Yokogawa A2EE2A-T S1 – 32-Channel Digital Input Module | CENTUM VP / CS 3000 DCS Platform
Engineering Background
The Yokogawa A2EE2A-T S1 is a field-proven digital input (DI) I/O module designed for the CENTUM VP and CS 3000 Distributed Control System (DCS) platforms — Yokogawa’s flagship process automation architecture deployed across refining, petrochemical, power generation, and pharmaceutical industries worldwide. The “-T” suffix denotes the terminal-type field wiring interface, while “S1” identifies the hardware revision series.
Product Positioning
Engineered for procurement engineers and system integrators who require a certified, drop-in replacement or expansion card for existing CENTUM VP / CS 3000 cabinets. The A2EE2A-T S1 delivers high-density, optically isolated digital input acquisition with deterministic scan performance — critical for safety-instrumented and process-critical environments.
Complete Technical Specifications
- Part Number / SKU: A2EE2A-T S1
- Manufacturer: Yokogawa Electric Corporation
- Module Type: Digital Input (DI) I/O Module
- Compatible Platform: CENTUM VP, CENTUM CS 3000
- Number of Channels: 32 DI channels
- Input Voltage: 24 VDC (nominal)
- Isolation: Optical isolation, channel-to-bus
- Wiring Interface: Terminal block (-T type)
- Hardware Revision: S1
- Signal Type: Dry contact / wet contact digital signals
- Scan Cycle: Synchronous with FCS (Field Control Station) scan period
- Power Consumption: Per Yokogawa CENTUM VP I/O specification
- Operating Temperature: 0 °C to 55 °C
- Storage Temperature: −25 °C to 70 °C
- Humidity: 5% to 95% RH (non-condensing)
- Certifications: CE, UL/cUL (per Yokogawa product certification)
- Weight: Approx. 200 g
- Country of Origin: Japan
Proven Application Environments
- Oil & Gas — upstream wellhead monitoring, downstream refinery DCS expansion
- Petrochemical — reactor status, valve position, and interlock signal acquisition
- Power Generation — turbine control, boiler management, and BOP systems
- Pharmaceutical — batch process monitoring under FDA 21 CFR Part 11 environments
- Pulp & Paper — continuous process DI integration with CENTUM VP FCS
- Water & Wastewater — pump status and level switch monitoring
Engineering Advantages
- High-Density I/O: 32 channels per slot maximizes cabinet real estate and reduces wiring cost
- Optical Isolation: Eliminates ground loops and protects the FCS backplane from field-side transients
- Hot-Swap Compatible: Supports online replacement within CENTUM VP redundant I/O architecture (verify with site SOP)
- Deterministic Scan: Synchronized with FCS scan cycle for time-stamped event logging
- Terminal-Type Wiring (-T): Direct field cable termination without marshalling panel adapters
- Long Service Life: Yokogawa CENTUM platform modules are supported for 10+ years post-production
System Architecture & Signal Flow
The A2EE2A-T S1 installs into the CENTUM VP / CS 3000 I/O unit nest. Field digital signals (dry or wet contact, 24 VDC) are wired to the terminal block. The module optically isolates each channel, converts the signal state, and transmits the data over the I/O bus to the Field Control Station (FCS). The FCS processes the DI data within its scan cycle and makes it available to the HIS (Human Interface Station) and historian via the V-net/IP or Vnet control network. Redundant I/O configurations are supported by pairing with a corresponding redundant I/O module and ESB bus coupler.
Sourcing & Quality Verification
- All modules are sourced from authorized distributors or verified industrial surplus channels
- Each unit undergoes visual inspection, label verification, and functional pre-shipment check
- Original Yokogawa part number and revision markings are preserved and verified
- Traceability documentation available upon request for regulated industries
- Packaging: anti-static bag + foam-lined carton for international freight
Procurement Process
- Submit your RFQ via support@konmask.com or add to cart for immediate checkout
- Receive lead time confirmation and proforma invoice within 1 business day
- Payment via T/T, PayPal, or credit card (Shopify Payments)
- Export documentation (commercial invoice, packing list, COO) provided for international shipments
- Shipping via DHL / FedEx / UPS with full tracking; EXW Xiamen or CIF available
Technical FAQ
Q: Is the A2EE2A-T S1 compatible with CENTUM VP R6.x?
A: Yes. The A2EE2A series is compatible across CENTUM CS 3000 and CENTUM VP platforms. Confirm firmware compatibility with your FCS revision via Yokogawa IA documentation.
Q: Can this module replace an A2EE2A (without -T suffix)?
A: The -T suffix denotes terminal-block wiring. Non-T variants use a different field wiring connector. Physical interchangeability depends on your I/O unit nest and field wiring configuration — consult your CENTUM VP I/O unit drawing.
Q: Do you provide a warranty?
A: Yes. Konmask.com provides a 90-day functional warranty on all modules. Extended warranty and on-site support can be arranged for volume orders.
Q: Can I order a single unit?
A: Yes. Minimum order quantity is 1 unit. Volume pricing is available for orders of 5+ units.
Q: What lead time should I expect?
A: In-stock units ship within 2–3 business days. For out-of-stock items, typical lead time is 2–6 weeks depending on sourcing channel.
