (SGDV/SGDH) → receives commands, closes current/velocity/position loops, outputs 3-phase PWM power
- SGM-02U3B4L Motor → converts electrical power to mechanical torque; encoder feeds position data back to drive
- Encoder Feedback Cable (500L) → returns incremental/absolute position data at high resolution to the servo drive
This architecture supports position loop bandwidths exceeding 1 kHz, enabling sub-micron positioning repeatability in precision applications.
Sourcing & Quality Verification
- Source: Konmask.com sources YASKAWA components from authorized distributors and verified OEM surplus channels.
- Inspection: Each unit undergoes visual inspection, nameplate verification, and functional pre-shipment checks where applicable.
- Traceability: Original manufacturer part numbers, date codes, and serial numbers are documented and available upon request.
- Warranty: 90-day replacement warranty against DOA (Dead on Arrival) defects. Extended warranty available — contact sales.
- Counterfeit Prevention: We do not source from unverified gray-market channels. All YASKAWA products are cross-referenced against manufacturer databases.
Procurement Process
- Confirm Compatibility: Verify your servo drive model (SGDV/SGDH series) and existing cable harness connector type before ordering.
- Request Quote: Contact [email protected] for volume pricing, lead time, and availability confirmation.
- Place Order: Orders accepted via website checkout, bank transfer (T/T), or PayPal. Pro-forma invoice available for corporate procurement.
- Shipping: Ships from China via DHL Express, FedEx International, or sea freight for bulk orders. Export documentation (commercial invoice, packing list, CO) provided.
- After-Sales: Technical support available via email or WhatsApp: +0086 19859288691.
Technical FAQ
Q: Is the SGM-02U3B4L compatible with SGDV-2R8A01A servo drive?
A: Yes. The SGDV-2R8A01A is rated for 200W motors and is the recommended pairing for this motor. Ensure parameter Pn000.1 is set correctly for encoder type.
Q: What is the difference between SGM-02U3B4L and SGM-02U314L?
A: The suffix characters indicate shaft type, brake, and encoder options. The “B” in position 7 typically denotes a specific shaft/key configuration. Contact us with your application requirements for exact cross-reference confirmation.
Q: Can this motor be used with a third-party servo drive?
A: While physically possible with appropriate wiring adapters, YASKAWA servo motors are optimized for YASKAWA drives. Third-party drive compatibility requires custom parameter tuning and is not guaranteed.
Q: What is the lead time for this part?
A: In-stock units ship within 1–3 business days. Out-of-stock lead time is typically 2–4 weeks depending on sourcing channel. Contact us for real-time availability.
Q: Do you provide a test report or inspection certificate?
A: Yes, a basic inspection report is available upon request. Third-party testing certificates can be arranged for an additional fee.
