Industrial Process Control Solution – Yokogawa SDV144-S13 S1 | CENTUM VP Series
Where This Product Is Used
The Yokogawa SDV144-S13 S1 Processing Module is a core component deployed across demanding industrial environments where high-reliability distributed control is non-negotiable. Typical application sites include:
- Oil & Gas Refineries – Integrated into CENTUM VP DCS architectures for continuous process monitoring and control of distillation columns, compressors, and separator units.
- Chemical & Petrochemical Plants – Used in batch and continuous process control loops requiring precise signal processing and deterministic scan cycles.
- Power Generation Facilities – Deployed in boiler management systems, turbine control, and plant-wide SCADA integration.
- Pulp & Paper Mills – Supports multi-loop control strategies for digester, bleaching, and recovery boiler processes.
- Pharmaceutical Manufacturing – Applied in GMP-compliant process automation where validated control hardware is required.
- Water & Wastewater Treatment – Integrated into SCADA/DCS hybrid systems for pump station and treatment process automation.
Technical Specifications
| Part Number | SDV144-S13 S1 |
| Manufacturer | Yokogawa Electric Corporation |
| Series | CENTUM VP / CS 3000 |
| Module Type | Signal/Data Processing Module |
| Form Factor | DIN-rail / Rack-mount (CENTUM VP nest) |
| Communication | Vnet/IP (Ethernet-based control bus) |
| Operating Temperature | 0°C to 55°C |
| Storage Temperature | -25°C to 70°C |
| Power Supply | 24 VDC (via nest backplane) |
| Weight | Approx. 2 kg (with packaging) |
| Compliance | CE, UL, IECEx (refer to datasheet) |
Why Engineers Specify This Model
- Proven CENTUM VP Compatibility – Designed and validated for seamless integration within Yokogawa’s CENTUM VP and CS 3000 DCS platforms, eliminating firmware and bus compatibility risks.
- High-Availability Architecture – Supports redundant configuration options to meet SIL and process uptime requirements in critical applications.
- Deterministic Scan Performance – Delivers consistent, low-latency processing cycles essential for tight PID loop control and interlock logic.
- Long Product Lifecycle – Yokogawa’s commitment to long-term parts availability makes this module a safe investment for brownfield plant upgrades and MRO stocking.
- Simplified Maintenance – Hot-swap capable in redundant configurations; module-level diagnostics reduce mean time to repair (MTTR).
Complete System Bill of Materials
For a fully operational CENTUM VP control station incorporating the SDV144-S13 S1, engineers typically specify the following complementary components:
- Yokogawa AFV10D / AFV30D – Field Control Station (FCS) processor unit
- Yokogawa ESB Bus Interface Module – for nest-to-nest communication
- Yokogawa PW481 / PW482 – Redundant power supply modules
- Yokogawa AAI141 / AAI143 – Analog I/O modules (4–20 mA)
- Yokogawa ADV151 / ADV161 – Digital I/O modules
- Yokogawa AIP835 – Vnet/IP interface card for HIS workstation
- CENTUM VP Engineering Workstation (EWS) with R6.xx software license
Contact support@konmask.com for bundle pricing and availability on complete BOM packages.
Compliance & Industry Standards
- IEC 61511 – Functional Safety for Process Industry Sectors (SIL-rated configurations)
- IEC 61508 – Functional Safety of E/E/PE Safety-related Systems
- CE Marking – Electromagnetic Compatibility (EMC) Directive 2014/30/EU
- UL Listed – Industrial Control Equipment (UL 508)
- RoHS Compliant – Restriction of Hazardous Substances Directive
- NAMUR NE 107 – Self-monitoring and diagnosis of field devices
Quality Assurance & Sourcing
At Konmask.com, every Yokogawa module undergoes a structured verification process before dispatch:
- Visual Inspection – PCB, connectors, and housing checked for physical damage or counterfeit indicators.
- Label & Firmware Verification – Part number, revision code, and firmware version confirmed against Yokogawa’s official documentation.
- Functional Bench Test – Where applicable, modules are powered and communication verified prior to shipment.
- Traceability – Each unit ships with a condition report and sourcing declaration. Original Yokogawa packaging preserved where available.
- Warranty – 90-day replacement warranty on all verified units. Extended warranty available on request.
How to Source This Part
- Request a Quote – Email support@konmask.com with your required quantity, delivery timeline, and destination country.
- Receive Availability Confirmation – Our team will confirm stock status, lead time, and pricing within 1 business day.
- Place Order & Confirm Payment – Secure checkout via Shopify. T/T (bank transfer), PayPal, and credit card accepted.
- Shipping & Export Documentation – We handle commercial invoice, packing list, and certificate of origin. DHL / FedEx express available worldwide.
- After-Sales Support – Technical support available via email for installation and integration questions.
Application-Specific FAQ
Q: Is the SDV144-S13 S1 compatible with CENTUM CS 3000 systems?
A: The SDV144 series was originally developed for CS 3000 and is forward-compatible with CENTUM VP in most configurations. Confirm your FCS firmware revision before ordering.
Q: Can this module be used in a redundant pair configuration?
A: Yes. The SDV144-S13 supports dual-redundant deployment when paired with the appropriate nest and power supply modules. Consult your CENTUM VP system engineering guide (TI 33Q01B10-01E) for wiring details.
Q: What is the typical lead time for this part?
A: In-stock units ship within 3–5 business days. For out-of-stock items, lead time is typically 4–8 weeks depending on sourcing channel.
Q: Do you provide an export license for shipment to restricted countries?
A: We comply with all applicable export control regulations. Certain destinations may require an export license under EAR/ECCN classification. Contact us before ordering if your destination is subject to trade restrictions.
Q: Can Konmask.com assist with a full CENTUM VP system build?
A: Yes. We supply complete BOM packages for CENTUM VP control stations. Share your I/O list and we will prepare a full parts quotation.
