DCS Field Wiring Solution – YOKOGAWA AED5D Terminal Board | CENTUM VP / CS 3000 Series
Where This Product Is Used
The YOKOGAWA AED5D Terminal Board is a field-wiring interface module designed for use within YOKOGAWA’s CENTUM VP and CS 3000 Distributed Control Systems (DCS). It serves as the physical termination point between field instrumentation cables and the I/O cards housed in the control cabinet — a critical component in the following industrial environments:
- Oil & Gas Refineries – Terminating transmitter signals from pressure, temperature, and flow instruments on process units
- Chemical & Petrochemical Plants – Providing reliable signal marshalling for hazardous-area field devices
- Power Generation Facilities – Connecting boiler and turbine instrumentation to the DCS I/O subsystem
- Pulp & Paper Mills – Interfacing analog and digital field signals in continuous process control loops
- Pharmaceutical Manufacturing – Supporting validated control architectures requiring traceable wiring documentation
- Water & Wastewater Treatment – Terminating sensor and actuator cables in SCADA-integrated DCS environments
Engineers specify the AED5D when a dedicated, labeled, and mechanically robust terminal interface is required between field cables and YOKOGAWA I/O modules — eliminating direct field-wire termination on sensitive electronics.
Technical Specifications
| Part Number / SKU | AED5D |
| Manufacturer | YOKOGAWA Electric Corporation |
| Series / Platform | CENTUM VP / CS 3000 DCS I/O System |
| Module Type | Terminal Board (Field Wiring Interface) |
| Compatible I/O Cards | YOKOGAWA AAI / AAB / ADV / ADI series I/O modules |
| Mounting | DIN rail / cabinet panel mount |
| Weight | Approx. 1,800 g |
| Signal Type | Analog / Digital field signal termination |
| Country of Origin | Japan |
Note: Full electrical ratings, terminal counts, and connector specifications are available in the YOKOGAWA AED5D datasheet. Contact Konmask for documentation.
Why Engineers Specify This Model
- System-native compatibility – Designed and validated by YOKOGAWA for direct integration with CENTUM VP and CS 3000 I/O cards; no adaptation required
- Simplified field wiring – Clearly labeled screw terminals reduce installation errors and accelerate commissioning timelines
- Mechanical protection – Shields sensitive I/O card connectors from repeated field-cable connect/disconnect cycles, extending card service life
- Maintenance-friendly design – Allows field cable disconnection without disturbing the I/O card, enabling hot-swap maintenance procedures
- Documentation traceability – Terminal numbering aligns with YOKOGAWA engineering drawings, supporting IEC 61511 functional safety documentation requirements
- Proven reliability – Widely deployed across global process industries with a multi-decade installed base
Complete System Bill of Materials
The AED5D Terminal Board is typically specified alongside the following YOKOGAWA components for a complete I/O node assembly:
- YOKOGAWA AAI141 / AAI143 – Analog Input I/O Card (pairs with AED5D)
- YOKOGAWA AAB841 – Analog Output I/O Card
- YOKOGAWA ADV151 / ADV161 – Digital Input / Output I/O Card
- YOKOGAWA ANB10D – Node Unit (I/O bus interface)
- YOKOGAWA AIP835 – I/O Power Supply Module
- Field cable glands and shielded instrumentation cable (customer-supplied)
Contact Konmask to source complete I/O node assemblies or individual replacement components.
Compliance & Industry Standards
- Designed in accordance with IEC 61131 programmable controller standards
- Supports installations compliant with IEC 61511 (Functional Safety – Safety Instrumented Systems)
- Compatible with NAMUR NE 43 signal range conventions for analog transmitters
- Suitable for use in facilities operating under ISA-5.1 instrumentation symbology and documentation standards
- CE marking applicable per YOKOGAWA product certification (verify with current datasheet)
Quality Assurance & Sourcing
Konmask.com sources YOKOGAWA AED5D Terminal Boards through established industrial automation supply channels. Each unit offered is:
- Inspected for physical integrity and connector condition prior to listing
- Stored in ESD-safe, climate-controlled warehouse conditions
- Shipped with appropriate anti-static and mechanical packaging
- Traceable to batch/lot documentation where available
We supply both new surplus and refurbished/tested units. Condition is clearly stated at time of quotation. All sales include a Konmask quality guarantee — contact us if the part does not perform as specified.
How to Source This Part
- Submit an RFQ – Email [email protected] with your required quantity, delivery timeline, and destination country
- Receive a quotation – We respond within 1 business day with pricing, lead time, and stock condition details
- Confirm & pay – Secure payment via T/T bank transfer or other agreed method; export documentation provided for international orders
- Ship & track – DHL / FedEx / sea freight options available; tracking number provided upon dispatch
For urgent plant shutdowns or emergency replacement requirements, call us directly at +0086 19859288691.
Application-Specific FAQ
Q: Is the AED5D compatible with both CENTUM VP and CS 3000 systems?
A: Yes. The AED5D Terminal Board is used across YOKOGAWA’s CENTUM platform generations. Confirm compatibility with your specific I/O card model number before ordering.
Q: Can I use the AED5D with third-party I/O cards?
A: The AED5D is engineered specifically for YOKOGAWA I/O cards. Use with non-YOKOGAWA cards is not supported and may result in wiring incompatibilities.
Q: Do you supply the mating cable/connector between the terminal board and the I/O card?
A: Yes, YOKOGAWA inter-unit cables are available separately. Specify your I/O card model when requesting a quote so we can confirm the correct cable part number.
Q: What is the typical lead time for the AED5D?
A: Lead time depends on current stock status. In-stock units ship within 3–5 business days internationally. Contact us for real-time availability.
Q: Can you provide a certificate of conformance or test report?
A: Yes, documentation is available upon request for new surplus units. Refurbished units include a Konmask test report.
