Zeiss 348224-9113-1302 VAC Control Board – Vacuum Control Module
When a VAC Control Board fails inside a precision optical or semiconductor processing system, the consequences are immediate and severe: vacuum integrity collapses, process chambers vent uncontrollably, and entire production lines halt. Wafer inspection tools, lithography stages, and coordinate measuring machines (CMMs) all depend on stable vacuum control to maintain sub-micron positioning accuracy. Without a functioning Zeiss 348224-9113-1302, there is no safe path to resume operations — every hour of downtime translates directly into yield loss and missed delivery commitments.
The Zeiss 348224-9113-1302 VAC Control Board is a purpose-engineered vacuum management module designed for Carl Zeiss precision instruments and semiconductor capital equipment. Within the Zeiss spare-parts ecosystem, this board occupies a critical tier: it governs vacuum sensing, valve sequencing, and interlock logic that protect both the optics and the workpiece. Its global installed base spans advanced semiconductor fabs, metrology labs, and high-precision manufacturing facilities across Asia, Europe, and North America — making it one of the most sought-after Zeiss replacement boards on the international MRO market.
Technical Specifications
- Part Number: 348224-9113-1302
- Manufacturer: Carl Zeiss AG
- Module Type: VAC (Vacuum) Control Board
- Form Factor: PCB Assembly (OEM replacement board)
- Weight: 1,850 g (as shipped)
- Compatibility: Zeiss precision optical and semiconductor equipment platforms (confirm with serial number before ordering)
- Condition: New / Refurbished / Tested — specify at inquiry
Key Features & Benefits
- OEM-Grade Precision: Manufactured to Zeiss engineering tolerances, ensuring drop-in compatibility with existing system wiring harnesses and firmware.
- Vacuum Integrity Management: Handles real-time vacuum level monitoring, pump sequencing, and emergency vent interlock — protecting optics and wafers from contamination events.
- Rapid Restoration of Uptime: A direct replacement board eliminates the need for field re-engineering, reducing MTTR (Mean Time To Repair) from days to hours.
- Globally Sourced Inventory: Konmask.com maintains access to surplus and refurbished Zeiss boards through vetted supply channels, supporting urgent AOG (Aircraft/Equipment on Ground) scenarios.
- Traceable Documentation: Each unit ships with available test records and part traceability documentation upon request.
Industry & Equipment Applications
- Semiconductor Manufacturing: Wafer inspection systems, lithography tool stages, and vacuum-chuck metrology platforms.
- Optical Metrology: Zeiss CMM (Coordinate Measuring Machine) systems requiring stable vacuum clamping.
- Precision Optics Production: Lens grinding and coating equipment with vacuum workholding.
- Research & Development Labs: University and national lab instruments using Zeiss optical platforms.
- Aerospace & Defense: High-precision measurement systems in controlled environments.
System Integration & Compatible Parts
The 348224-9113-1302 VAC Control Board is typically integrated alongside other Zeiss control and power distribution modules. When sourcing this board, consider verifying the condition of related assemblies including vacuum pump driver boards, pressure sensor interface cards, and main system controller PCBs. Konmask.com can assist in identifying compatible Zeiss spare parts based on your equipment serial number and system configuration.
Our Quality Assurance Process
- Visual Inspection: All boards are inspected for physical damage, burnt components, and connector integrity before listing.
- Functional Verification: Where test fixtures are available, boards undergo power-on and signal-path testing.
- ESD-Safe Packaging: All PCB assemblies are packed in anti-static bags with foam cushioning to prevent transit damage.
- Traceability: Part numbers, serial numbers (where present), and inspection records are documented for each shipment.
How to Order
- Submit an inquiry via the Contact / Request a Quote form on this page.
- Provide your equipment model, serial number, and required quantity.
- Our technical team will confirm compatibility and availability within 1 business day.
- Receive a formal quotation with lead time, shipping options, and payment terms.
- Upon order confirmation, we arrange secure export packaging and international logistics.
Why Choose Konmask.com?
- Industrial Automation Specialists: We focus exclusively on PLC modules, DCS components, and precision equipment spare parts — not general electronics.
- Global B2B Export Experience: We ship to semiconductor fabs, EPC contractors, and MRO distributors across 40+ countries with full export documentation.
- Technical Pre-Sales Support: Our engineers can cross-reference part numbers and advise on compatibility before you commit to a purchase.
- Competitive Lead Times: Established supplier relationships allow us to source hard-to-find Zeiss boards faster than standard distribution channels.
- Secure Transactions: T/T, L/C, and other B2B payment methods supported with formal commercial invoices.
Frequently Asked Questions
- Q: Is the Zeiss 348224-9113-1302 a new or refurbished part?
- A: We offer both new OEM and professionally refurbished units depending on availability. The condition will be clearly stated in your quotation.
- Q: How do I confirm this board is compatible with my Zeiss system?
- A: Please provide your equipment model number and serial number when submitting your inquiry. Our technical team will verify compatibility before issuing a quote.
- Q: What is the typical lead time?
- A: Lead time varies by stock availability — typically 3–15 business days for in-stock units, and 4–8 weeks for sourced items. We will confirm at the time of quotation.
- Q: Do you provide a warranty?
- A: Yes. Refurbished boards carry a 90-day functional warranty. New OEM units follow the manufacturer’s standard warranty terms.
- Q: Can you ship internationally?
- A: Yes. We ship worldwide via DHL, FedEx, and freight forwarders, with full export documentation including commercial invoice and packing list.
