Process Wiring Solution – YOKOGAWA NFTI3S-00 S2 | CENTUM VP Terminal Block Series
Where This Product Is Used
The YOKOGAWA NFTI3S-00 S2 Pressure Clamp Terminal Block Module is engineered for field-level signal wiring in distributed control system (DCS) architectures. It serves as the critical interface between field instruments and the CENTUM VP Field Control Station (FCS) I/O subsystem. Typical deployment environments include:
- Oil & Gas Refineries – Connecting pressure transmitters, flow meters, and temperature sensors to the DCS in hazardous-area marshalling cabinets.
- Chemical & Petrochemical Plants – Providing reliable, vibration-resistant terminations for analog and discrete field signals in continuous process loops.
- Power Generation Facilities – Wiring RTDs, thermocouples, and 4–20 mA transmitters to CENTUM VP I/O cards in turbine and boiler control panels.
- Pulp & Paper Mills – Terminating field cables in high-density marshalling racks where space efficiency and re-wiring speed are critical.
- Pharmaceutical & Food Processing – Meeting clean-room and hygienic panel requirements with tool-free pressure clamp connections that reduce contamination risk.
- Water & Wastewater Treatment – Providing corrosion-resistant, maintenance-friendly terminations in outdoor or humid control enclosures.
Technical Specifications
| Part Number | NFTI3S-00 S2 |
| Manufacturer | YOKOGAWA Electric Corporation |
| Series | CENTUM VP / FCS I/O Terminal Block |
| Connection Type | Pressure Clamp (Tool-Free Spring Clamp) |
| Module Type | Field Terminal Block / I/O Wiring Interface |
| Compatible System | YOKOGAWA CENTUM VP Field Control Station (FCS) |
| Weight | 200 g (approx.) |
| Suffix Code | S2 – Standard specification variant |
| Mounting | DIN Rail / Panel Mount (per CENTUM VP cabinet standard) |
| Operating Environment | Industrial control cabinet; refer to CENTUM VP system specifications |
Why Engineers Specify This Model
- Tool-Free Pressure Clamp Connection – Spring-clamp terminals accept conductors without a screwdriver, reducing installation time and eliminating torque-related wiring errors in high-density panels.
- CENTUM VP Native Compatibility – Designed and validated by YOKOGAWA for direct plug-in to CENTUM VP FCS I/O card slots, ensuring zero signal integrity compromise.
- Vibration & Shock Resistance – Pressure clamp mechanism maintains consistent contact force under mechanical stress, critical for rotating-equipment environments.
- High-Density Wiring – Compact form factor supports maximum I/O point density within standard 19″ or 24″ marshalling cabinets.
- Reduced Maintenance Downtime – Field cables can be disconnected and reconnected rapidly during loop checks or card replacements without disturbing adjacent terminations.
- Long Service Life – YOKOGAWA’s industrial-grade materials ensure reliable performance across the full DCS lifecycle (10–20+ years).
Complete System Bill of Materials
The NFTI3S-00 S2 is typically specified alongside the following CENTUM VP components:
- YOKOGAWA CENTUM VP Field Control Unit (FCU) – e.g., AFV10D, AFV30D
- YOKOGAWA I/O Module Cards – e.g., AAI141, AAI143, ADV151, ADV161
- YOKOGAWA Node Interface Unit (NIU) – e.g., ANB10D
- YOKOGAWA Marshalling Cabinet / I/O Cabinet
- Shielded twisted-pair field cable (per instrument loop specification)
- DIN Rail (35 mm TS-35 per IEC 60715)
- End brackets and cable duct accessories
Contact support@konmask.com for complete BOM assistance and cross-reference support.
Compliance & Industry Standards
- Manufactured under YOKOGAWA’s ISO 9001-certified quality management system
- Designed for use within CENTUM VP systems compliant with IEC 61511 (Functional Safety – SIS) and IEC 61508
- Compatible with NAMUR NE 21 EMC requirements for process control equipment
- RoHS compliant materials (confirm with YOKOGAWA datasheet for specific suffix)
- CE marking applicable per CENTUM VP system-level certification
Quality Assurance & Sourcing
Konmask.com specializes in genuine, traceable YOKOGAWA automation components for industrial OEM and MRO procurement. Every unit offered is:
- Sourced from authorized YOKOGAWA distribution channels or verified surplus with full traceability documentation
- Inspected for physical integrity, label authenticity, and correct suffix code prior to dispatch
- Packaged in anti-static, moisture-barrier packaging to preserve connector integrity during transit
- Supported by pre-sales technical consultation for system compatibility verification
How to Source This Part
To place an order or request a quotation for the YOKOGAWA NFTI3S-00 S2:
- Email: support@konmask.com
- Phone / WhatsApp: +0086 19859288691
- Website: https://konmask.com
Please provide your required quantity, delivery timeline, and destination country when enquiring. We support global shipping with export documentation.
