Marine HMI Solution – Allen-Bradley 2711P-RDT7CM | PanelView Plus 6 Series
The Allen-Bradley 2711P-RDT7CM is a 7-inch WVGA Touch LED Display Module from the PanelView Plus 6 (PVP6) series, engineered for marine-grade and harsh-environment industrial applications. Designed to integrate with the PanelView Plus 6 terminal platform, this display module delivers reliable human-machine interface (HMI) performance in environments where standard panels cannot operate safely.
Where This Product Is Used
The 2711P-RDT7CM is specified across a wide range of demanding industrial and marine environments:
- Marine & Offshore Vessels – Engine room monitoring, navigation control panels, ballast management systems, and propulsion control interfaces on commercial ships, offshore platforms, and naval vessels.
- Oil & Gas Facilities – Wellhead control panels, pipeline SCADA terminals, and compressor station HMI stations requiring marine-certified components.
- Water & Wastewater Treatment – Pump station control, filtration process monitoring, and chemical dosing system interfaces in humid or corrosive environments.
- Food & Beverage Processing – Washdown-tolerant HMI displays for production line monitoring and batch control systems.
- Power Generation & Utilities – Generator set control panels, switchgear monitoring, and substation HMI terminals.
- Mining & Heavy Industry – Conveyor control, crusher monitoring, and process visualization in dusty, vibration-prone environments.
Technical Specifications
| Part Number | 2711P-RDT7CM |
| Series | PanelView Plus 6 (PVP6) |
| Display Size | 7 inch WVGA (800 × 480) |
| Display Type | Color TFT LED Backlight |
| Touch Technology | Analog Resistive Touch Screen |
| Module Type | Display Module (requires logic module) |
| Marine Certification | Marine Grade (M suffix) |
| Operating Temperature | 0 °C to +55 °C |
| Storage Temperature | -20 °C to +70 °C |
| Humidity | 5% to 95% non-condensing |
| Enclosure Rating | NEMA 4/4X, IP65 (front face) |
| Weight | 1.7 kg (approx.) |
| Manufacturer | Allen-Bradley / Rockwell Automation |
| Country of Origin | USA |
Why Engineers Specify This Model
- Marine-Grade Certification (M suffix) – Meets stringent marine classification society requirements, making it the correct choice for shipboard and offshore installations where standard HMI panels are not approved.
- Modular PVP6 Architecture – The display module separates from the logic module, allowing independent replacement of the screen without disturbing the control logic or wiring — reducing downtime and maintenance cost.
- LED Backlight Longevity – LED backlighting provides significantly longer service life compared to CCFL alternatives, critical for remote or hard-to-access installations.
- Seamless FactoryTalk View ME Integration – Fully compatible with Rockwell Automation’s FactoryTalk View Machine Edition software, enabling rapid application development and version-controlled HMI projects.
- Wide Environmental Tolerance – Rated for salt-air, humidity, and vibration conditions typical of marine and offshore environments.
- NEMA 4/4X & IP65 Front Face – Protects against water ingress, dust, and washdown, suitable for both indoor and outdoor-protected panel installations.
Complete System Bill of Materials
The 2711P-RDT7CM is a display module and must be paired with a compatible PanelView Plus 6 logic module to form a complete HMI terminal. Typical system BOM:
- 2711P-RDT7CM – 7″ Touch LED Display Module, Marine (this item)
- 2711P-RP8D / 2711P-RP9 – PanelView Plus 6 Logic Module (select per application)
- 2711P-RSACDIN – DIN Rail Power Supply (if required)
- 1756-EN2T / 1756-EN3TR – EtherNet/IP Communication Module (ControlLogix)
- 2711P-CBL-EX04 – Extension Cable (display to logic module)
- Appropriate panel cutout hardware – Per Rockwell Automation installation drawing
Compliance & Industry Standards
- CE Marking – EU Machinery Directive compliance
- UL Listed – UL 508 Industrial Control Equipment
- Marine Classification – Suitable for DNV, ABS, Lloyd’s Register, and BV certified installations (verify with classification society for specific vessel type)
- RoHS Compliant
- NEMA 4 / NEMA 4X (front face)
- IEC 61131-2 compatible HMI platform
Quality Assurance & Sourcing
At Konmask.com, every Allen-Bradley component is sourced through verified industrial supply channels. The 2711P-RDT7CM units we supply are:
- Inspected for physical integrity and original factory packaging upon receipt
- Stored in ESD-safe, climate-controlled warehousing
- Traceable to batch and lot documentation where available
- Supported by our technical team for pre-sales specification confirmation
We serve OEM integrators, MRO procurement teams, and plant engineering departments requiring reliable sourcing of Rockwell Automation / Allen-Bradley components.
How to Source This Part
- Add to Cart – Place your order directly on this page for standard lead times.
- Request a Quote – For volume orders, project BOM pricing, or expedited delivery, contact our team at support@konmask.com.
- Technical Pre-Sales – Unsure if this is the correct display module for your logic module revision? Our engineers will confirm compatibility before you order.
- International Shipping – We ship globally with full export documentation. DDP and DAP Incoterms available for marine and offshore project procurement.
Application-Specific FAQ
Q: Can the 2711P-RDT7CM be used as a standalone HMI?
A: No. The 2711P-RDT7CM is a display module only. It requires a compatible PanelView Plus 6 logic module (e.g., 2711P-RP8D) to function as a complete HMI terminal.
Q: What is the difference between 2711P-RDT7C and 2711P-RDT7CM?
A: The “M” suffix denotes the Marine-grade variant, which carries additional environmental certifications and construction standards required for shipboard and offshore installations. The non-M version is for standard industrial environments.
Q: Is this compatible with FactoryTalk View ME?
A: Yes. The PanelView Plus 6 platform is fully supported by FactoryTalk View Machine Edition (ME) software. Application files (.MER) developed for PVP6 are compatible with this display module.
Q: What panel cutout dimensions are required?
A: Refer to Rockwell Automation publication 2711P-IN006 for exact panel cutout dimensions and mounting hardware specifications for the 7″ PanelView Plus 6 display module.
Q: Can this display module be replaced in the field without reprogramming?
A: Yes. Because the logic module retains the application program and configuration, replacing only the display module does not require reprogramming — a key advantage of the PVP6 modular architecture.
Q: Do you offer warranty on this part?
A: Yes. Please contact support@konmask.com for warranty terms applicable to your order.
