Allen-Bradley 1769-CRR1 Right-to-Right Bus Expansion Cable – CompactLogix 1769 Series
When a CompactLogix control system cannot physically accommodate all required I/O modules within a single bank, production lines stall, engineers scramble for workarounds, and costly downtime accumulates. Without a reliable bus expansion solution, system architects are forced into expensive controller upgrades or compromised panel layouts that sacrifice maintainability. The Allen-Bradley 1769-CRR1 eliminates this constraint entirely — it is the purpose-engineered right-to-right bus expansion cable that connects two CompactLogix 1769 I/O banks, preserving full backplane communication integrity across the expanded system.
Within the Rockwell Automation CompactLogix 1769 ecosystem, the 1769-CRR1 occupies a critical infrastructure role. It is the right-bank-to-right-bank variant of the 1769 bus expansion cable family, designed specifically for multi-bank configurations where the controller bank must communicate with one or more remote I/O banks mounted to its right side. As CompactLogix systems have become the de facto standard for mid-range industrial automation globally — deployed across automotive, food & beverage, oil & gas, and discrete manufacturing — the 1769-CRR1 has become an indispensable component in thousands of control panel builds worldwide.
Technical Specifications
- Part Number: 1769-CRR1
- Catalog Number: 1769-CRR1
- Manufacturer: Allen-Bradley (Rockwell Automation)
- Series: CompactLogix 1769
- Module Type: Right-to-Right Bus Expansion Cable
- Function: Extends the 1769 backplane bus from the right end of one bank to the right end of an adjacent bank
- Compatible Systems: CompactLogix 1769 I/O expansion banks
- Bus Interface: 1769 backplane serial bus
- Weight: Approx. 120 g
- Certifications: CE, UL (refer to Rockwell Automation product documentation for full certification list)
Key Features & Benefits
- Seamless Bank Expansion: Connects right-side I/O banks without signal degradation, maintaining full backplane communication speed and integrity.
- Plug-and-Play Installation: Designed for tool-free connection between 1769 bank end caps — reduces installation time and eliminates wiring errors.
- Compact Form Factor: Minimal footprint preserves valuable panel space in dense control cabinet installations.
- Rockwell Automation OEM Quality: Manufactured to exact Rockwell Automation specifications, ensuring long-term reliability in 24/7 industrial environments.
- System Scalability: Enables phased I/O expansion without replacing the controller, protecting your capital investment.
- Vibration & EMI Resistance: Engineered for harsh industrial environments with robust connector design.
Industry & Equipment Applications
- Automotive Manufacturing: Body-in-white assembly lines, paint shop conveyors, and powertrain test stands requiring distributed I/O across multiple panel sections.
- Food & Beverage Processing: Packaging lines and filling systems where hygienic panel layouts demand modular I/O bank separation.
- Oil & Gas: Wellhead control panels and pipeline SCADA systems with geographically distributed I/O requirements.
- Material Handling & Logistics: Conveyor sortation systems and automated storage/retrieval systems (AS/RS) with extended I/O counts.
- Water & Wastewater Treatment: Pump station control panels requiring scalable I/O expansion within compact enclosures.
- Discrete Manufacturing: Machine tool controllers, press lines, and robotic workcells using CompactLogix as the primary automation platform.
System Integration & Compatible Parts
The 1769-CRR1 is designed to work within the broader CompactLogix 1769 I/O ecosystem. Commonly integrated with:
- 1769-CRL1 / 1769-CRL2: Left-to-right and right-to-left bus expansion cables for alternative bank configurations.
- 1769-ECR: Right end cap for terminating the final I/O bank in a multi-bank system.
- 1769-ECL: Left end cap for the controller bank.
- 1769-L16ER / 1769-L18ER / 1769-L24ER / 1769-L27ERM: CompactLogix 5370 controllers commonly used with expanded I/O banks.
- 1769-IQ16 / 1769-OB16 / 1769-IF4: Typical 1769 digital and analog I/O modules deployed in expanded banks.
Our Quality Assurance Process
At Konmask.com, every Allen-Bradley 1769-CRR1 unit we supply undergoes a rigorous multi-stage verification process before shipment:
- Source Verification: All units are sourced from authorized distributors or verified surplus channels with full traceability documentation.
- Physical Inspection: Connector integrity, cable sheath condition, and label authenticity are inspected against OEM reference standards.
- Functional Testing: Where applicable, units are bench-tested for backplane communication continuity prior to dispatch.
- Secure Packaging: Anti-static packaging with moisture barrier protection ensures safe transit to any global destination.
- Documentation: Certificate of conformance and inspection report available upon request.
How to Order
- Submit your inquiry via the Contact / Get a Quote button on this page.
- Provide your required quantity, delivery timeline, and destination country.
- Our technical sales team will respond within 24 business hours with availability, lead time, and a formal quotation.
- Upon order confirmation, we arrange export documentation, freight, and customs clearance support as required.
For urgent requirements, contact us directly at [email protected] or call +0086 19859288691.
Why Choose Konmask.com?
- Industrial Automation Specialists: We focus exclusively on PLC, DCS, and industrial control components — not a generalist marketplace.
- Global Export Experience: We ship to 60+ countries with full export documentation, DDP/DAP terms available.
- Technical Pre-Sales Support: Our engineers can verify compatibility with your existing system configuration before you commit to an order.
- Competitive Lead Times: Extensive supplier network enables fast sourcing even for discontinued or hard-to-find part numbers.
- Transparent Quotation: No hidden fees. Clear pricing with itemized freight and handling costs.
Frequently Asked Questions
- Q: What is the difference between 1769-CRR1 and 1769-CRL1?
- A: The 1769-CRR1 connects the right end of one bank to the right end of an adjacent bank (right-to-right). The 1769-CRL1 connects the right end of one bank to the left end of another (right-to-left). The correct cable depends on your physical panel layout and bank mounting orientation.
- Q: How many expansion banks can I connect using the 1769-CRR1?
- A: The CompactLogix 1769 system supports up to 3 expansion banks beyond the controller bank, subject to the total I/O module count and power budget of your specific controller model. Consult Rockwell Automation publication 1769-UM011 for detailed system sizing guidelines.
- Q: Is the 1769-CRR1 compatible with all CompactLogix controllers?
- A: The 1769-CRR1 is compatible with all controllers that support the 1769 I/O platform, including CompactLogix 5370 (L1, L2, L3) and earlier CompactLogix families. It is not compatible with CompactLogix 5380/5480 (Compact 5000 I/O platform).
- Q: Can Konmask.com provide a certificate of conformance?
- A: Yes. A certificate of conformance and inspection report are available upon request for all orders. Please specify this requirement when submitting your inquiry.
- Q: What is the typical lead time for the 1769-CRR1?
- A: Lead time varies by stock availability. In-stock units typically ship within 3–5 business days. For out-of-stock items, our sourcing team will provide an estimated lead time within 24 hours of your inquiry.
