Industrial Motion Control Solution – YOKOGAWA F3NC04-OZ | FA-M3 Series
Where This Product Is Used
The YOKOGAWA F3NC04-OZ is a 4-axis position control module engineered for demanding industrial motion applications. It is widely deployed in:
- CNC Machining Centers – Precise multi-axis servo coordination for milling, turning, and grinding operations
- Robotic Assembly Lines – Synchronized axis control for pick-and-place, welding, and palletizing robots
- Semiconductor Wafer Handling – Sub-micron positioning accuracy for wafer transfer and inspection stages
- Printing & Packaging Machinery – High-speed register control and web tension management
- Conveyor & Sorting Systems – Multi-zone position tracking with encoder feedback
- Injection Molding Machines – Clamp, injection, and ejector axis position management
- Textile & Winding Equipment – Traverse and spindle position synchronization
Technical Specifications
| Part Number / SKU | F3NC04-OZ |
| Brand | YOKOGAWA |
| Series | FA-M3 (Wide Field Controller) |
| Module Type | Position Control Module |
| Number of Controlled Axes | 4 axes |
| Control Method | Pulse train output (open-loop / servo driver interface) |
| Max Output Pulse Frequency | 500 kpps per axis |
| Encoder Input | Incremental encoder (A/B/Z phase), line driver |
| Positioning Range | −2,147,483,648 to +2,147,483,647 pulses |
| Interpolation | Linear (2-axis), Circular (2-axis) |
| I/O Interface | FA-M3 backplane bus |
| Power Consumption | 5 VDC, 1.5 A (from backplane) |
| Operating Temperature | 0 °C to 55 °C |
| Storage Temperature | −20 °C to 70 °C |
| Humidity | 10 % to 90 % RH (non-condensing) |
| Weight | 1,480 g |
| Dimensions | Standard FA-M3 single-slot module |
| Certifications | CE, UL, cUL |
Why Engineers Specify This Model
- 4-Axis Simultaneous Control – Reduces cabinet footprint versus discrete motion controllers; one module handles a complete servo system
- 500 kpps High-Speed Pulse Output – Supports high-resolution servo drives without pulse loss at rapid traverse speeds
- Linear & Circular Interpolation – Native interpolation eliminates the need for external motion co-processors in contouring applications
- Seamless FA-M3 Integration – Shares the same backplane, power supply, and programming environment as the host CPU, minimizing integration effort
- Long Product Lifecycle – YOKOGAWA FA-M3 platform has a proven 20+ year support history, reducing obsolescence risk
- Deterministic Scan Cycle – Position data is updated synchronously with the PLC scan, ensuring repeatable motion profiles
Complete System Bill of Materials
A typical FA-M3 position control system using the F3NC04-OZ includes:
- FA-M3 CPU Module (e.g., F3SP71-4S, F3SP76-7S)
- FA-M3 Base Unit (e.g., F3BU04-0N, F3BU13-0N)
- FA-M3 Power Supply Module (e.g., F3PU20-0S)
- F3NC04-OZ Position Control Module (this item)
- Compatible Servo Amplifier (e.g., YOKOGAWA UR series, or third-party pulse-input servo drives)
- Incremental Encoder (line driver, A/B/Z phase)
- Limit Switch / Home Sensor Wiring Harness
- YOKOGAWA WideField3 Programming Software
Compliance & Industry Standards
- CE Marking – EMC Directive 2014/30/EU; Low Voltage Directive 2014/35/EU
- UL / cUL Listed – UL 508 Industrial Control Equipment
- RoHS Compliant – Directive 2011/65/EU (restriction of hazardous substances)
- IEC 61131-2 – Programmable controllers: equipment requirements and tests
- IP20 – Protection rating for open-frame panel-mount installation
Quality Assurance & Sourcing
Every F3NC04-OZ unit supplied by Konmask.com undergoes the following verification process:
- Visual inspection for physical damage, label authenticity, and date code consistency
- Functional power-on test confirming backplane communication and axis initialization
- Traceability documentation available upon request (batch records, test reports)
- Units sourced from authorized distributors or verified surplus channels with full chain-of-custody records
- Packaging in anti-static ESD bags with foam cushioning for safe international transit
How to Source This Part
- In Stock: Add to cart and check out directly — most orders ship within 1–3 business days
- Lead Time / Bulk Orders: Contact support@konmask.com for volume pricing and delivery schedules
- Urgent Requirements: Call or WhatsApp +0086 19859288691 for same-day quotation
- Cross-Reference / Substitution: Our engineers can advise on compatible alternatives if this exact model is unavailable
- Export & International Shipping: We ship worldwide with full export documentation (commercial invoice, packing list, COO)
Application-Specific FAQ
Q: Can the F3NC04-OZ control servo drives from brands other than YOKOGAWA?
A: Yes. The module outputs a standard pulse train (CW/CCW or pulse+direction), compatible with most servo amplifiers that accept pulse-input commands, including Mitsubishi, Panasonic, Delta, and Omron drives.
Q: Does this module support electronic gearing or cam synchronization?
A: Basic linear and circular interpolation is supported natively. Advanced electronic gearing requires ladder logic implementation using the module’s position data registers. Contact us for application-specific programming guidance.
Q: What programming software is required?
A: YOKOGAWA WideField3 (or WideField2 for legacy projects). The F3NC04-OZ is configured via dedicated function blocks within the FA-M3 programming environment.
Q: Is the F3NC04-OZ compatible with the F3BU04-0N and F3BU13-0N base units?
A: Yes, it is compatible with all standard FA-M3 base units. Verify slot power budget (5 VDC, 1.5 A) when planning your rack configuration.
Q: Can I get a warranty on this module?
A: Konmask.com provides a 90-day functional warranty on all tested units. Extended warranty options are available — contact us for details.
