Yokogawa AFV30D S2 Field Control Unit | CENTUM VP / CS 3000 DCS Platform
Engineering Background
The Yokogawa AFV30D S2 is a Field Control Unit (FCU) designed for deployment within Yokogawa’s CENTUM VP and CS 3000 Distributed Control System (DCS) architectures. As a core field-side controller, it bridges the gap between field instrumentation and the central process control network, executing real-time control logic with deterministic scan cycles. It is engineered for continuous-process industries where uptime, signal integrity, and redundancy are non-negotiable.
Product Positioning
The AFV30D S2 targets process engineers and automation architects who require a proven, OEM-grade FCU for greenfield installations, brownfield expansions, or direct replacement of aging CENTUM CS 3000 field controllers. Konmask.com sources this unit through verified industrial channels, providing procurement teams with a reliable, traceable supply path outside of standard OEM lead times.
Complete Technical Specifications
| Manufacturer | Yokogawa Electric Corporation |
| Model / SKU | AFV30D S2 |
| Module Type | Field Control Unit (FCU) |
| Compatible Platform | CENTUM VP, CENTUM CS 3000 |
| Series | AFV30D |
| Suffix Code | S2 (Standard, Dual-redundancy capable) |
| Control Function | Real-time process control, sequence control, batch control |
| Communication Bus | Vnet/IP (Ethernet-based control bus) |
| Redundancy | Supports dual-redundant FCU configuration |
| Scan Period | Configurable (typical: 100 ms – 1000 ms) |
| I/O Capacity | Expandable via FIO (Field I/O) node modules |
| Power Supply | 24 VDC (via system power bus) |
| Operating Temperature | 0 °C to 55 °C |
| Storage Temperature | -20 °C to 70 °C |
| Humidity | 5% to 95% RH (non-condensing) |
| Weight | Approx. 700 g |
| Mounting | DIN rail / panel-mount within CENTUM FCU nest |
| Certifications | CE, UL (per Yokogawa system certification) |
| Country of Origin | Japan |
Proven Application Environments
- Oil & Gas: Upstream wellhead control, midstream pipeline SCADA integration, downstream refinery unit control
- Petrochemical & Chemical: Continuous reactor control, distillation column management, batch recipe execution
- Power Generation: Boiler combustion control, turbine auxiliary systems, balance-of-plant automation
- Pulp & Paper: Digester control, bleaching sequence automation, recovery boiler management
- Pharmaceuticals: FDA 21 CFR Part 11-compliant batch control, clean-room HVAC automation
- Water & Wastewater: Treatment plant process control, pump station automation
Engineering Advantages
- Deterministic Real-Time Control: Guaranteed scan-cycle execution ensures process stability in high-speed or safety-critical loops
- Dual-Redundancy Architecture: S2 suffix enables hot-standby FCU pairing — zero-bump switchover on primary failure
- Vnet/IP Integration: High-speed, Ethernet-based control bus eliminates proprietary cabling bottlenecks and supports large I/O counts
- Scalable I/O via FIO Nodes: Modular field I/O expansion without FCU replacement — future-proof for plant expansions
- Unified Engineering Environment: Fully integrated with Yokogawa CENTUM VP engineering tools (CAMS for HIS, FCS Builder)
- Long Service Life: Yokogawa’s CENTUM platform has a documented 20+ year lifecycle with backward compatibility commitments
System Architecture & Signal Flow
Within a CENTUM VP system, the AFV30D S2 FCU resides in the Field Control Station (FCS) nest. The signal flow is as follows:
- Field Instruments (transmitters, valves, analyzers) → connect to FIO Node I/O modules via marshalling cabinets
- FIO Nodes communicate with the AFV30D S2 FCU via the internal ESB (Enhanced Signal Bus) or optical bus
- AFV30D S2 FCU executes control logic and communicates upstream via Vnet/IP to the HIS (Human Interface Station) and ENG (Engineering Station)
- In redundant configurations, a secondary AFV30D S2 mirrors the primary in hot-standby mode, monitored via the FCU-to-FCU synchronization link
Sourcing & Quality Verification
- Source Traceability: All units sourced through documented industrial supply channels — no gray-market or counterfeit risk
- Pre-shipment Inspection: Visual inspection, label verification, and firmware/hardware revision check performed before dispatch
- Packaging: ESD-safe anti-static packaging with moisture barrier; original OEM packaging preserved where available
- Warranty: 90-day functional warranty against DOA (Dead on Arrival) defects
- Documentation: Yokogawa part number, revision code, and serial number provided with each unit
Procurement Process
- Submit RFQ: Email support@konmask.com with your required quantity, delivery timeline, and project details
- Receive Quote: Pricing and lead time confirmed within 1 business day
- Order Confirmation: Purchase order issued; payment via T/T, L/C, or agreed terms
- Quality Check & Dispatch: Pre-shipment inspection completed; unit shipped with full documentation package
- After-Sales Support: Technical assistance available for installation verification and system integration queries
Technical FAQ
Q: Is the AFV30D S2 compatible with CENTUM CS 3000?
A: Yes. The AFV30D series is designed for both CENTUM CS 3000 and CENTUM VP platforms. Confirm your system revision with your Yokogawa system documentation before ordering.
Q: What does the “S2” suffix indicate?
A: The S2 suffix denotes the standard dual-redundancy capable variant. It supports hot-standby pairing with a second AFV30D S2 unit for high-availability configurations.
Q: Can this FCU be used as a direct replacement for a failed unit?
A: Yes, provided the hardware revision and firmware version are compatible with your existing FCS configuration. Konmask recommends verifying the revision code against your system’s engineering database before installation.
Q: Do you provide firmware or configuration support?
A: Konmask supplies the hardware unit. Firmware loading and FCS configuration must be performed by a qualified Yokogawa-certified engineer using the CENTUM VP engineering tools.
Q: What is the typical lead time?
A: Stock availability varies. Contact us for current inventory status. Expedited shipping available for urgent plant requirements.
