FOUNDATION Fieldbus Solution – YOKOGAWA NFBU200-S00 | CENTUM VP / ProSafe Series
Where This Product Is Used
The YOKOGAWA NFBU200-S00 Fieldbus Communication Module is engineered for demanding process automation environments where reliable, deterministic field device communication is critical. Typical deployment scenarios include:
- Oil & Gas Upstream/Downstream: Connecting HART and FOUNDATION Fieldbus instruments (flow transmitters, pressure sensors, control valves) in wellhead control panels and refinery DCS cabinets.
- Chemical & Petrochemical Plants: Integrating multi-drop fieldbus segments for reactor monitoring, distillation column control, and safety instrumented systems (SIS).
- Power Generation: Boiler management systems and turbine control loops requiring high-speed, noise-immune digital communication.
- Pulp & Paper / Water Treatment: Distributed I/O architectures where long cable runs demand robust fieldbus topology over traditional 4–20 mA wiring.
- Pharmaceutical Manufacturing: FDA-compliant process control networks with full device diagnostics and audit trail support via FOUNDATION Fieldbus.
Technical Specifications
- Model: NFBU200-S00
- Manufacturer: YOKOGAWA Electric Corporation
- Series: CENTUM VP / ProSafe-RS Compatible
- Communication Protocol: FOUNDATION Fieldbus H1
- Fieldbus Segments: Supports multiple H1 segments per module
- Baud Rate: 31.25 kbps (H1 standard)
- Power Supply: Supplied via backplane (CENTUM VP FCS)
- Operating Temperature: 0°C to +60°C
- Storage Temperature: -20°C to +70°C
- Humidity: 5% to 95% RH (non-condensing)
- Mounting: DIN rail / CENTUM VP node unit backplane
- Weight: Approx. 500 g
- Certifications: CE, UL, cUL (refer to YOKOGAWA datasheet for full listing)
Why Engineers Specify This Model
- Native CENTUM VP Integration: Plug-and-play compatibility with YOKOGAWA’s CENTUM VP FCS (Field Control Station) eliminates custom driver development and reduces commissioning time.
- Deterministic Communication: FOUNDATION Fieldbus H1 guarantees cycle-time consistency critical for closed-loop PID control executed at the field device level.
- Advanced Device Diagnostics: Supports NAMUR NE 107 condition monitoring, enabling predictive maintenance and reducing unplanned shutdowns.
- Segment Redundancy Options: Compatible with redundant fieldbus coupler configurations for SIL-rated loops.
- Reduced Wiring Cost: Multi-drop topology (up to 32 devices per segment) significantly cuts cable, conduit, and I/O card costs versus conventional analog wiring.
- Long-Term Availability: YOKOGAWA’s global spare parts program ensures module availability for the full plant lifecycle (20+ years).
Complete System Bill of Materials
For a fully operational FOUNDATION Fieldbus node using the NFBU200-S00, engineers typically specify the following companion components:
- YOKOGAWA CENTUM VP FCS (Field Control Station) — e.g., AFV10D / AFV30D
- YOKOGAWA Fieldbus Power Conditioner — e.g., NFBP100 series
- YOKOGAWA Fieldbus Terminator — passive or active (segment-end termination)
- YOKOGAWA Node Unit / Baseplate — compatible with NFBU200 form factor
- FOUNDATION Fieldbus H1 field instruments (flow, pressure, temperature, valve positioners)
- Shielded twisted-pair fieldbus cable (Type A, IEC 61158-2 compliant)
Compliance & Industry Standards
- IEC 61158-2: Physical layer standard for FOUNDATION Fieldbus H1
- IEC 61784: Communication profile families for industrial networks
- NAMUR NE 107: Self-monitoring and diagnosis of field devices
- IEC 61511 / IEC 61508: Functional safety — compatible with SIL-rated loop architectures
- CE Marking: EMC Directive compliance for European installations
- RoHS Compliant: Restriction of Hazardous Substances
Quality Assurance & Sourcing
At Konmask.com, every YOKOGAWA NFBU200-S00 unit is:
- Sourced from authorized distributors or verified surplus channels with full traceability documentation
- Inspected for physical integrity, label authenticity, and firmware version consistency
- Tested for power-on functionality prior to shipment where applicable
- Shipped with anti-static packaging and humidity indicator cards
- Backed by our 90-day quality guarantee — if the module fails on arrival, we replace or refund
How to Source This Part
- Request a Quote: Contact us at support@konmask.com or call +0086 19859288691 with your required quantity and delivery timeline.
- Lead Time: In-stock units ship within 3–5 business days. Ex-stock or special-order units: 2–4 weeks.
- Payment Terms: T/T (Bank Transfer), PayPal, and trade assurance options available.
- Export & Customs: We handle export documentation (commercial invoice, packing list, COO) for international shipments. HS Code: 8537.10 (programmable controllers / communication modules).
- Bulk Orders: Volume pricing available for MRO stocking programs and EPC project procurement.
Application-Specific FAQ
Q: Is the NFBU200-S00 compatible with CENTUM CS 3000?
A: The NFBU200-S00 is designed for the CENTUM VP platform. For CS 3000 systems, please consult YOKOGAWA’s compatibility matrix or contact us — we can source the appropriate legacy module.
Q: Can this module be used in a SIL 2 safety loop?
A: When integrated within a certified ProSafe-RS architecture and paired with SIL-rated field devices, the fieldbus segment can support SIL 2 applications. Always verify with your functional safety engineer and the YOKOGAWA SIL certificate documentation.
Q: What is the maximum number of field devices per H1 segment?
A: FOUNDATION Fieldbus H1 supports up to 32 devices per segment; however, practical installations typically limit segments to 8–16 devices to maintain adequate bus power and cycle time margins.
Q: Do you provide the YOKOGAWA device description (DD) files?
A: DD files are available from the YOKOGAWA FieldMate / PRM library. We can assist in locating the correct DD version for your host system upon request.
Q: What warranty does Konmask.com provide?
A: We offer a 90-day functional warranty on all modules. Extended warranty and exchange programs are available for long-term MRO contracts.
