Genuine PLC 1336F-BRF100-AA-EN 1336 PLUS II - Industrial Automation Part

AB | 1336F-BRF100-AA-EN | 1336 PLUS II AC Drive

SKU: 1336F-BRF100-AA-EN Category: Allen-Bradley

Description

Allen-Bradley 1336F-BRF100-AA-EN 1336 PLUS II AC Drive | Replacement, Equivalent & Selection Guide

The Allen-Bradley 1336F-BRF100-AA-EN is a high-performance AC variable frequency drive from Rockwell Automation’s 1336 PLUS II series. Designed for demanding industrial motor control applications, this drive delivers precise speed and torque regulation for three-phase AC induction motors. This page provides full technical specifications, compatible replacement models, equivalent alternatives, and a practical selection guide to help engineers and procurement teams make confident sourcing decisions.

Technical Specifications

Manufacturer: Allen-Bradley (Rockwell Automation)
Series: 1336 PLUS II
Catalog Number: 1336F-BRF100-AA-EN
Drive Type: AC Variable Frequency Drive (VFD)
Output Power: 100 HP (75 kW) nominal
Input Voltage: 380–480 V AC, 3-Phase
Output Voltage: 0–480 V AC, 3-Phase
Input Frequency: 50/60 Hz
Output Frequency Range: 0–400 Hz
Control Method: Sensorless Vector / V/Hz
Communication: EN (EtherNet/IP) adapter included
Enclosure: Open Type (IP00)
Approximate Weight: 10.88 kg
Certifications: UL, CE, CSA

Compatible Replacement & Equivalent Models

When the 1336F-BRF100-AA-EN is unavailable or end-of-life, the following models are commonly used as direct or near-equivalent replacements. Always verify electrical ratings, frame size, and communication protocol before substitution.

Allen-Bradley PowerFlex 400 (22C-D088A103) – Direct Rockwell replacement; same voltage class, 88A output, EtherNet/IP compatible. Recommended first-choice upgrade path.
Allen-Bradley PowerFlex 70 (20AB088A0AYNANC0) – Compact form factor, equivalent power range, supports DeviceNet/EtherNet/IP. Suitable for panel-mount retrofits.
Allen-Bradley PowerFlex 753 (20F11ND088AA0NNNNN) – Next-generation platform with advanced diagnostics; ideal for new installations requiring long-term support.
Siemens SINAMICS G120 (6SL3224-0BE31-5UA0) – Cross-brand equivalent at 15 kW/100 HP class; requires wiring adaptation and parameter reconfiguration.
ABB ACS580-01-088A-4 – 45 kW/90A equivalent; widely available, strong cross-brand alternative with similar V/Hz and vector control modes.
Schneider Electric Altivar 630 (ATV630D90N4) – 90 kW class equivalent; suitable for pump and fan applications with EtherNet/IP option card.

Note: Cross-brand replacements require engineering review of motor nameplate data, load profile, and control wiring before installation.

Why Choose the Original Model

Proven Reliability: The 1336 PLUS II series has decades of field-proven performance in heavy industrial environments.
Native Rockwell Integration: Seamless integration with Studio 5000, RSLogix 5000, and ControlLogix/CompactLogix PLC platforms via EtherNet/IP.
Sensorless Vector Control: Delivers high starting torque and precise speed regulation without encoder feedback.
Broad Application Coverage: Suitable for pumps, fans, conveyors, compressors, and general-purpose motor loads.
Established Spare Parts Ecosystem: Wide availability of replacement boards, HIM modules, and communication adapters.

Typical Applications

Centrifugal pumps and water treatment systems
HVAC fans and air handling units
Conveyor and material handling lines
Compressors and blowers in process industries
Mixers and agitators in chemical/food processing
General-purpose industrial motor speed control

System Compatibility

PLC Platforms: ControlLogix (1756), CompactLogix (1769), SLC 500, PLC-5 (via gateway)
Communication Networks: EtherNet/IP (native via -EN suffix), DeviceNet, ControlNet (with adapter modules)
HIM Modules: Compatible with 1336-MOD-L2, 1201-HA2, and remote HIM panels
Software: RSLogix 5000 / Studio 5000, DriveExplorer, DriveExecutive
Motor Types: Standard NEMA/IEC 3-phase AC induction motors

Selection Guide

Use the following criteria to confirm the 1336F-BRF100-AA-EN is the correct drive for your application, or to select an appropriate replacement:

Step 1 – Motor HP/kW Rating: Confirm motor nameplate HP. This drive is rated for 100 HP (75 kW) at 480 V. For motors above or below this range, select the corresponding catalog number in the 1336 PLUS II or PowerFlex series.
Step 2 – Input Voltage: Verify supply voltage is 380–480 V AC, 3-phase. For 208–240 V applications, select the -AA voltage code variant.
Step 3 – Communication Protocol: The -EN suffix denotes EtherNet/IP. If your network uses DeviceNet (-DN) or ControlNet (-CN), select the matching suffix.
Step 4 – Enclosure: Open-type (IP00) for panel mounting. For standalone installations, consider a NEMA 1 or NEMA 12 enclosure kit.
Step 5 – Control Mode: Standard V/Hz is default. Enable sensorless vector mode in parameters for applications requiring higher starting torque.
Step 6 – Replacement vs. Upgrade: For like-for-like replacement, source an original 1336F-BRF100-AA-EN. For a supported upgrade path, the PowerFlex 400 or PowerFlex 753 is recommended by Rockwell Automation.

Quality Assurance & Sourcing

Authenticity: All units sourced by Konmask.com are verified against manufacturer documentation and serial number records.
Condition Options: New surplus (factory-sealed), refurbished (tested to OEM specs), and used (functional tested) units available — condition clearly stated on each listing.
Testing: Refurbished and used units undergo power-on functional testing and insulation resistance checks prior to shipment.
Warranty: 12-month warranty on new surplus and refurbished units; 90-day warranty on used units.
Traceability: Full documentation available including test reports and country of origin declarations upon request.

How to Order

Online: Add to cart directly from this page. Secure checkout with multiple payment options.
Email: Send your BOM or part number list to support@konmask.com for a formal quotation.
Phone/WhatsApp: +0086 19859288691 — available for urgent inquiries and bulk orders.
Lead Time: In-stock items ship within 1–3 business days. Ex-stock lead times quoted at time of order.
Shipping: Worldwide shipping via DHL, FedEx, UPS, and EMS. Export documentation provided for international orders.
