Machine Control HMI Solution – Allen-Bradley 2711P-T10C21D8S | PanelView Plus 7 Standard Series
The Allen-Bradley 2711P-T10C21D8S is a 10.4-inch SVGA color touchscreen operator interface terminal from Rockwell Automation’s PanelView Plus 7 Standard series. Engineered for demanding industrial environments, this HMI delivers reliable real-time visualization and control across discrete manufacturing, process, and infrastructure applications.
Where This Product Is Used
The 2711P-T10C21D8S is specified across a broad range of industrial sectors where operators require a robust, high-resolution interface to monitor and control automated processes:
- Automotive Assembly Lines – Real-time monitoring of robotic welding cells, conveyor sequencing, and torque verification stations integrated with ControlLogix or CompactLogix PLCs.
- Food & Beverage Processing – Hygienic-area machine interfaces for filling, capping, and labeling lines; supports recipe management and batch reporting via FactoryTalk View ME.
- Water & Wastewater Treatment – SCADA-edge HMI for pump station control, chemical dosing, and alarm annunciation in remote or unmanned facilities.
- Oil & Gas Upstream/Midstream – Wellhead and compressor station operator panels requiring wide-temperature tolerance and vibration resistance.
- Pharmaceutical Manufacturing – 21 CFR Part 11-compatible visualization for validated batch processes, integrated with PlantPAx DCS architectures.
- Material Handling & Logistics – Sortation system operator stations, palletizer control panels, and AGV dispatch interfaces.
- Building Automation & Utilities – Chiller plant, air handling unit, and electrical distribution monitoring panels.
Technical Specifications
- Part Number: 2711P-T10C21D8S
- Catalog Number (Full): AB2711P-T10C21D8S
- Series: PanelView Plus 7 Standard
- Manufacturer: Allen-Bradley / Rockwell Automation
- Display Size: 10.4 inch (diagonal)
- Display Type: SVGA Color TFT LCD with Resistive Touchscreen
- Resolution: 800 × 600 pixels
- Communication: EtherNet/IP (dual-port), DH-485, DF1
- Processor: 1 GHz ARM Cortex-A8
- Memory: 512 MB RAM / 2 GB Flash Storage
- Operating System: Windows Embedded Compact 7
- Software: FactoryTalk View ME (pre-installed runtime)
- Power Supply: 24V DC (18–32V DC range)
- Power Consumption: 30W typical
- Operating Temperature: 0°C to +55°C (32°F to 131°F)
- Storage Temperature: –20°C to +70°C
- Humidity: 5–95% RH (non-condensing)
- Protection Rating: IP65 / NEMA 4/4X (front panel)
- Mounting: Panel cutout, landscape orientation
- Weight: Approx. 1.5 kg
- Certifications: UL, CE, cUL, RCM
Why Engineers Specify This Model
- Dual EtherNet/IP Ports – Enables device-level ring (DLR) topology for fault-tolerant network architectures without additional switches.
- FactoryTalk View ME Runtime Included – No separate software license required for the terminal runtime; reduces total project cost.
- Seamless Logix Integration – Native tag-based communication with ControlLogix, CompactLogix, and GuardLogix controllers eliminates address mapping overhead.
- IP65 Front Panel – Washdown-rated for food, beverage, and chemical environments; protects against dust ingress and directed water jets.
- Wide Operating Temperature – Suitable for unheated enclosures in cold-storage or outdoor-rated cabinet applications.
- Scalable Platform – Application files are portable across the PanelView Plus 7 family, protecting engineering investment when upgrading display sizes.
- Long Product Lifecycle – Rockwell Automation’s extended lifecycle commitment reduces obsolescence risk for long-running capital equipment.
