Allen-Bradley 1336-MOD-KC005 Dynamic Brake Kit for 500-600V AC Drives – 1336 PLUS Series
When a high-inertia load — a centrifuge, a winding machine, a heavy conveyor — needs to decelerate rapidly, the energy has to go somewhere. Without a properly rated dynamic brake kit, that regenerative energy surges back into the DC bus of the drive, triggering overvoltage faults, forcing unplanned shutdowns, and in worst cases, damaging the drive’s power section. In demanding 500–600V industrial environments, the margin for error is zero. The Allen-Bradley 1336-MOD-KC005 Dynamic Brake Kit is the engineered answer: it safely dissipates regenerative braking energy through a dedicated resistor circuit, keeping your drive online and your process running.
The 1336-MOD-KC005 is a factory-designed option module within the Allen-Bradley 1336 PLUS AC drive family — one of Rockwell Automation’s most widely deployed variable frequency drive platforms across global manufacturing. Designed specifically for 500–600V class installations, this brake kit integrates directly into the 1336 PLUS drive architecture without external wiring complexity. Its global installed base spans automotive assembly, pulp & paper, metals, and water treatment — industries where controlled deceleration is not a convenience but a process-critical requirement.
Technical Specifications
- Part Number: 1336-MOD-KC005
- Manufacturer: Allen-Bradley / Rockwell Automation
- Series: 1336 PLUS AC Drive
- Module Type: Dynamic Brake Kit (Option Module)
- Voltage Class: 500–600V AC
- Weight: 4.8 kg (as shipped)
- Compatibility: 1336 PLUS series drives rated for 500–600V input
- Installation: Internal option module — mounts within the drive enclosure
- Standards: Designed to Rockwell Automation factory specifications
Note: Specifications above are based on published Rockwell Automation documentation. Always verify against your specific drive nameplate and system design before ordering.
Key Features & Benefits
- Regenerative Energy Dissipation: Safely absorbs and dissipates kinetic energy during rapid deceleration, preventing DC bus overvoltage faults.
- Factory-Integrated Design: Engineered as an OEM option module for the 1336 PLUS platform — no field-fabricated wiring, no compatibility guesswork.
- 500–600V Class Rated: Purpose-built for higher-voltage industrial installations common in North American and international heavy-industry facilities.
- Reduced Drive Stress: Extends the operational life of the main drive by preventing repetitive overvoltage events that degrade power electronics over time.
- Process Continuity: Enables aggressive deceleration ramp profiles without fault trips — critical for cycle-time-sensitive applications.
- Compact Form Factor: Installs within the existing drive enclosure footprint, preserving panel space.
Industry & Equipment Applications
- Automotive Manufacturing: Conveyor systems, transfer lines, and robotic positioners requiring precise, repeatable stop profiles.
- Pulp & Paper: Winder and unwinder drives where web tension control demands controlled deceleration.
- Metals & Steel: Rolling mill auxiliary drives, coiler/decoiler systems with high rotational inertia.
- Water & Wastewater: Large pump and blower drives where soft-stop requirements must be met without bus overvoltage.
- Material Handling: Overhead cranes, hoists, and high-speed sortation conveyors.
- HVAC & Compressors: High-inertia fan and compressor loads in industrial facilities.
System Integration & Compatible Parts
The 1336-MOD-KC005 is designed for use within the Allen-Bradley 1336 PLUS drive family. When planning your system, consider the following related components:
- 1336 PLUS main drive units (various horsepower ratings, 500–600V class)
- 1336-MOD series option modules (communication adapters, I/O expansion, encoder feedback)
- Rockwell Automation 1321 series line reactors and EMC filters for upstream power conditioning
- External braking resistors (if supplemental energy dissipation capacity is required beyond the kit’s internal resistor)
Always consult the 1336 PLUS User Manual (Publication 1336 PLUS-5.0) and your Rockwell Automation distributor for system-level compatibility confirmation.
Our Quality Assurance Process
At Konmask.com, every Allen-Bradley component we source undergoes a structured verification process before it reaches your facility:
- Source Traceability: We document the supply chain origin of each unit — authorized distribution channels, OEM surplus, or certified refurbished stock — and disclose this clearly in our quotation.
- Visual & Physical Inspection: Each unit is inspected for label integrity, connector condition, housing damage, and counterfeit indicators prior to shipment.
- Functional Testing (where applicable): Select units undergo bench-level functional verification. Test reports are available upon request.
- Secure Packaging: ESD-safe packaging with moisture barrier bags and rigid outer cartons to protect sensitive electronics in transit.
- Documentation: Certificate of conformance and inspection records provided with each shipment on request.
How to Order
Konmask.com operates as a B2B inquiry-driven platform. To request a quote for the 1336-MOD-KC005:
- Submit an Inquiry: Use the contact form on this page or email support@konmask.com with your part number, required quantity, and delivery timeline.
- Receive a Quotation: Our technical team will respond within 1 business day with pricing, lead time, and stock availability.
- Confirm & Ship: Upon order confirmation, we arrange secure packaging and international logistics to your facility.
For urgent requirements or large-volume procurement, call us directly at +0086 19859288691.
Why Choose Konmask.com?
- Industrial Automation Specialists: We focus exclusively on PLC, DCS, HMI, and drive components — not a generalist marketplace.
- Global Sourcing Network: Access to both current-production and legacy/obsolete Allen-Bradley parts that are no longer available through standard distribution.
- Technical Pre-Sales Support: Our engineers can assist with compatibility verification, cross-referencing, and system-level questions before you commit to a purchase.
- Transparent Sourcing Disclosure: We tell you exactly what you are buying — new, surplus, or refurbished — with no ambiguity.
- Reliable International Logistics: Experienced in export documentation, customs compliance, and carrier selection for industrial components shipped worldwide.
Frequently Asked Questions
- Q: Is the 1336-MOD-KC005 compatible with all 1336 PLUS drives?
- A: It is designed for 1336 PLUS drives in the 500–600V voltage class. Compatibility depends on the specific drive catalog number and firmware revision. Please provide your drive nameplate details when submitting an inquiry so our team can confirm fitment.
- Q: Do I need an external braking resistor with this kit?
- A: The 1336-MOD-KC005 includes an internal braking resistor sized for typical application duty cycles. High-inertia or high-cycle-rate applications may require supplemental external resistors. Our engineers can assist with duty cycle calculations.
- Q: What is the lead time for this part?
- A: Lead time varies based on current stock levels. Submit an inquiry and we will confirm availability and estimated delivery within 1 business day.
- Q: Can Konmask.com supply a warranty on this component?
- A: Yes. Warranty terms are specified in our quotation and vary by sourcing condition (new OEM, surplus, or refurbished). Details are provided transparently before order confirmation.
- Q: Is this part still in production by Rockwell Automation?
- A: The 1336 PLUS platform is a mature product line. Availability of specific option modules may vary. Konmask.com specializes in sourcing both current and legacy Rockwell Automation components — contact us to confirm current availability.
{
