Genuine YOKOGAWA ANB10D-S1 Node Interface Unit | CENTUM VP / CS 3000 Series – Verified Source
The YOKOGAWA ANB10D-S1 is a Node Interface Unit designed for seamless integration within YOKOGAWA’s CENTUM VP and CS 3000 distributed control systems. Sourced directly through verified supply channels, every unit offered by Konmask.com undergoes rigorous authenticity and functional checks before dispatch.
Technical Specifications
- Manufacturer: YOKOGAWA Electric Corporation
- Part Number / SKU: ANB10D-S1
- Product Type: Node Interface Unit
- Compatible Platform: CENTUM VP, CENTUM CS 3000
- Communication Interface: Vnet/IP or ESB (Engineering Station Bus) — model dependent
- Mounting: DIN rail / panel mount (per system configuration)
- Operating Temperature: 0°C to 55°C
- Storage Temperature: -25°C to 70°C
- Humidity: 5% to 95% RH (non-condensing)
- Power Supply: 24 VDC (system bus powered)
- Weight: Approx. 250 g
- Compliance: CE, UL, IEC 61508 (functional safety ready)
Note: Full datasheet available upon request. Contact [email protected] for OEM documentation.
Our 4-Step Quality Verification Process
Every ANB10D-S1 unit shipped from Konmask.com passes through a documented 4-step verification protocol:
- Step 1 — Source Traceability Check: We verify the unit’s supply chain origin, cross-referencing batch codes and manufacturer markings against YOKOGAWA’s known production standards.
- Step 2 — Physical Inspection: Trained technicians inspect PCB condition, connector integrity, label authenticity, firmware version stamps, and housing for any signs of refurbishment or tampering.
- Step 3 — Functional Bench Test: Where applicable, units are powered up and tested for communication handshake, LED status response, and basic I/O signaling to confirm operational readiness.
- Step 4 — Documentation & Packaging Audit: Units are repackaged with inspection records, and a Konmask quality seal is applied. Certificates of conformance are available on request.
Key Features & Benefits
- Enables high-speed, deterministic node communication within YOKOGAWA DCS architectures
- Plug-and-play compatibility with existing CENTUM VP / CS 3000 field control stations
- Supports redundant network configurations for mission-critical process environments
- Compact form factor minimizes cabinet footprint without sacrificing throughput
- Low power consumption reduces heat load in densely populated control panels
- Firmware-upgradeable to support evolving system requirements
Typical Applications
- Oil & Gas: Upstream wellhead control, midstream pipeline SCADA, refinery DCS expansion
- Petrochemical & Chemical: Reactor monitoring, batch process control, safety interlock systems
- Power Generation: Turbine control networks, boiler management, grid-tie automation
- Pulp & Paper / Food & Beverage: Continuous process lines requiring reliable node-level communication
- Pharmaceutical: GMP-compliant process automation with audit trail support
- Water & Wastewater: Remote node integration in distributed treatment plant architectures
Compatible System Components
The ANB10D-S1 is designed to operate within the following YOKOGAWA ecosystem components:
- CENTUM VP Field Control Station (FCS) — AFC30D, AFV30D series
- CENTUM CS 3000 Field Control Unit (FCU) — ACF11, ACF12 series
- Vnet/IP Communication Bus infrastructure
- ESB (Engineering Station Bus) modules
- YOKOGAWA HIS (Human Interface Station) workstations
- EWS (Engineering Workstation) running CENTUM VP Builder
- Exaopc OPC server for third-party SCADA integration
Contact us to confirm compatibility with your specific system revision and firmware version.
Global Sourcing & Shipping Capabilities
- Stock Availability: In-stock and ex-stock units available for immediate dispatch; lead-time sourcing available for bulk or rare configurations
- Shipping Origin: China (Mainland) — with export documentation and commercial invoice provided
- Supported Incoterms: EXW, FOB Xiamen/Shenzhen, CIF, DAP — negotiable based on order volume
- Courier Partners: DHL Express, FedEx International Priority, UPS Worldwide, SF International
- Lead Time: In-stock: 3–5 business days; Sourced: 7–21 business days (confirmed at order)
- Export Compliance: HS Code classification, ECCN review, and end-user declaration available upon request
- Packaging: Anti-static ESD bag + foam-lined carton; double-boxing available for fragile or high-value orders
Certifications & Compliance Statement
- CE Marking: Compliant with EU Low Voltage Directive and EMC Directive
- UL Listed: Recognized under applicable UL standards for industrial control equipment
- IEC 61508: Functional safety design aligned with SIL-rated system requirements
- RoHS Compliant: Restriction of Hazardous Substances — confirmed for applicable production batches
- ISO 9001 Supply Chain: Konmask.com operates under quality management principles consistent with ISO 9001 procurement practices
Copies of manufacturer compliance documentation are available upon written request for qualified buyers.
How to Order
- Step 1: Add the ANB10D-S1 to your cart and proceed to checkout, or contact us directly for a formal quotation (RFQ).
- Step 2: Provide your shipping destination, required quantity, and any special requirements (e.g., certificate of conformance, specific firmware version).
- Step 3: Receive a proforma invoice (PI) with confirmed lead time, unit price, and shipping cost.
- Step 4: Confirm payment via T/T (bank transfer), PayPal, or other agreed method. Order is locked upon payment confirmation.
- Step 5: Receive tracking number and shipping documents (commercial invoice, packing list, COO) within 24 hours of dispatch.
For urgent requirements or large-volume procurement, email [email protected] or call +0086 19859288691.
Authenticity & Trust FAQ
- Q: Is this a genuine YOKOGAWA part?
- A: Yes. All units are sourced from verified supply channels and inspected against YOKOGAWA’s known manufacturing standards. We do not sell counterfeit, cloned, or relabeled components.
- Q: Can you provide a certificate of conformance (CoC)?
- A: Yes, a Konmask inspection certificate is available for all orders. OEM CoC availability depends on the specific unit’s sourcing batch — please inquire before ordering if this is a hard requirement.
- Q: What is your return policy if the unit is DOA (dead on arrival)?
- A: We offer a 30-day DOA replacement guarantee. Units must be returned in original packaging with a fault description. Shipping costs for verified DOA units are covered by Konmask.
- Q: Do you offer a warranty?
- A: Yes — a 12-month limited warranty against manufacturing defects is included. Warranty does not cover damage from improper installation, overvoltage, or unauthorized modification.
- Q: Can I verify the part number before shipment?
- A: Absolutely. We can provide pre-shipment photos of the actual unit, label, and serial number upon request at no additional charge.
- Q: Do you accept purchase orders (POs) from companies?
- A: Yes. We work with procurement teams, MRO buyers, and engineering firms. Net-30 terms may be available for established accounts. Contact us to discuss.