Complete System Bill of Materials
A typical machine control panel using the 2711P-T10C21D8S includes the following complementary components:
- PLC Controller: 1769-L33ERM CompactLogix 5370 L3 Controller
- Power Supply: 1606-XLP95E 24V DC / 95W Power Supply
- EtherNet/IP Switch: 1783-US5T Stratix 2000 Unmanaged Switch (if DLR not used)
- I/O Modules: 1769-IQ16 Digital Input / 1769-OB16 Digital Output
- Enclosure: NEMA 4X stainless steel or polycarbonate panel, min. 400 × 500 mm
- Panel Cutout Hardware: 2711P-RMKP10 Mounting Kit (sold separately)
- USB Programming Cable: 1784-U2DHP USB-to-DH+ / DF1 adapter (for legacy network access)
- FactoryTalk View Studio ME: Development software (PC-side, licensed separately)
Compliance & Industry Standards
- UL 508 – Industrial Control Equipment
- CE Marking – EMC Directive 2014/30/EU & Low Voltage Directive 2014/35/EU
- cUL – Canadian Standards (CSA C22.2 No. 142)
- RCM – Australian/New Zealand Regulatory Compliance Mark
- IP65 – IEC 60529 Ingress Protection (front panel)
- NEMA 4 / 4X – National Electrical Manufacturers Association enclosure ratings
- RoHS Compliant – Restriction of Hazardous Substances Directive
Quality Assurance & Sourcing
Konmask.com sources the 2711P-T10C21D8S through verified industrial distribution channels. Every unit undergoes the following quality process before shipment:
- Visual inspection for physical damage, label integrity, and firmware version verification
- Power-on functional test confirming display, touchscreen calibration, and communication port status
- Authenticity verification against Rockwell Automation authorized distributor documentation
- Anti-static packaging with humidity indicator card and shock-watch label
- Certificate of conformance (CoC) available upon request
We stock both new-in-box (NIB) and factory-reconditioned units. Condition is clearly stated at time of quotation. All units carry a minimum 12-month warranty against manufacturing defects.
How to Source This Part
To request a quote or place an order for the Allen-Bradley 2711P-T10C21D8S:
- Online: Add to cart directly on this page for standard lead times.
- Email RFQ: Send your purchase order or RFQ to support@konmask.com with quantity, required delivery date, and destination country.
- Phone / WhatsApp: +0086 19859288691 (Monday–Friday, 08:00–18:00 CST)
- Bulk / Project Orders: Volume pricing available for orders of 3+ units. Contact us for a project BOM review.
- Lead Time: In-stock units ship within 1–3 business days. Ex-stock orders may require 2–4 weeks.
- Export: We ship worldwide. DDP (Delivered Duty Paid) terms available for select destinations.
Application-Specific FAQ
Q: Is the 2711P-T10C21D8S compatible with Studio 5000 Logix Designer?
A: The terminal communicates with controllers programmed in Studio 5000 via EtherNet/IP tag-based messaging. The HMI application itself is developed in FactoryTalk View Studio ME, not Studio 5000.
Q: Can this terminal replace an older 2711P-T10C4D8 (PanelView Plus 6)?
A: Yes, with minor application migration. The PanelView Plus 7 Standard uses the same FactoryTalk View ME platform. Existing .MER application files can be opened and re-compiled in FactoryTalk View Studio ME v10 or later. Physical mounting dimensions are compatible.
Q: Does the 2711P-T10C21D8S support remote access or VNC?
A: Yes. The terminal supports VNC server functionality, enabling remote monitoring and limited interaction via FactoryTalk Remote Access or any standard VNC client over EtherNet/IP.
Q: What is the difference between the “D8” and “D8S” suffix?
A: The “S” suffix denotes the Standard feature set (as opposed to Performance). Standard terminals include the FactoryTalk View ME runtime and dual EtherNet/IP ports but do not include the extended memory or additional communication options found in Performance variants.
Q: Is this unit suitable for use in a Class I, Division 2 hazardous location?
A: The standard 2711P-T10C21D8S is not rated for Class I, Div. 2 out of the box. For hazardous location applications, consult Rockwell Automation’s 2711P-T10C21D8SK (with appropriate purge/pressurization enclosure) or contact us for a certified solution.
Q: Can I get a datasheet or dimensional drawing?
A: Yes. Contact us at support@konmask.com and we will provide the official Rockwell Automation publication 2711P-TD001 and enclosure cutout drawings in PDF format.
